ifttt News - CNX Software - Embedded Systems News

March 14, 2024March 14, 2024 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

$35 SONOFF POW ring smart power meter (POWCT) safely supports up to 100A

SONOFF POW Ring smart power meter is the first CT clamp-based WiFi power meter from ITEAD. It is designed for installation in an electric cabinet to measure whole-house power consumption with up to 100A current. The power meter relies on an ESP32 microcontroller for control and wireless connectivity with a range of up to 130 meters thanks to an external high-gain antenna. It is supported by the usual eWelink mobile app that also enables integration with Google Home, Amazon Alexa, and IFTTT services, and ITEAD also mentions integration with the Home Assistant open-source framework. SONOFF POW Ring (POWCT) specifications: MCU – ESP32 WiFi and Bluetooth microcontroller Connectivity – 2.4 GHz WiFi 4 (802.11b/g/n) with SMA antenna connector for an external antenna to be placed outside of the electrical cabinet Current transformer (CT) interface type – RJ9 Current transformer detection range – 0 to 100A Measurement category – CAT II 0-100A […]

October 25, 2023October 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

SONOFF SNZB-06P Zigbee human presence sensor is based on a 5.8GHz microwave radar

SONOFF SNZB-06B human presence detection sensor

ITEAD has launched a new Zigbee sensor with the SONOFF SNZB-06P designed to detect human presence using a 5.8GHz microwave radar whose main advantage over a traditional PIR motion sensor is the ability to detect stationary persons since this type of sensor can detect breathing. You’ll need a Zigbee Hub from SONOFF such as the NSPanel Pro or SONOFF iHost, or from other manufacturers, for instance, the Amazon Echo Plus 2nd generation, or simply use a Zigbee USB dongle such as the SONOFF ZBDongle-E connected to a host like a Raspberry Pi. Configuration and control is done through the usual eWelink app for Android or iOS. SONOFF SNZB-06P specifications: MCU – Silicon Labs EFR32MG22 wireless microcontroller Human presence sensor 5.8GHz microwave radar Sensitivity configurable from 2.5 meters to 4 meters Wireless – Zigbee 3.0 (router type) up to 30 meters Misc – Red LED, magnetic base, button Power Supply – […]

June 17, 2022September 5, 2022 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

SONOFF POW Elite ESP32 WiFi power meter switch handles up to 20A load

SONOFF POW Elite is an ESP32-powered smart power meter switch that can handle up to 20A max load to monitor the power consumption of all appliances in a whole room. The data can be visualized in real-time on the built-in LCD or via the eWelink app, up to six-month of hourly power consumption history can be saved, and the system can also be integrated with third-party solutions such as a Home Assistant, IFTTT, and Alexa Energy dashboard. SONOFF POW Elite specifications: WiSoC – Espressif Systems ESP32 dual-core Xtenxa processor @ up to 240 MHz with 2.4 GHz WiFi 4 and Bluetooth 4.2 connectivity Wireless – 2.4GHz 802.11 b/g/n WiFi 4 (Bluetooth does not seem to be used) Power Input/Output POWR316D model – 100-240V~ 50/60Hz 16A Max POWR320D model – 100-240V~50/60Hz 20A Max Dimensions – 98 x 54 x 31mm (DIN Rail mountable) Casing Material – PC V0 (Tested with UL94v-0 […]

August 3, 2019 by Stephen Vicinanza - No Comments

Actcast Combines IFTTT-like Service with AI and Raspberry Pi 3 / Zero

In a report on April 30, 2017, Idein had developed GPGPU accelerated object recognition for the Raspberry Pi platform. That development led to the beta release of the ActCast IoT platform, which was announced on July 29, 2019, and uses deep learning algorithms for object and subject recognition. The program is for use with IoT and AI. The idea is to increase performance and link the system to the web for even more solutions. What it Does The use of physical world information in IoT projects has many applications. Such as a doorbell that sees a person, can then recognize the person. Ultimately letting the user know over the web through a smartphone, the person should be let in. And then the system unlocks the door. So Actcast is a bit like IFTTT with artificial intelligence / computer vision capabilities. Edge Computing Bringing the source of data closer to the […]

March 4, 2018March 4, 2018 by Karl Johnson - 14 Comments

Sonoff S31 Smart Socket Review – Power Consumption Monitoring with eWelink Android App

Today we are looking at the Sonoff S31. It is another device in the Sonoff line by ITEAD Studio. Similar to the Sonoff POW, you can see power usage but on the S31 you can keep historical data up to 100 days. This time around I am using it with the standard firmware, and will not be flashing the popular MQTT Tasmota firmware. Specifications per ITEAD website: Max. Current: 16A Voltage Input: 90~264V AC, 50/60HZ Wireless Standard: 2.4GHz, 802.11 b/g/n Receive Sensitivity: 802.11b: <-84dBm(11Mbps); 802.11g: <-68dBm(54Mbps) Output Power: 802.11b:16±2dBm; 802.11g:13±2dBm Security Mechanism: WEP/WPA-PSK/WPA2-PSK Encryption: AES/TKIP Working Temp: -20 °C ~ 75 °C Working Humidity: 10%-80% Product Dimensions: 75.7×39.7x32mm Gang: 1 Weight: 135g Certification: FCC (Download) Sonoff S31 Unboxing & Teardown Taking the S31 apart is rather easy but I did not take it fully apart for fear of breaking it. Just pop the power button off the left side. Then […]

May 15, 2016April 8, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Getting Started with Wio Link Starter Kit, Visual Programming Android App, and IFTTT

Wio Link is a board based on ESP8266 WiSoC that is supposed to be easy to set up thanks to Grove modules – no breadboard and mesh or wires – and, as I first understood it, to program thanks to a drag-and-drop mobile app that does not require any actual programming. More advanced users can also use a RESTful API in Python, JavaScript, Node.js, PHP, Objective-C or Java. I’ve been sent a $49 Wio Link Starter Kit including the board, a USB cable, and six Grove modules to evaluate the kit. I’ll start by having a look a the kit, before experimenting with the Wio Link Android app. Wio Link Starter Kit Unboxing The kit is sent in a red plastic case. Wio Link board is lodged in the top cover, and other accessories are placed in bags in the main part of the case. Let’s check the board first. […]
