May 5, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

ClusBerry-2M Industrial IoT controller takes two Raspberry Pi Compute Modules 4

Earlier this year, Techbase introduced the ClusBerry 9500-CM4 cluster system for industrial IoT that can take up to eight Raspberry Pi Compute Modules 4 housed in a DIN rail enclosure. But for smaller projects and IoT prototyping, the company has now designed ClusBerry-2M, a smaller cluster device including two independent ModBerry I/O mainboards and two Compute Module 4’s that’s equivalent to two ModBerry 500-CM4, but with support for software cluster management tools such as Docker and K3s Lightweight Kubernetes. The company did not share the full ClusBerry-2M specifications, but we can derive most of the features from the photos, previous products features, and the announcement: SoM – 2x Raspberry Pi Compute Module 4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, 1 to 8GB RAM, up to 32GB eMMC flash. Storage – 2x M.2 slots for NVMe SSDs Video Output – 2x HDMI 2.0 ports Connectivity 4x Gigabit Ethernet […]

April 4, 2021October 27, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

Raspberry Pi CM4 based predictive maintenance gateway features Google Coral Edge AI accelerator

Techbase IModGate-AI predictive maintenance gateway

Techbase had already integrated the Raspberry Pi CM4 module into several industrial products including Modberry 500 CM4 DIN Rail industrial computer, ModBerry AI GATEWAY 9500-CM4 with a Google Edge TPU, and ClusBerry 9500-CM4 that combines several Raspberry Pi CM4 modules into a DIN Rail mountable system. The company has now announced another Raspberry Pi Compute Module 4 gateway – iModGATE-AI – specially designed for failure monitoring and predictive maintenance of IoT installations, which also embeds a Google Coral Edge TPU AI module to accelerate computer vision. iModGATE-AI gateway specifications: SoM – Raspberry Pi Compute Module 4 with up to 32GB eMMC AI accelerator – Google Coral Edge TPU AI module Video Output – HDMI port Connectivity – Gigabit Ethernet USB – USB 2.0 port Sensors – 9-axis motion tracking module with 3-axis gyroscope with Programmable FSR, 3-axis accelerometer with Programmable FSR, 3-axis compass (magnetometer) Expansion 2x 16-pin block terminal Advanced […]

February 4, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

IP67 mini PC targets harsh environments and marine applications

We’ve covered plenty of Whiskey Lake-based mini PC‘s and SBC‘s, but most of them are made for the home or the office, except for some designed with a wider temperature range for industrial and factory environments. But Stealth is going further with WPC-905 IP67 waterproof mini PC that’s completely sealed and fanless making it suitable for harsher environments, including marine applications. The rugged computer comes with a choice of Intel Celeron and Core processors and supports variable DC input from 9V to 48V DC via an M12 connector. Stealth WPC-905 IP67 mini PC specifications: SoC (one or the other) – all from the Whisky Lake Embedded family Intel Celeron 4305UE dual-core processor @ 2GHz with Intel UHD Graphics 610; 15W TDP Intel Core i3-8145UE dual-core/quad-thread processor @ 2.2GHz / 3.9GHz (Turbo) with Intel UHD Graphics 620; 15W TDP Intel Core i5-8365UE quad-core/octa-thread processor @ 1.6GHz / 4.1GHz (Turbo) with Intel […]

January 27, 2021September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Elkhart Lake fanless mini PC’s are made for IIoT applications

Onlogic Karbon 410 Elkhart-Lake fanless rugged mini pc

Intel Atom x6000E Series, Celeron and Pentium Elkhart Lake IoT Edge processors were introduced in September 2020, and we covered several Elkhart Lake modules and SBC’s. We’ve seen fewer full systems such as the Atom x6425RE based Vecow SPC-6000 Elkhart Lake mini PC for embedded & IoT applications. But OnLogic is more offering four more choices with Helix 300 and Karbon K400 Series of rugged fanless mini PCs, all equipped with Atom, Celeron, or Pentium Elkhart Lake processors, and designed for industrial IoT (IIoT) or Industry 4.0 applications Helix 300 Series Specifications The Helix 300 family is comprised of two models with Helix 310 and Helix 330 share most of the same specifications: SoC – Intel Celeron N6211 dual-core processor or Pentium J6425 quad-core processor System Memory – Up to 32 GB DDR4 RAM Storage – M.2 Storage Video Output – 3x DisplayPort for triple independent display setups Audio – […]

