July 25, 2019July 26, 2019 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Espressif Systems Gets Listed on the Shanghai Stock Market

Espressif Systems is widely popular community thanks to their low-cost ESP8266 and ESP32 WiFi & Bluetooth SoC, modules, and development kit as well as their extensive software ecosystem, and community support. If you wonder how they did outside of the maker sphere, you don’t need to worry, as the company founded in 2008 is already profitable ($23 US million profit in 2018), and even launched an IPO on the new STAR market for science and technology sectors on the Shanghai stock market that was completed on July 9 and oversubscribed around 2,880 times. A bank source informed me the IPO was only available to local Chinese people, and the IPO price was set to 62.60 CNY ($9.1). Listing started this Monday (July 22, 2019), and the stock has done extremely well with the price having reached 161.54 CNY at the time of writing. For reference, the stock code is 688018, […]

May 21, 2019May 21, 2019 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

Espressif ESP32-S2 Secure WiFi MCU Comes with an Xtensa LX7 Core @ 240 MHz

Espressif Systems has unveiled a new ESP32 WiFi MCU based on Cadence (previously Tensilica) Xtensa LX7 core instead of the usual Xtensa LX6 core(s). ESP32-S2 is powered by a single Xtensa LX7 core clocked at 240 MHz, supports Wi-Fi HT40 @ 2.4 GHz, and provides up to 43 GPIOs. Espressif ESP32-S2 specifications: CPU – Cadence Xtensa single-core 32-bit LX7 microcontroller @ up to 240 MHz, and ultra-low-power co-processor System Memory – 320 kB SRAM, external SPIRAM support up to 128 MB in total, 16 KB RTC memory Storage – 128 kB ROM, up to 1 GB of external flash support Connectivity Wi-Fi 802.11 b/g/n 1×1 transmit and receive with HT40 support with data rate up to 150 Mbps Support for TCP/IP networking, ESP-MESH networking, TLS 1.0, 1.1 and 1.2 and other networking protocols over Wi-Fi Support Time-of-Flight (TOF) measurements with normal Wi-Fi packets I/O & peripherals 43x programmable GPIOs 14x […]

March 24, 2019 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

ESP-WROOM-5C is a Side-Mounted ESP8285 WiFi Module

You’d think by now we’d have enough ESP8266 or ESP8285 WiFi modules, but based on an FCC listing, we now know that Espressif Systems has been working on another ESP8285 WiFi module – ESP-WROOM-5C – designed to be side-mounted. ESP-WROOM-5C specifications: SoC – Espressif Systems ESP8285 Wi-Fi 802.11 b/g/n WiFi 4 @ 2412 MHz ~2462 MHz; Station/SoftAP/SoftAP + Station modes WPA/WPA2 security with EP/TKIP/AES encryption PCB antenna Peripheral interface I2C/IR Remote Control GPIO/PWM Operating voltage – 2.7V ~ 3.6V Operating current – Average: 80 mA Minimum current delivered by power supply – 500 mA Dimensions – 19 x 16 x 3.2 mm Temperature Range – -40°C ~ 105°C Reliability Tests – HTOL/HTSL/uHAST/TCT/ESD The module supports firmware upgrade over UART or OTA (Over-The-Air). Software development can be done with the IDF SDK for custom firmware, but “Cloud Server development” is also possible, and an Android/iOS app can be provided for user […]

March 20, 2019 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Espressif “Chip 7” WiSoC May Support 5GHz WiFi

Espressif Systems has not released any new chips since the launch of ESP32 WiFi & Bluetooth SoC in 2016. But it looks like an new chip may be right around the corner, as John Lee from Espressif Systems teased us with a photo featuring a module equipped with “Chip 7” that should be released “soonish”. We really don’t know much about the chip except it comes in a 56-pin QFN package (4x 14 pins), and it won’t most likely be named Chip 7 once it is released. One Twitter user left a comment mentioning that it “looks like a bodged RF Filter. 5GHz mod?”. This reminded me of the potential ESP32-D0CD / ESP32-D2CD processors with dual band (2.4 + 5 GHz) WiFi. When I say “potential” it simply refer to the fact that ESP32 nomenclature has a “CD” connectivity option for WiFi ac/c/b/g/n and Bluetooth dual mode. But Espressif never […]

