November 3, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Axiomtek iNA200 DIN-Rail cybersecurity gateway offers 6x Ethernet ports up to 2.5GbE

Axiomtek iNA200 is a DIN-rail mountable cybersecurity gateway powered by a choice of Elkhart Lake Atom x6000E-series processor and designed for operational technology (OT) network security. The fanless gateway comes with up to 32GB RAM, supports SATA storage, offers 2.5GbE & Gigabit Ethernet (RJ45/SFP) networking, and as it is designed for industrial settings, can take input from two 9V to 36V power sources and operate in the -40°C to 70°C temperature range. Axiomtek iNA200 specifications: SoC – Intel Atom x6212RE/x6414RE dua-core or quad-core Elkhart Lake processor with 16 EU Intel UHD Graphics; TDP: x6212RE: 6W, x6414RE: 9W System Memory – Up to 32GB DDR4-3200 SO-DIMM Storage – Support for 2.5-inch SATA III SSD, optional eMMC flash Video Output – HDMI Networking 2x Gigabit Ethernet RJ45 ports via Marvell 88E1512 controller with LAN Bypass 2x 2.5GbE RJ45 ports via Intel I225-IT controller with LAN Bypass and TSN function 2x Gigabit Ethernet […]

September 2, 2022September 2, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

AAEON launches UP Xtreme i11 & UP Squared 6000 robotic development kits

AAEON’s UP Bridge the Gap community has partnered with Intel to release two robotic development kits based on either UP Xtreme i11 or UP Squared 6000 single board computers in order to simplify robotics evaluation and development. Both robotic development kits come with a four-wheeled robot prototype that can move omnidirectionally, sense and map its environment, avoid obstacles, and detect people and objects. Since those capabilities are already implemented, users can save time and money working on further customization for specific use cases. Key features and specifications: SBC UP Squared 6000 SBC – Recommended for power efficiency and extended battery power SoC – Intel Atom x6425RE Elkhart Lake processor clocked up to 1.90 GHz with Intel UHD Graphics System Memory – 8GB LPDDR4 Storage – 64GB eMMC flash, SATA port UP Xtreme i11 SBC – Recommended for higher performance SoC Intel Core i7-1185GRE clocked at up to 4.40 GHz and […]

August 25, 2022 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

UP Squared 2 is a compact Elkhart Lake SBC with Celeron N6210 or Pentium J6426 processor

UP Squared 2 is a compact single board computer powered by either an Intel Celeron N6210 or Pentium J6426 “Elkhart Lake” processor with up to 16GB RAM, 64GB eMMC flash, 4K capable HDMI and DisplayPort video outputs, two Gigabit Ethernet ports, and more. Slightly smaller than two business cards, the UP Squared 2 is an upgrade of the UP Squared SBC introduced in 2016 with Intel Celeron N3350 or Pentium N4200 “Apollo Lake” processor. The new board offers virtually the same features, except the two HDMI ports, have been replaced by one HDMI port, and one DisplayPort connector, the mini PCIe slot is gone in favor of an M.2 NVMe socket, the Altera FPGA has been removed, and the new system provides overall better specifications in terms of CPU/GPU performance. UP Squared V2 specifications: Elkhart Lake SoC (one or the other) Intel Celeron N6210 dual-core processor up to 2.6 GHz […]

August 15, 2022November 15, 2022 by Jean-Luc Aufranc (CNXSoft) - 19 Comments

Thin Mini-ITX networking board features six 2.5GbE ports, Celeron J6412 Elkhart Lake SoC

Thin Mini-ITX networking board with 6x 2.5GbE

Powered by an Intel Celeron J6412 quad-core Elkhart Lake processor, the Jetway MI05-0XK thin mini-ITX networking board is equipped with six 2.5GbE ports, up to 16GB RAM via a single SO-DIMM socket, as well as M.2 sockets for storage, WiFi and/or cellular connectivity, some serial ports, and an optional HDMI port for video output. Four variants are offered: the standard MI05-00K model without eMMC flash nor TPM, the MI05-02K with a TPM 2.0 chip, the MI05-03K with a 32GB eMMC flash, and finally the MI05-07K with both the TPM 2.0 security chip and 32GB eMMC flash. Jetway MI05-0XK specifications: SoC – Intel Celeron J6412 quad-core Elkhart Lake processor @ 2.0 GHz / 2.6GHz (Burst frequency) with 1.5MB cache, 16 EU Intel UHD Graphics; 10W TDP System Memory – Up to 16GB DDR4-3200 via SO-DIMM socket Storage 1x SATA III (6 Gb/s) port 1x M.2 M-key 2242 SATA/PCIe Gen.3 x2 interface […]