December 30, 2020December 30, 2020 by Abhishek Jadhav - No Comments

OAS software now supports Raspberry Pi 4 for Industry 4.0 solutions

A week before the announcement that Raspberry Pi supported industrial customers through several new services, including a dedicated website for the industry and the Raspberry Pi Approved Design Partners program, OAS announced support for deploying the Open Automation Software Platform on Raspberry Pi 4 with 4GB or 8GB of memory. The solution enables the low-cost scaling of operations and “reliable on-site data logging in remote locations with limited power and connectivity”. As you may know… or not, OAS has provided IIoT solutions for the last 20 years and is widely used since the company offers secure moving of data from one location to another. Network Configuration Possibilities The platform offers support for Windows PC/Server, Windows Embedded, Windows IoT, Linux Server, Virtual Machines (Win/Linux), Raspberry Pi 4, and Docker Containers (Win/Linux). “These systems can be networked together and share data creating endless network configuration possibilities”. The OAS platform running on the […]

December 11, 2020December 11, 2020 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Raspberry Pi CM3 “Industrial IoT” baseboard features PoE, 4G LTE modem, and isolated I/Os

The Raspberry Pi Computer Module 4 (CM4) may have been introduced in October, but that does not mean people have stopped all development on Raspberry Pi CM3/CM3+ hardware, and Waveshare has just launched a carrier board for the module with PoE support and a 4G LTE modem namely Simcom SIM7600G-H module with 3G and 2G fallback. The board also offers Ethernet and WiFi connectivity, HDMI and MIPI CSI/DSI video interfaces, multiple USB ports, as well as isolated CAN bus, RS485, RS232, and other I/Os for industrial applications. Compute Module PoE 4G board specifications: Storage – MicroSD card slot for Raspberry Pi CM3 Lite / CM3+ Lite modules Video Output – HDMI 2.0 port, MIPI DSI connector compatible with the official Raspberry Pi display Audio – 3.5mm stereo audio jack, 4-pin speaker connector for 8Ω/5W speaker Camera I/F – 2x independent MIPI CSI ports Connectivity 10/100M Ethernet RJ45 port with PoE […]

November 11, 2020January 7, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

Fanless Tiger Lake UP3 embedded box PC targets industrial IoT, robotics & automation

Last month Vecow introduced SPC-6000 fanless embedded PC powered by an Atom x6425RE Elkhart Lake processor, and considering Tiger Lake UP3 embedded processors were announced at about the same time as Atom x6000E-series family, it should come as no surprise that the Taiwanese company has introduced a more powerful Tiger Lake UP3 model. Vecow SPC-7000/7100 Tiger Lake UP3 embedded box PC is equipped with a choice of Core i3 to i7 processors with 12W to 28W TDP with support for Iris Xe graphics, 2.5GbE, TSN networking that makes it suitable for factory automation, robotics, cellular V2X, smart retail, and any AIoT/Industry 4.0 applications. Vecow SPC-7000/7100 specifications: SoC – Intel Core i7/i5/i3 quad-core Tiger Lake UP3 processor with Intel UHD graphics or Intel Xe Graphics; 12W to 28W configurable TDP System memory – Up to 32GB via 1x DDR4 3200MHz SO-DIMM socket Storage – 1x M.2 Key B 2260 Socket, 1x […]

October 7, 2020January 7, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

Vecow SPC-6000 Fanless Embedded PC is Powered by an Atom x6425RE Elkhart Lake Processor

Since the official launch of the Elkhart Lake processor family last month, we’ve covered a Pico-ITX SBC, a 3.5-inch SBC, and several CoM’s following SMARC, Q7, COM Express, and other system-on-module standards. So far, we had not found any Elkhart Lake mini PCs, but Vecow SPC-6000 fanless embedded PC powered by an Intel Atom x6425RE processor is one of the first such solutions offered from the market, and supports 2.5 Gbps Ethernet with TSN support. Vecow SPC-6000 specifications: SoC – Intel Atom x6425RE quad-core Elkhart Lake processor @ 1.90 GHz with 1.5MB cache, 32EU Intel UHD graphics; 12W TDP System Memory – Up to 32GB DDR4 3200MHz via a single SO-DIMM socket Storage – 1x M.2 Key M Socket (2280, PCIe x2), and 1x SATA III (6Gbps) Video Output DVI-I up to 3840 x 2160 @ 60Hz DisplayPort up to 4096 x 2160 @ 60Hz Audio Realtek ALC892, 5.1 Channel […]
