September 14, 2016September 14, 2016 by Jean-Luc Aufranc (CNXSoft) - 29 Comments

Broadlink MP1 Quad Socket WiFi Power Strip Review and Teardown

Broadlink MP1 is an inexpensive ($20) power strip with four international sockets that can be controlled over WiFi. Since I was interested in finding out how the power strip was designed internally, I asked GearBest whether they could send a sample for evaluation, which they did, and I got it today. So I’ll first check the device, and hardware design, before trying it with the Android app. Broadlink MP1 Unboxing I don’t have much to say about the package, it’s just a bland white box with Broadlink logo. The bottom of the package is useful however, as it contains a sort of user guide in Chinese together with the specifications. I could not find any mentions of CE/FCC/CCC (for WiFi) or UL/TUV (safety) certifications on the package. There’s no more information inside the box, except what looks like a warranty card in Chinese. The power strip itself has four multi-standard […]

September 14, 2016July 31, 2020 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Widora-NEO OpenWrt WiFi IoT & Audio Board is Based on Mediatek MT7688 SoC, WM8960 Audio DAC

A couple of weeks ago, I reviewed ReSpeaker board combining MediaTek MT7688 WiFi SoC with WM8960 audio DAC, running OpenWrt, and allowing you to perform tasks using text-to-speech and speech-to-text thanks to the built-in microphone (or optional microphone array), and a 3.5mm audio jack to connect speakers, as well as several I/O pins. It turns out there’s been board with similar features, minus the built-in microphone, available in China for a while. Meet Widora-NEO. Widora-NEO board specifications: SoC – Mediatek MT7688AN MIPS SoC @ 580 MHz with built-in WiFi System Memory – 128 MB RAM Storage – 16MB SPI flash, micro SD card Connectivity – 10/100M Ethernet, 802.11 b/g/n WiFi 1T1R up to 150 Mbps with PCB antenna, or IPEX connector Audio – 3.5mm jack for stereo headphone and mono microphone, WM8960G audio codec USB – 1x micro USB port for programming via CP2104 chip, 1x micro USB host (or […]

September 12, 2016September 12, 2016 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Pine64 Unveils $2 PADI IoT Stamp WiFi IoT Module with FreeRTOS SDK, Upcoming ARM mbed 5.0 Support

Realtek RTL8710 WiFi IoT modules came out as potential competitors to ESP8266 modules last month, with similar features. an ARM Cortex M3, and a pricing as low as $2 in quantities. However, documentation is often in Chinese only, and based on my experience with an RTL8710AF module limited to AT commands set for now. Software and documentation are likely to improve a lot however, as Pine64, the makers of Pine A64 boards, are about to launch their own “PADI IoT Stamp” RTL8710AF module for just $1.99 in any quantities. PADI IoT Stamp specifications: SoC – Realtek RTL8710AF ARM Cortex-M3 @ 83 MHz with 1MB ROM, 512KB RAM, and 1MB flash Connectivity – 802.11 b/g/n WiFi @ 2.4 GHz – 2.5 GHz (2400 MHz – 2483.5 MHz) with PCB antenna; Station / SoftAP / SoftAP + Station modes; Expansion headers – 22 half-holes with Up to 1x SPI @ 41.5 Mbps […]

September 8, 2016February 25, 2018 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

u-Blox Unveils SARA-R4 LTE Cat M1 and SARA-N2 NB-IoT Modules for Professional IoT Applications

While I’ve mostly read about SigFox and LoraWan solutions for long range, low power, and low bitrate communications for the Internet of Things so far, there are many active of planned LPWAN standards for IoT applications, and 3GPP Release 13 standard stipulates two LTE LPWAN standards, namely LTE Cat M1 (eMTC) and LTE Cat NB1 (NB-IoT), with the former supporting 1 Mbps downlink and uplink peak data rates, and the latter 250 Kbps downlink, and 250 Kbps (multi-tone) or 20 Kbps (single tone) uplink data rates. U-Blox has released modules for both standard with SARA-R4 LTE Cat M1 and SATA-N2 NB-IoT modules. SARA-N2 Cat NB1 cellular module specifications: LPWAN Connectivity – 3GPP Release 13 NB1; NB-IoT bands: 5, 8, 20; downlink: 227 Kbps, uplink: 21 Kbps Positioning – GNSS via Modem Interfaces – 1x UART, 1x SPI, 2x GPIO, 1x DDC(I2C) for GNSS Features – Antenna supervisor, embedded IPv4 & […]

