July 22, 2021July 29, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

MagikEye Developer Kit enables 120 fps 3D sensing on Raspberry Pi

MagikEye ILT001 developer kit (DK-ILT001) is a low-latency 3D sensing kit that connects to the Raspberry Pi’s MIPI CSI camera connector and features the company’s Invertible Light Technology (ILT) module with an infrared laser and a CMOS image sensor. The company says a “unique algorithm” developed in-house can generate 3D point cloud datasets acquired at high speeds (up to 120 fps) and with very low latency using simple hardware configuration. The kit targets researchers, students, and hobbyists working on machine vision, robotics, automated carriers, and other projects that can benefit from low-latency 3D sensing. MagikEye DK-ILT001 kit key features and specifications 850nm infrared light laser CMOS image sensor Range up to 1.5 meters (15 to 80 cm recommended) Compatibility – Raspberry Pi Zero W/3B/3B+/4 Power Supply – 3.3V (via MIPI Interface on Raspberry Pi) Power Consumption – 0.6W (average) Dimensions – 44 x 24 x 16 mm (within enclosure) Weight […]

March 2, 2021March 2, 2021 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

tCam-Mini IR thermal camera board ships with ESP32 module

While there are plenty of ESP32 camera boards, it’s much harder to find off-the-shelf solutions with ESP32 wireless SoC and an IR thermal camera. That’s likely why Dan Julio decided to design tCam-Mini board combining an ESP32 module with a Flir Lepton 3.5 sensor with 160×120 resolution to capture radiometric data for thermographic analysis. tCam-Mini board hardware specifications: Wireless module – Espressif ESP32-WROVER-E module with dual-core ESP32-D0WD0V3 WiSoC, 8 MB PSRAM, 8 MB Flash, and PCB antenna; Camera – Flir Lepton 3.5: 160×120 pixel radiometric LWIR camera with shutter operating in either Radiometric/TLinear (each pixel contains temperature data) or AGC modes (no temperature data in each pixel but better images). Expansion – 4-pin I2C header Debugging – Micro USB port with CP2102N-A02 USB to UART bridge for ESP32 boot loader control Misc – Dual color (Red/Green) status LED, Factory/Wifi Reset button Power supply – 5V input via micro USB port […]

January 25, 2021January 25, 2021 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Firefly dual-lens AI camera module comes with Rockchip RV1109 or RV1126 processor

We’ve very recently written about Rockchip RV1126 quad-core Cortex-A7 processor designed AI cameras thanks to a 2.0 TOPS AI accelerator together with its little dual-core brother: RV1109. We’ve also found some RV1109 and RV1126 evaluation boards, but prices were in the hundreds of dollars. It was then brought to our attention than the upcoming MAIX-III board would feature RV1126 at a more affordable cost, but it turns out there’s no need to wait as Firefly has just launched a dual-lens AI camera module based on either Rockchip RV1109 or RV1126 for under $100 with respectively CAM-C1109S2U and CAM-C1126S2U models. Both version of the modules have the same specifications except for the processor: SoC (one or the other) RV1109 SoC with CPU – Dual-core Arm Cortex-A7 @ 1.5 GHz + RISC-V MCU @ 400 MHz GPU – 2D graphics engine NPU – 1.2 TOPS with support for INT8/ INT16 VPU Encoder […]

October 13, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Remodo X is a Programmable Bluetooth & IR Remote Control for Raspberry Pi (Crowdfunding)

There are plenty of Bluetooth or RF remote controls on the market, but Remodo X is a little different. Mainly designed for the Raspberry Pi board, the compact Bluetooth & IR remote control comes with four buttons that can be programmed from a mobile app to launch program or trigger scripts for home automation, home entertainment, or any other function you may think of. Remodo X specifications: Connectivity Bluetooth LE up to 30 meters (line-of-sight) via Realtek BLE 4.2 Class 2 chip IR up to 10 meters User Input – 4x keys for 8 different actions using long or short presses Misc – Buzzer for “find me” function Power Supply – 2x AAA batteries Dimensions – 114 x 36 x 13 mm Weight – 37 grams The remote control can be programmed in the yet-to-be-released Remodo app for Android or iOS with any smartphone that comes with Bluetooth LE connectivity. […]

