Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Radxa ROCK 5 ITX RK3588 mini-ITX motherboard review – Building an Arm PC and NAS with Debian KDE

Radxa ROCK 5 ITX RK3588 mini-ITX motherboard review – Building an Arm PC and NAS with Debian KDE

ROCK 5 ITX Review: Build Arm Computer NAS

In this review, I’ll show how I installed Debian on the ROCK 5 ITX mini-ITX motherboard powered by a Rockchip RK3588 octa-core Arm Cortex-A76/A55 processor, before building a computer/NAS with the Arm mini-ITX motherboard, testing various features and running benchmarks. In the first part of the review, we checked out the Radxa ROCK 5 ITX (Arm) and Jupiter (RISC-V) mini-ITX motherboards with specifications and unboxing, and the Auriga 6-Bay NAS mini-ITX chassis used in this review. I already built the computer with the Jupiter RISC-V mini-ITX motherboard, so here I simply switched the RISC-V motherboard with the Radxa ROCK 5 ITX Arm motherboard and installed a few SATA drives. Radxa ROCK 5 ITX first boot – A tricky start… Radxa provides getting started instructions on the documentation website which I mostly follow to hopefully boot within a few minutes. I had to prepare the hardware first. So I installed a […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Luckfox Pico Mini – A tiny Arm Linux camera board based on Rockchip RV1103 SoC with 64MB on-chip RAM

Luckfox Pico Mini – A tiny Arm Linux camera board based on Rockchip RV1103 SoC with 64MB on-chip RAM

Luckfox Pico Mini A microSD card

Luckfox Pico Mini is a tiny (28 x 21 mm) board based on the Rockchip RV1103 Cortex-A7 camera SoC with a built-in 0.5 TOPS NPU, 64MB on-chip DDR2 RAM, USB-C port for power and data, two rows of headers with up to seventeen GPIOs, and five castellated holes for Ethernet. Two versions are offered: the Pico Mini A with a microSD card slot or the Pico Mini B with an extra 128MB SPI NAND flash. Both boards are a shorter version of the Luckfox Pico with similar features but additional GPIOs and the Luckfox Pico Plus model also adds an RJ45 Ethernet port. Luckfox Pico Mini A and B specifications: SoC – Rockchip RV1103 SoC CPU – Arm Cortex-A7 processor @ 1.2GHz + RISC-V core Memory – 64MB DDR2 NPU – 0.5 TOPS NPU with support for INT4, INT8, and INT16 ISP – 4M @ 30 fps ISP Storage MicroSD […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Radxa ROCK E20C “Mini Network Titan” features 2.0 GHz Rockchip RK3528A SoC, dual GbE, metal case

Radxa ROCK E20C “Mini Network Titan” features 2.0 GHz Rockchip RK3528A SoC, dual GbE, metal case

Radxa ROCK E20C router

Radxa ROCK E20C, also “dubbed Mini Network Titan”, is a router with dual Gigabit Ethernet, a USB 2.0 host port, and a microSD card slot powered by a Rockchip RK3528A quad-core Cortex-A53 processor clocked at 2.0 GHz. Housed in a CNC aluminum alloy case, the ultra-compact fanless router is offered with 1GB to 4GB LPDDR4 memory, 8GB to 32GB eMMC flash, and also exposes two USB-C ports, one for power and the other for serial console access without having to tear down the device. Radxa ROCK E20C specifications: Processor – Rockchip RK3528A CPU – Quad-core Arm Cortex-A53 @ 2.0 GHz GPU – Arm Mali-G450 GPU with support for OpenGL ES1.1, ES2.0, and OpenVG 1.1 APIs VPU H.264, H.265, and AVS2 decoder up to 4Kp60 H.264 and H.265 encoder up to 1080p60 NPU – 1 TOPS NPU (TBC) Memory – 1GB, 2GB, or 4GB LPDDR4 Storage 8GB, 16GB, or 32GB eMMC flash […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Firefly EC-R3576PC FD is an Embedded Large-Model Computer based on Rockchip RK3576 processor

Firefly EC-R3576PC FD is an Embedded Large-Model Computer based on Rockchip RK3576 processor

Firefly RK3576 Embedded Large Model Computer

Firefly EC-R3576PC FD is described as an “Embedded Large-Model Computer” powered by a Rockchip RK3576 octa-core Cortex-A72/A53 processor with a 6 TOPS NPU and supporting large language models (LLMs) such as Gemma-2B, LlaMa2-7B, ChatGLM3-6B, or Qwen1.5-1.8B. It looks to be based on the ROC-RK3576-PC SBC we covered a few weeks ago, and also designed for LLM. But the EC-R3576PC FD is a turnkey solution that will work out of the box and should deliver decent performance now that the RKLLM toolkit has been released with NPU acceleration. However, note there are some caveats doing that on RK3576 instead of RK3588 that we’ll discuss below. Firefly EC-R3576PC FD specifications: SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, four Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU – ARM Mali-G52 MC3 GPU clocked at 1GHz with support for OpenGL ES 1.1, 2.0, and 3.2, OpenCL up to 2.0, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Akeana unveils 10 RISC-V cores suitable for microcontrollers up to data center chips

