May 16, 2021 by Saumitra Jagdale - 3 Comments

HEGduino V2 supports fNIRS and Blood-Flow Monitoring (Crowdfunding)

AlasKit has launched a crowdfunding campaign on Crowd Supply for HEGduino V2. The device features noninvasive optical imaging through fNIRS (Functional near-infrared spectroscopy), apart from its brain blood flow monitoring functionality. We saw the previous version of the HEGduino in September 2019 which only supported blood flow monitoring. But the HEGduino V2 also monitors breathing, heart rate, and skin temperature. HEGduino V2 has a MAX86141 optical pulse oximeter cum heart-rate sensor for incorporating Heart Rate Variability (HRV) training. It also allows breath and skin temperature monitoring. The sensor has a specification of 2×4096 SPS sensing with a 19-bit resolution which is a bit higher than its previous version. As HEGduino V1 had an 860 SPS sensing with a 16-bit resolution. However, the practical application observes even lesser values for HEGduino V1. Setup of HEGduino V2 The device also comes with an ESP32 breakout board with rechargeable battery support. The board […]

August 31, 2020August 31, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Heart Rate Development Kit Features ESP32 WiSoC, MAX30102 Pulse Oximeter & HR sensor

Arduino ESP32 Heart Rate-Oxygen Level Monitor

LilyGO has launched a fair amount of ESP32 boards with some less common features like Ethernet and OLED Display, cellular connectivity, LoRa & GPS, PoE, watch form factor, and more. Their latest product is somewhat different from their earlier boards with the TTGO Heart rate programming development kit being closer to a reference design since it comes with an enclosure similar to commercial products. The heart rate devkit features ESP32 WiFi and Bluetooth SoC, a small LCD, as well as a Maxim Integrated MAX30102 pulse oximeter and heart-rate sensor. TTGO heart rate development kit specifications: SoC – Espressif Systems ESP32 dual-core Tensilica SoC with WiFi 4 & Bluetooth connectivity Display – 0.96-inch IPS LCD via ST7735 SPI controller Sensors MAX30102 heart rate blood oxygen I2C sensor MPU6050 6-axis accelerometer and gyroscope (I2C) Debugging – Micro USB port via CP2104 USB to TTL bridge Misc -PCF8563 RTC, user button Battery […]

March 26, 2018March 28, 2018 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

WeLoop Hey 3S Sports Smartwatch Review – Part 2: GPS, Running, Cycling, Notifications, and More

As mentioned previously I did not have such good luck with smart wearables so far, with disappointing products often with a short lifetime (a few weeks to a few months, and some design issues here and there like an e-Paper display without backlight, a touchscreen display with poor locking mechanism (so it’s activated while taking a shower), unreliable heart rate monitor, poor waterproofness and so on… My main requirements are always-on display, battery life as long as possible, notification support, good waterproofness to do tasks like taking shower or swim without having to remember to remove the watch, among others less important requirements. I mostly gave up on the category for about year, but decided to give it a try when GeekBuying asked me if I was interested in reviewing WeLoop Hey 3S sports smartwatch. Maybe things have improved since then. I’ve already gone through unboxing and initial setup in […]

December 15, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Mediatek Unveils Sensio MT6381 6-in-1 Biosensor Module for Smartphones

Nearly exactly two years ago, Samsung unveiled S3FBP5A bio-processor for fitness tracking wearables with five analog frontends measuring PPG, ECG,skin temperature, BIA, and GSR data, and that is (or was?) expected in the company’s S-Patch3 health tracker. Mediatek has now come up with something with similar functionalities, but instead of being a standalone bio-processor for wearables, Sensio MT6381 biosensor module is designed as a companion chip for smartphones, and capable for delivering 6 different types of heart and fitness data in about 60 seconds. MediaTek Sensio key features and specifications: Integrated R and IR LEDs for reflective PPG measurement + 1-channel ECG analog front-end Health Data Heart-rate in heart beats per minute Heart-Rate Variability (variation in the time between heartbeats). Blood Pressure Trends Peripheral Oxygen Saturation (SpO2) – amount of oxygen in the blood. Electrocardiography (ECG) – electrical activity of the heart over a period of time Photoplethysmography (PPG) – […]

August 8, 2016 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

TW68 Smart Bracelet Measures Blood Pressure and Heart Rate for $22 and Up

Some people may need to frequently measure their blood pressure because of their health condition, but it’s often a cumbersome experience, so they may get lazy, and not do it as often as needed. TW68 smart bracelet should make this easy, as it’s your typical fitness tracker with an heart rate monitor, but adding the capability to also measure blood pressure. It’s also very cheap, and I first found it on DealExtreme where it sells for just $24. TW68 specifications: MCU – Nordic Semi NRF51822 ARM Cortex M0 micro-controller with 2.4 GHz radio Data Storage – 7 days detailed data, 23 days total data Connectivity – Bluetooth 4.0 LE Display – 0.49″ OLED display Sensors – PixArt-PAH8001EI blood pressure sensor; 6-axis Invensense-MPU6500 accelerometer and gyroscope Function Health tracker: Blood pressure measurement, Heart rate monitor, Pedometer, Sleep tracker Other functions: Call/Message notification, Fall reminder, Social sharing, Time, Alarm clock Misc – […]

June 27, 2016July 5, 2016 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Review of Xiaomi Mi Band 2 Activity Tracker

I’ve been using Xiaomi Mi Band 2 for a little over two weeks now, so I’m not ready to report my findings, and the results are mixed. If you are interesting in checking out the accessories, and physical aspect of the watch, feel free to read Xiaomi Mi Band 2 unboxing post first. Since the new model adds an OLED display, let’s first see what options it has to offer. The display is off by default, and pressing the capacitive touch button (please note that it’s not a real physical button, so it won’t work with most gloves for example) will turn on the display for 5 seconds. You can keep pressing to go through time, step count, distance, calories burnt, heart rate monitor, and battery level. Except for time, there’s a icon shown before display the actual value. If you find that the display does not look clear, that’s […]

June 17, 2016 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Energympro EP-SH09 Fitness Tracker Review

Energympro EP-SH09 is a strapless fitness tracker with an heart rate monitor and Bluetooth 4.0 LE for synchronization with your smartphone, in the first part of the review, I took some picture of the device, and expressed my opinion about the build quality. I’ve now played close to two weeks with the tracker, so I can share my experience with the device. Bear in mind that this was still considered an engineering sample, so the company will likely on some of the issues I encountered before it ships to the general public or resellers. A capacitive touch area just under the display is used to cycle through 7 watch faces: Time, Date, Bluetooth (Icon will change to a chain when connected), step count, distance, calorie count, and heart rate monitor. It works well enough, but there are a couple of point that you may want to be aware. The display […]

June 13, 2016 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Xiaomi Mi Band 2 Fitness Tracker Unboxing

Xiaomi started selling Xiaomi Mi Band 2 fitness tracker with an OLED display last week in China for 149 CNY (~$23), but it can also be purchased overseas with the many online resellers, and one of them, GearBest sent me a sample for review, and sells it for $33.91 with coupon GBMI2 once oversea shipping, currency conversion, and possibly some margins are included. Today, I’ll start by taking some pictures of the devices and its accessories, before writing a review in a couple of weeks after testing the device features and battery life. I received the device in a typical Mi package, and GearBest also included a User service card to encourage people leaving feedback, and helping with returns and issues. That’s the first time I receive this card, so maybe GearBest is trying to improve their customer service. The product is definitely geared towards the Chinese market, as the specifications […]
