April 2, 2017September 5, 2019 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

NanoPi NEO2 Board Benchmarks with Ubuntu 16.04.2 using Linux 3.10 and Linux 4.10

I’ve received NanoPi NEO 2 boards, add-boards and sensor modules last week, where we could see how small the boards were, and how it could be suitable for IoT projects or “hardware hacking” education. Before testing the board with the add-ons, I have to select the image to run on the board, and currently we have two choices: Ubuntu 16.04.2 FriendlyELEC image with Linux 3.10 “legacy” kernel, or Armbian Ubuntu 16.04.2 Xenial nightly build with Linux 4.10 “mainline” kernel. So I decided to try both: dfssf nanopi-neo2-ubuntu-core-qte-sd4g-20170329.img.zip (296 MB) is the image from FriendlyELEC (previously FriendlyARM) Armbian_5.27.170401_Nanopineo2_Ubuntu_xenial_dev_4.10.0.7z (222 Mb) is the image from Armbian, which I downloaded on March 31st despite the filename including “170401” string You can flash the image with Win32DiskImager (Windows) or dd (linux) to a micro SD card the usual way, and while I’ve never personally had troubles with dd, I’ve been told Etcher was better, […]

March 26, 2017September 5, 2019 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

NanoPi NEO2 Board, NanoHats, and BakeBit Starter Kit Review – Part 1: Hardware Overview & Assembly

NanoPi NEO 2 development board is an update of NanoPi NEO with a quad core 64-bit Allwinner H5 processor + 512 MB RAM, Gigabit Ethernet, and an extra audio header, which can be a great little board for headless application since there’s no video output. FriendlyELEC ask me whether I wanted to review to board with some of their NanoHATs add-on boards, and while I asked for NanoHat PCM5102A audio board and NEO Hub which I intended to use with Grove modules from my Wio Link Started Kit, I get a bit more than expected, as the company included sets of NEO 2 boards and accessories, NanoHATs, two serial debug board, and their BakeBit Starter Kit with several Grove modules to play with. Since I have so many things to look at in this first post, I’ll just describe the hardware, assemble it, quickly check the paper documentation, and give […]

March 14, 2017March 14, 2017 by Jean-Luc Aufranc (CNXSoft) - 49 Comments

NanoPi NEO2 Development Board Powered by Allwinner H5 64-bit ARM Processor Sells for $15

NanoPi NEO is a cool little board, and I’ve been using it with Armbian as a 24/7 MQTT + Domoticz server for several weeks without any issues so far. FriendlyElec has now an update with NanoPi NEO2 featuring Allwinner H5 quad core Cortex A53 processor instead of Allwinner H3 Cortex A7 processor, a faster Gigabit Ethernet connection, and a new audio header. NanoPi NEO2 specifications: SoC – Allwinner H5 quad core Cortex A53 processor with an ARM Mali-450MP GPU System Memory – 512 MB DDR3 Storage – micro SD card slot Connectivity – Gigabit Ethernet (via RTL8211E-VB-CG chip) USB – 1x USB 2.0 host ports, 1x micro USB OTG port, 2x USB via headers Expansion headers 24-pin header with I2C, 2x UART, SPI, PWM, and power signals 12-pin header with 2x USB, IR pin, I2S 5-pin audio header with microphone and LINE out signals Debugging – 4-pin header for serial […]

March 1, 2017April 15, 2017 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

FriendlyELEC NanoPi M1 Plus Allwinner H3 Board Adds Gigabit Ethernet, WiFi & Bluetooth, and an 8GB eMMC Flash

FriendlyELEC has introduced an update to NanoPi M1 board, aptly named NanoPi M1 Plus with a similar form factor and Allwinner H3 processor, but adding Gigabit Ethernet, 802.11 b/g/n WiFi & Bluetooth, and an 8GB eMMC flash, at the expense of one USB port that had to go to make place for the new features, and it got a little wider too.NanoPi M1 Plus board specifications: SoC – Allwinner H3 quad core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 1GB DDR3 Storage – 8GB eMMC flash + micro SD card slot Video & Audio Output – HDMI and 3.5mm jack for CVBS (composite + stereo audio) Connectivity – Gigabit Ethernet, 802.11 b/g/n WiFi and Bluetooth 4.0 dual mode (classic + low energy) with chip antenna and IPEX/u.FL connector USB – 2x USB 2.0 host ports, 1x 4-pin USB 2.0 […]

January 20, 2017January 20, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

$30 BakeBit Starter Kit Adds Sensors & Buttons to Your NanoPi NEO & NEO Air Boards