April 7, 2020July 20, 2020 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Beware of Defective, Wrongly Manufactured IR Thermometers

There is a lot of demand for medical supplies and equipment due to COVID-19. IR Thermometers are used to check the temperature of people before entering a building for instance and are also in short supply. So factories are frantically mass-producing everything they can from face masks to IR thermometers, and it looks like some may forgo quality control. The latter are very hard to find in Thailand, but one person managed to purchase an IR thermometer online and decided to open it… [Update April 16th 2020: The Facebook video has been taken down, but still available on Youtube] This Heaco MDI908 medical thermometer’s infrared board is not connected to the mainboard, so it “works” even without the IR sensor… This takes “non-contact infrared thermometer” to a whole new level 🙂 I can see Kaidee (Thailand’s eBay) had some listed a few days, but the pages have since then been […]

March 27, 2020March 27, 2020 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

This Non-Invasive AI Temperature Screening System Checks Multiple Persons On-the-Fly

Yesterday, I had to go to the bank with the branch located in a building where they closed all doors except one in order to make sure all people were wearing masks, check their temperature, and let them wash hands with alcohol hand gel. Those are good preventive measures to slow the spread of SARS-CoV-2 virus, but in case many people visit a location that’s also time-consuming. I’ve just come across a system that should speed up the process, as it can check forehead temperature of people as they walk by, using a camera and artificial intelligence for face detection, and an IR camera/thermometer to report temperature. Remote AI temperature screening system specifications: SoC/Memory/Storage – Don’t know, but I would not be surprised if it was based on RK3399 since Rockchip often promotes AI use cases for this processor. External Storage – MicroSD card, USB drive Video Output- HDMI 2.0 […]

September 22, 2019 by Jean-Luc Aufranc (CNXSoft) - No Comments

PUCK 2 Bluetooth to IR Bridge Allows you to Control Appliances from your Android or iOS Phone

We’ve already seen there are several solutions to control IR appliances such as air conditioners or (dumb) televisions via your smartphone thanks to solutions such as ZaZa Remote that adds an IR transmitter to your 3.5mm audio jack or more recently via your USB-C port. If you don’t quite like having extra hardware connected to your smartphone WiFi to Infrared bridges such as the compact and omnidirectional Broadlink RM Mini 3 are cost-effective solutions, although you’d need one in every room where you wish to control appliances. I’ve recently noticed an even smaller “smartphone to IR” solution with PUCK v2 Bluetooth to IR bridge. The full technical details about PUCK 2 have not been made available, but we do know it’s a Bluetooth 4.2 to infrared remote bridge that transforms any iOS or Android device into a remote. The infrared LED has a range of about 4.5 meters, while Bluetooth […]

June 25, 2019June 25, 2019 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Vosen V1 S905X2 Android TV Box Doubles as a Home Gateway with IR Blaster and Z-Wave Support

At first look, Vosen V1 appears to be like any other 4K HDR Android TV box powered by Amlogic S905X2 quad-core Cortex-A53 processor, but it offers a bit more thanks to a built-in IR blaster allowing you to control other appliances in the room such as air conditioner, television, or A/V receiver. The box can be further enhanced by plugging-in a Z-Wave USB adapter to control & monitor even more compatible devices around the house such as light bulbs or water-leak sensors. Vosen V1 specifications: SoC – Amlogic S905X2 quad core Arm Cortex-A53 with Mali-G31 MP2 GPU System Memory – 2GB LPDDR4 RAM Storage – 16GB eMMC flash, microSD card slot up to 32GB Video & Audio Output – HDMI 2.1 output up to 4K @ 75 Hz with HDR, 3.5mm AV port (composite + stereo audio) Video Codecs – VP9 Profile-2 up to 4K 60fps, 10-bit H.265/HEVC up to […]