Akeana unveils 10 RISC-V cores suitable for microcontrollers up to data center chips

Chip Diagram Akeana 5000

Founded about three years ago, Akeana has just officially launched and announced three 32-bit and 64-bit RISC-V processor lines and SoC IP with the Akeana 100 series for 32-bit microcontrollers, the Akeana 1000 series for 64-bit processors with MMU, and the Akeana 5000 series with much higher single-thread performance and designed for laptops, data centers, and cloud infrastructure. The company also introduced Scalable Coherent Interconnect, Interrupt Controller, and IOMMU IP for building out compute subsystems based on the aforementioned RISC-V cores,  as well as AI-targeted Vector RISC-V Cores and Matrix Computation IP. The design team is said to have previously worked on Marvell’s ThunderX2 server chips. Akeana 100 Series The Akeana 100 Series is a line of highly configurable processors with 32-bit RISC-V cores that support applications from embedded microcontrollers to edge gateways, to personal computing devices. Four Akeana 100 RISC-V cores are available Akeana 110 for area- and power-constrained […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on The first Realtek RTL8157 5Gbps Ethernet to USB 3.2 adapters are now available for $35

The first Realtek RTL8157 5Gbps Ethernet to USB 3.2 adapters are now available for $35

RTL8157 USB 3.2 to 5GbE adapter

WisdPi WP-UT5 is the first Realtek RTL8157 5Gbps Ethernet (5GbE) to USB 3.2 adapter to make it to market, following the launch of Realtek RTL8126 5Gbps Ethernet PCIe and M.2 adapters last June, and the announcement for both the RTL8126 and RTL8157 chips at Computer 2023 last year. While the RTL8126 dongles and cards are fairly cheap at around $16 on average and as low as $12, the WisdPi WP-UT5 is sold at a premium for about $35 on AliExpress, but we can expect the price to down come as more companies introduce 5GbE to USB 3.2 adapters. For reference, the 2.5GbE variants based on RTL8156(BG) can be had for about $20 on Amazon. WisdPi WP-UT5 specifications: Chip – Realtek RTL8157 USB USB 3.2 Type-C female port A-C and C-C cables to support hosts with USB Type-C or Type-A ports Ethernet 10/10/100/2500/5000 Mbps Ethernet Supports 5G Lite (2.5Gbps data rate) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Efinix introduces the low-power Topaz RISC-V SoC FPGA family for “high-volume, mass-market applications”

Efinix introduces the low-power Topaz RISC-V SoC FPGA family for “high-volume, mass-market applications”

Efinix Topaz RISC-V SoC FPGA

Efinix Topaz is a new low-power RISC-V SoC FPGA family manufactured with the same 16nm TSMC process as the Efinix Titanium SoC FPGA, but optimized for high-performance in a low-power footprint, and targetting high-volume, mass-market applications. The Topaz SoC FPGAs provide fewer features than the Titanium family but still offer up to four RISC-V hard cores, PCIe Gen3, MIPI interfaces, LPDDR4, LVDS, and 12.5 Gbps transmitter with most features being optional and depending on the exact SKUs selected. Efinix Topaz key features and specifications: FPGA compute fabric Up to 326,080 logic elements (LEs) Up to 19.22 Mbits embedded memory Up to 1,877 10-Kbit SRAM blocks Up to 1,008 embedded DSP blocks Memory – 10-kbit high-speed, embedded SRAM, configurable as single-port RAM, simple dual-port RAM, true dual-port RAM, or ROM FPGA interface blocks Optional 32-bit quad-core hardened RISC-V block (RISCV32I with M, A, C, F, and D extensions and six pipeline […]

Posted on by Sponsored Post - 4 Comments on $129 coupon code for GEEKOM A7 mini PC with AMD Ryzen 9 7940HS CPU (Sponsored)

$129 coupon code for GEEKOM A7 mini PC with AMD Ryzen 9 7940HS CPU (Sponsored)

GEEKOM A7 coupon code

You can now get $129 off the GEEKOM A7 mini PC with the coupon code CNX129OFF for the configuration based on an AMD Ryzen 9 7940HS octa-core/16-thread processor, 32GB RAM, and a 2TB NVMe SSD by purchasing it on the GEEKOM US website. This brings the price down to $670 after applying the discount code instead of $799 for the regular price. The mini PC also supports up to four 4K displays through HDMI 2.0 and USB-C ports, provides fast networking via a 2.5GbE jack and a WiFi 6E + Bluetooth 5.3 module, and offers plenty of USB ports for expansion in a compact form factor. GEEKOM A7 specifications: SoC – AMD Ryzen 9 7940HS 8-core/16-thread processor up to 4.0GHz with 16MB cache, AMD Radeon 780M Graphics; TDP: 35 to 54W System Memory – 32GB dual-channel DDR5-5600 via 262-pin SODIMM sockets, upgradeable to 64GB Storage 2TB NVMe PCIe x4 Gen […]