July 5, 2018 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

ESP32-SOLO-1 is a Single Core ESP32 WiFi and Bluetooth Module

Espressif ESP32 is popular dual core processor with built-in WiFi and Bluetooth connectivity, except as we’ve seen last year, the company also developed a single core version with ESP32-S0WD chip, whose price is only slightly more expensive than ESP8266. But so far, I had not seen many hardware platforms announced with the single core version, with the exception of Particle Argon board. But I believe we should soon see more ESP32-S0WD boards brought to market, since Espressif Systems has now announced ESP32-SOLO-1 single core module. ESP32-SOLO-1 wireless module specifications: SoC – Espressif ESP32-S0WD single core Tensilica Xtensa LX6 processor @ up to 160 MHz with 448 KB ROM, 520KB on-chip SRAM, and 16KB SRAM in RTC Storage – 4MB SPI flash Connectivity 2.4 GHz 802.11 b/g/n WiFi up to 150 Mbps Bluetooth 4.2 LE + EDR I/Os – SD card, UART, SPI, SDIO, I2C, LED PWM, motor PWM, I2S, IR, […]

April 12, 2018April 13, 2018 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

ESP32-LyraT Speech Recognition Board Sold for 22 Euros

Just last week, we wrote about Espressif ESP-ADF Audio development framework that can be used to develop smart speakers and other audio applications with ESP32 boards. There was only one board with documentation at the time however: ESP32-Lyra-T. One tiny problem: it was not for sale just yet, but today Olimex has announced the board is in stock, selling it for 22 Euros. Main features: Wireless module – ESP32-WROVER module with WiFi and Bluetooth LE Audio Many audio inputs – Wi-Fi, BT-audio, DLNA, 3.5mm audio Line-in 3.5mm headphone jack 2x microphones Speaker connectors Storage – micro SD slot Debugging – JTGA header, USB UART Misc – Touch sense buttons, function/boot/reset keys, DIP switch for configuration Power – 5V via micro USB port; battery header + charger chip You’ll find documentation on Espressif website (user guide) as well as on Github’s ESP-ADF (getting started guide). Jean-Luc Aufranc (CNXSoft)Jean-Luc started CNX Software in […]

April 7, 2018 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Espressif ESP-ADF Audio Development Framework for ESP32 Supports Baidu DuerOS, and Soon Amazon Alexa, Google Assistant, etc…

Espressif Systems have been working on audio applications like Smart Speakers based on ESP32 WiSoC with hardware development kits like ESP32-LyraTD-MSC Audio Mic HDK, and I could test it with Baidu DuerOS using Mandarin language. However, at the time (February 2018), there was not much else that could be done with the hardware kit, since no corresponding ESP32 audio software development kit had been made available. This has now changes since Espressif has just released ESP-ADF Audio Development Framework on Github. The framework will support the development of audio applications for the Espressif Systems ESP32 chip such as: Music player or recorder handling MP3, AAC, WAV, OGG, AMR, SPEEX … audio formats Play music from network (HTTP), storage (SD card), Bluetooth A2DP/HFP Integration with Media services such as DLNA, Wechat, etc.. Internet Radio Voice recognition and integration with voice services such as Alexa, DuerOS, Google Assistant As we can see […]

March 14, 2018 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

ESP32-WROOM-32D / ESP32-WROOM-32U WiFi & Bluetooth Modules Deliver Better RF Performance

ESP-WROOM-32 is likely the most popular ESP32 WiFi + Bluetooth module on the market, but a few months ago, Espressif Systems unveiled two variants named ESP32-WROOM-32D / ESP32-WROOM-32U, which are based on ESP32-D0WD (5x5mm package) instead of ESP32-D0WDQ6 (6x6mm package), and are said to offer better RF performance ESP32-WROOM-32D is the most similar to ESP-WROOM-32 since it also comes with a PCB antenna, while ESP32-WROOM-32U is much smaller as it relies on an external WiFi/Bluetooth antenna via a u.FL connector. Both new modules are pin-to-pin compatible with ESP-WROOM-32 Key features: CPU – Espressif ESP32-D0WD dual core Tensilica processor Storage – 32Mbit SPI flash Crystal – 40 MHz Connectivity – Wi-Fi 802.11 b/g/n up to 150 Mbps, Bluetooth 4.2 LE I/Os – 38- catellagated pin with I/Os + GND plane Antenna ESP32-WROOM-32D – on-board antenna ESP32-WROOM-32U – u.FL connector for external IPEX antenna Dimensions ESP32-WROOM-32D – 18 x 25.5 x 3.1 […]
