July 24, 2022July 28, 2022 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

NanoPi R4SE dual Gigabit Ethernet router adds 32GB eMMC flash

NanoPi R4SE is a variant of the Rockchip RK3399-powered NanoPi R4S dual Gigabit Ethernet router that adds a 32GB eMMC flash instead of only relying on a microSD card for the operating system. Most of the specifications remain the same with dual GbE, two USB 3.0 ports, but the router is now only offered with 4GB LPDDR4 and there’s no option for only 1GB RAM, and the GPIO and USB 2.0 headers are gone. The listed temperature range also changed from -20°C to 70°C to 0°C to 80°C. NanoPi R4SE specifications: SoC – Rockchip RK3399 hexa-core processor with dual-Core Cortex-A72 up to 2.0 GHz, quad-core Cortex-A53 up to 1.5 GHz, Mali-T864 GPU with OpenGL ES1.1/2.0/3.0/3.1, OpenCL, DX11, and AFBC support, 4K VP9 and 4K 10-bit H265/H264 60fps video decoder System Memory – 4GB LPDDR4 Storage – 32GB eMMC flash, MicroSD card slot Networking – 2x GbE, including one native Gigabit […]

July 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Acromag XMC-7A50-AP323 – An XMC module based on AMD Xilinx Artix-7 FPGA

Acromag XMC-7A50-AP323 is an XMC (Switched Mezzanine Card) module based on a Xilinx Artix-7 FPGA with 48 TTL I/O channels plus a 16-bit ADC for 20 differential or 40 single-ended analog inputs. Designed for commercial off-the-shelf (COSTS) applications, Acromag XMC modules are RoHS compliant, and suitable for automation applications, scientific development labs, as well as aerospace and military applications. Acromag XMC-7A50-AP323 module specifications: FPGA – AMD Xilinx Artix-7 (XC7A050) FPGA with 52,160 logic cells, 65,200 Flip flops, 2,700 kb block RAM, 120 DSP slices Storage – 32Mbit QSPI flash memory FPGA Digital I/O 48x I/O channels controlled in groups of eight channels, 5V tolerant TTL, RS485, and LVDS interface options: Build Option A: 24x EIA-485/422 channels Build Option B: 24x TTL and 12x EIA-485/422 channels Build Option C: 24x LVDS channels Analog Input 20 differential or 40 single-ended inputs Flexible scan control 16-bit A/D resolution 8μs conversion time FIFO buffer […]

July 22, 2022July 25, 2022 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Banana Pi BPI-W3 – An RK3588 SBC with dual Gigabit Ethernet, SATA, PCIe x4 slot

Banana Pi BPI-W3 is yet another upcoming Rockchip RK3588 SBC but with a different set of features, notably the presence of two Gigabit Ethernet ports, a PCIe x4 slot, and a SATA port, besides to more common dual HDMI output, HDMI input, USB 2.0/3.0 ports, etc… The board layout is somewhat similar to the company’s BPI-RK3588 SBC but with a system-on-module, and instead, the Rockchip RK3588 processor is soldered directly onto the board together with 8GB LPDDR4, and 32GB eMMC flash. Banana Pi BPI-W3 specifications (preliminary): SoC- Rockchip RK3588 octa-core processor with 4x Cortex-A76 cores @ up to 2.4 GHz (YMMV), 4x Cortex-A55 cores @ 1.8 GHz, an Arm Mali G610MC4 GPU, a 6 TOPS NPU, 8K 10-bit decoder, 8K encoder System Memory – 8GB LPDDR4 Storage – 32GB eMMC flash, SATA III port Video Output – 2x HDMI 2.1 ports up to 8Kp60 Input – 1x HDMI 2.0 input […]

July 21, 2022June 12, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

OSM Size M SiP Integrates STM32MP1 MPU for industrial & IoT applications

ARIES Embedded MSMP1 OSM-compatible system-in-package (SiP) based on STM32MP1 CortexA7/M4 microcontroller for Industrial and IoT applications follows the company’s MSRZG2UL and MSRZFive OSM-compatible SiPs with Renesas Arm or RISC-V microprocessor introduced a few months ago. But instead of coming in the ultra-compact 30×30 mm OSM Size S form factor, the new MSMP1 complies with the larger 45x30mm OSM Size M form factor with a total of 476 contacts to allow for more I/Os. The SiP also integrates 512 MB to 4 GB DDR3L RAM, and 4 to 64 GB eMMC flash. MSMP1 SIP specifications: SoC – STMicro STM32MP1 single or dual-core Arm Cortex-A7 processor up to 800MHz, with Arm Cortex-M4 real-time core up to 209MHz, Vivante GPU compatible with OpenGL ES 2.0 System Memory – 512MB – 4GB DDR3L RAM Storage – 4GB – 64GB eMMC NAND Flash 476-contact LGA with Networking – Gigabit Ethernet USB – USB 2.0 Host/OTG […]