September 5, 2016September 6, 2016 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

You Can Now Buy ESP3212 ESP32 WiFi + Bluetooth Module for $6.95

After the official launch of ESP32 processor for less than $3, it did not take long before ESP32 modules hit the market, and Seeed Studio has already listed ESP3212, one of the first modules based on Espressif ESP32 Bluetooth LE + WiFi SoC, for $6.95 with shipping scheduled to start on September 23, 2016. ESP3212 module specifications: SoC – Espressif ESP32 dual core Xtensa LX6 processor @ up to 240 MHz with 448 KB flash, 520 KB SRAM, 16 KB SRAM in RTC, WiFi and Bluetooth LE connectivity Storage – 4MB Winbond SPI flash Connectivity 802.11 b/g/n/e/i WiFi (HT40) up to 150 Mbps Bluetooth 4.2 BR/EDR and BLE 3 dBi PCB antenna Headers – 22x GPIOs (multiplexed with ADC, Touch, DAC, SPI, UART, CAN, ETH, IR, PWM, and I2S), 1x UART, Sense VP/Sense VN, EN pin. 3.3V and GND Power Supply – 3.0 – 3.6V Dimensions – 24 x 16 […]

September 5, 2016September 5, 2016 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

$5 Wemos D1 mini Pro ESP8266 Board includes 16MB Flash

Wemos D1 mini is one of my favorite ESP8266 development boards thanks to its small size, shield support, and low $4 price tag. There’s now a new version of the board – dubbed Wemos D1 mini Pro – with 16MB flash instead of 4MB for the original version, and a few other modifications. Wemos D1 mini Pro specifications: WiFi 802.11 b/g/n module based on ESP8266EX with 16 MB flash, chip antenna and external antenna connector Expansion – Through holes with 11x digital input/output pins (3.3V) supporting interrupt/PWM/I2C/one-wire (except D0 pin) 1x analog input (3.3V max input) Reset and power signals (5V, 3.3V, GND) USB – micro USB port Misc – Reset button Power – 5V via micro USB or 5V pin Dimensions – 34.2 x 25.6 mm Weight – 2.5 grams Beside the larger flash, the main differences are listed in a Wemos forum post: External antenna connector – switch […]

September 2, 2016September 3, 2016 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Espressif ESP32 WiFi & Bluetooth SoC is Now Up For Sale for $2.85

Espressif ESP32 is one of the most awaited chip for IoT applications as it combines a dual core processor, WiFi, Bluetooth 4.0, and various I/Os. The good news is that you can now purchase ESP32 for 19 RMB ($2.85) on Taobao, or if you are not based in China, contact Espressif by email at sales [at] espressif.com. Availability is however limited, and the maximum order is now 5 pieces. ESP32 modules and boards, as opposed to just the SoC, are not quite ready right now, but should become available in a few weeks. ESP-WROOM-32 is the ESP32 module developed by Espressif, and NodeMCU is also working on an ESP32 board, so we’ll get more good news very soon. You can also find documentation, hardware and software resources on a Espressif ESP32 page , including a getting started guide, ESP32 SDK, ESP32 reference manual, ESP-WROOM-32 datasheet, and more. If you are […]

August 29, 2016August 29, 2016 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

Broadlink MP1 is a $20 WiFi Power Strip with 4 Independent Sockets

There are plenty of WiFi sockets going around such as Broadlink SP2 or Kankun KK-SP3, but in some cases it might be both more convenient and cheaper to get a WiFi power strip, and Broadlink MP1 offers just that with 4 sockets that can be controlled and programmed (timer) independently, and sold for just $19.88 on Banggood. Broadlink MP1 specifications: Connectivity – 802.11b/g/n WiFi, controllable over 3G/4G with smartphone 4 multi-standard (EU/US/AU, but not UK) sockets Power input – 10A/250V (max) Power output – 10A/250V (max) Rated power – 2000W Total Misc – Power button Dimensions – 254mm x 60mm x 32mm; 50cm sockets spacing; cord Length – 1.5m with AU plug (Adapter provided for other countries) Weight – 450g The power strip can be controlled via Broadlink ihc (Intelligent Hone Control) app available for Android and iOS, which lets you independently manually turn on or off or set timers […]