FriendlyElec (previously FriendlyARM) launched NanoPi NEO and then NanoPi NEO Air board as respectively Ethernet and WiFi/Bluetooth connected boards for IoT applications. But so far, there was no ecosystem around the board, you had to use your own sensor modules, and write your own software to control them. This has now changed with the launch a BakeBit Starter Kit with twelve sensor modules, a NanoHat Hub add-on board designed for NanoPi boards, as well as BakeBit Library to control the hardware. The NanoHat Hub plugs into the two NanoPi NEO headers and provide 12 headers with 3x I2C interfaces, 3x analog interfaces, 2x UART interfaces, and 4x digital interfaces among which D3 and D5 support PWM, compatible with SeeedStudio Grove modules. You then have a choice of 12 modules to connect to the NanoHat Hub: OLED Module Ultrasonic Module Green LED Module Red LED Module LED Bar Module Rotary Angle […]

December 23, 2016May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

$25 NanoPi A64 is a Compact Yet Features Packed Allwinner A64 Development Board

FriendlyARM has had a very busy year with their NanoPi boards, and they are completing the year by launching NanoPi A64 development board based on Allwinner A64 quad core Cortex A53 processor with 1GB RAM, Gigabit Ethernet, HDMI, USB ports and more. NanoPi A64 board specifications: SoC – Allwinner A64 quad-core Cortex-A53 @ 648MHz to 1.152GHz with an ARM Mali400 MP2 GPU System Memory – 1GB DDR3 RAM Storage – 1x micro SD slot Video Output / Display IF – HDMI 1.4 port, 30-pin MIPI DSI connector Audio – HDMI, 3.5mm audio jack Connectivity – 1x Gigabit Ethernet port (RTL8211E), 802.11 b/g/n WiFi USB – 2x USB 2.0 ports, 1x micro USB port for power only Camera – 24-pin DVP camera interface Debugging – 4-pin debug UART header Expansion 40-pin mostly Raspberry Pi compatible header with UART, SPI, I2C, PWM, GPIOs, etc… 7-pin I2S header Misc – IR Receiver, 1x […]

October 28, 2016October 31, 2016 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

NanoPi S2 Quad Core ARM Linux Board Comes with WiFi & BT Connectivity, HDMI, LVDS, and LCD Interfaces

FriendlyARM has released a bunch of Allwinner based NanoPi Allwinner boards recently, but they also have some Samsung/Nexcell S5P ARM Cortex A9 boards in their portfolio, and the latest is NanoPi S2 with Samsung S5P4418 quad core processor, three display interfaces, a camera interface, wireless connectivity through WiFi and Bluetooth 4.0, a 40-pin “Raspberry Pi” header, and more. NanoPi S2 specifications: SoC – Samsung/Nexcell S5P4418 quad core Cortex A9 processor @ 400 MHz to 1.4 GHz with Mali-400MP GPU System Memory – 1 GB DDR3 Storage – 8GB eMMC flash + micro SD slot Video Output / Display I/F – micro HDMI port up to 1080p60, 24-pin LCD RGB interface, 24-pin LVDS interface Audio – 3.5mm audio jack, micro HDMI Camera – 24-pin DVP camera interface Connectivity – 802.11 b/g/n WiFi + Bluetooth 4.0 classic & LE (AP6212 module); IPEX/u.FL antenna connector USB – 1x USB 2.0 Host, 1x micro […]

September 28, 2016July 23, 2024 by Jean-Luc Aufranc (CNXSoft) - 33 Comments

FriendlyARM Introduces NanoPi NEO AIR Board with WiFi & BLE, Camera Interface and 8GB Storage for $17.99

FriendlyARM launched NanoPi NEO board with Allwinner H3 processor, Ethernet, and USB ports for $7.99 to $9.99 in July, and the company is back with a new board with the same form factor and processor, by trading Ethernet for WiFi, dropping one USB 2.0 port for a DVP camera interface, and adding an 8GB eMMC flash. NanoPi NEO AIR specifications: SoC – Allwinner H3 quad-core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 512 MB DDR3 Storage – 8GB eMMC Flash (Samsung) + micro SD card slot Connectivity – WiFi 802.11 b/g/n and Bluetooth 4.0 LE (via Ampak AP6212 module) with IPEX antenna connector USB – 1x micro USB OTG port, 2x USB via headers Camera – 1x DVP camera interface with optional 5MP CAM500B camera Expansion headers 24-pin header with I2C, 2x UART, SPI, PWM, and power signals 12-pin header […]