July 20, 2022February 25, 2023 by Jean-Luc Aufranc (CNXSoft) - 70 Comments

Rock 5B RK3588 SBC preview – What works, what doesn’t in Debian 11

I’ve recently received an early sample of Radxa ROCK5 Model B (aka ROCK 5B) SBC part of the “Developer Edition” batch with 16GB RAM, and already showed the hardware and it booting successfully in Debian 11.

I’ve now spent more time with the board, and as part of the “debug party” tested performance and features in Debian 11. As one would expect, some things work fine, providing excellent performance, but others still need improvements.

July 19, 2022February 24, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Nano-U12P – An 8K digital signage player powered by an Intel Alder Lake processor

Alder Lake processors were first formally announced at the end of 2021 with the most powerful H-Series, followed by a range of Alder Lake Edge IoT processors, and in February, Intel officially launched Alder Lake P-Series and U-Series mobile hybrid processors which I had expected to find in several mini PCs by now. But apart from ASRock iBOX 1200 Series announcement, and leaks of the NUC 12 Studio Pro, I had not really seen any. But today, I found what looks like a mini PC with the Polywell Nano-U12P, but it’s instead marketed as an 8K digital signage player with a choice of Alder Lake P-series and U-series processors. Nano-U12P specifications: SoC (one or the other) Intel Core i7-1280P 6P+8E (20 threads) processor @ 3.60/4.80GHz with Intel Xe graphics; 20/28W TDP Intel Core i7-1270P 4P+8E (16 threads) processor @ 3.50/4.80GHz with Intel Xe graphics; 20/28W TDP Intel Core i7-1260P 4P+8E […]

July 19, 2022August 11, 2022 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

CrowPi L Raspberry Pi 4 laptop review – Part 1: Unboxing and teardown

CrowPi L Raspberry Pi Education Laptop Review

Elecrow CrowPi L is an 11.6-inch laptop shell based on Raspberry Pi 4 designed for STEM education with optional electronics modules and tutorials. That’s an evolution of the CrowPi 2 laptop I reviewed in 2020 with a thinner design and more flexible since the electronics modules are optional, so it can serve the market of people just wanting a Raspberry Pi 4 laptop. The company has sent me a full “CrowPi L Advanced Kit” for review with the CrowPi L laptop fitted with a Raspberry Pi 4, as well as the Crowtail Starter Kit for Raspberry Pi. CrowPi L Advanced Kit Unboxing Let’s check out the laptop package first. Since in this design, the laptop comes with a battery, and mine already had a Raspberry Pi 4 installed, I could just turn it on immediately. Accessories include a wireless mouse, a 12V/2A power supply (with USB Type-C plug… this should […]

July 18, 2022August 2, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Geniatech XPI-3566 is a business-card sized Rockchip R3566 SBC

Geniatech has added a new member to its XPI SBC family with the business card-sized XPI-3566 board powered by a Rockchip RK3566 quad-core Cortex-A55 processor, and mostly following the Raspberry Pi 3 form factor like its predecessors. The single board computer comes with 1GB to 8GB RAM, up to 64GB eMMC flash, HDMI 2.0 video output, Gigabit Ethernet, dual-band WiFi, a few USB ports, and a 40-pin GPIO header. It is said to target retail, “interactive communication”, and education applications. Geniatech XPI-3566 specifications: SoC – Rockchip RK3566 quad-core Cortex-A55 processor @ up to 1.8 GHz with Arm Mali-G52 2EE GPU, 0.8 TOPS AI accelerator System Memory – 2GB DDR (1GB, 4GB, or 8GB optional） Storage 16GB eMMC flash (8GB, 32GB, 64GB optional） MicroSD card socket Video Output HDMI 2.0 up to 4Kp60 MIPI DSI connector (not listed in the specs, but it can clearly be seen on the board) Camera […]