July 27, 2022July 27, 2022 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

ZOTAC ZBOX PI336 PICO mini PC gets an Elkhart Lake upgrade with Intel Celeron N6211

The last time we wrote about the ZOTAC ZBOX PICO PI336 mini PC it featured an Intel Celeron N4100 Gemini Lake processor, but the company appears to have launched an upgrade with an Intel Celeron N6211 Elkhart Lake processor instead. The new ZBOX PI336 PICO fanless mini PC also gets more storage up to 128GB eMMC flash, but the rest of the specifications remain pretty much the same with 4GB RAM, HDMI & DisplayPort video outputs, three USB ports, Gigabit Ethernet, WiFI, and Bluetooth, although some of the interfaces got a version bump for additional performance. ZOTAC PI336 specifications: SoC – Intel Celeron N6211 dual-core Elkhart Lake processor up to 1.2/3.0 GHz with 16EU Intel UHD Graphics @ up to 750 MHz; 6.5W TDP System Memory – 4GB LPDDR4x 3200MT/s Storage – 128GB eMMC flash, microSD card socket Display HDMI 2.0 up to 3840×2160 @ 60Hz DisplayPort 1.4 up to […]

April 23, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Intel releases SDK for Cortex-M7 PSE found in Elkhart Lake processors

Elkhart Lake processors integrate the Intel Programmable Services Engine (Intel PSE) offload engine for IoT workloads powered by an Arm Cortex-M7 microcontroller that handles real-time IO control using GPIO, I2C, and/or UART interfaces, and supports functions such as remote, out-of-band device management, network proxy, embedded controller, and sensor hub. Until now the firmware was only provided as a closed-source binary, and Coreboot developers published an open letter to open the source code for the PSE firmware last December, and it’s been successful with Intel releasing the Intel PSE SDK based on Zephyr OS. The SDK combines open-source components (code samples, services, etc…) released under a permissive Apache 2.0 license (“License A”), and closed-source libraries and tools released under an Intel license (“License B”) allowing the redistribution and use in binary form, without modification. You’ll find everything on Github including documentation explaining how to get started with the Zephyr SDK, the […]

March 28, 2022September 30, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

INNOTECH AX-1020 Atom x6000E Elkhart Lake SBC targets fanless equipment

Japan-based INNOTECH has announced the AX-1020 SBC based on Intel Atom x6000E Elkhart Lake processor designed for fanless industrial equipment, medical equipment, surveillance/security, and transportation applications. The board supports up to 16GB of RAM, SATA & NVMe storage, and is equipped with three display interfaces, two Gigabit Ethernet ports, six USB3.0/2.0 interfaces, one RS-485/422, and four RS-232C serial interfaces. INNOTECH AX-1020 specifications: Choice of Atom x6000E Elkhart Lake SoC Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.0 GHz with 32 EU UHD graphics; 12W TDP Intel Atom x6413E quad-core processor @ 1.50 GHz / 3.0 GHz with 16 EU UHD graphics; 9W TDP Intel Atom x6211E dual-core processor @ 1.30 GHz / 3.0 GHz with 16 EU UHD graphics; 6W TDP System Memory – 4GB to 16GB DDR4 SO-DIMM (The company tells customers to contact them first when using 8GB or 16GB RAM) Storage – 1x SATA port, […]

March 2, 2022March 2, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

3.5-inch Elkhart Lake SBC offers dual GbE, 4x M.2 sockets, 5G cellular support

AAEON GENE-EHL5 Elkhart Lake 3.5-inch SBC

AAEON GENE-EHL5 is a 3.5-inch Subcompact board based on Intel Atom x6000E Series, Pentium, and Celeron “Elkhart Lake” processors with four M.2 expansion slots for wireless connectivity (5G, WiFi, etc…) and NVMe modules, as well as two Gigabit Ethernet ports. The single board computer comes with one DDR4 SODIMM slot for up to 32GB IBECC memory, supports SATA and NVME storage, offers DisplayPort and HDMI, and eDP/LVDS video interface, as well as wide DC input from 9-36V, although there’s also a cost-down option for 12V DC input only. AAEON GENE-EHL5 specifications: Elkhart Lake SoC (one or the other) with Intel UHD graphics Intel Atom x6425RE quad-core processor @ 1.90 GHz; 12W TDP Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.00 GHz (Turbo); 12W TDP Intel Atom x6211E dual-core processor @ 1.30 GHz / 3.00 GHz; 6W TDP Intel Pentium J6426 quad-core processor @ 2.00 GHz / 3.00 GHz; […]
