Posted on by Debashis Das - No Comments on DFI RPS101/RPS103 mini-ITX motherboards support 12th-14th Gen Intel processors, quad 4K displays, dual 2.5GbE

DFI RPS101/RPS103 mini-ITX motherboards support 12th-14th Gen Intel processors, quad 4K displays, dual 2.5GbE

DFI RPS101 or RPS103 Mini-ITX motherboard with up to 14th Gen Raptor Lake-S Refresh processor.

DFI has recently launched the RPS101/RPS103 industrial mini-ITX motherboards compatible with 14th/13th/12th Gen Intel Core processors and equipped with R680E, Q670E, or H610E chipset. They also support up to 64GB of DDR5 memory and offer various connectivity and management features including support for up to four independent 4K displays, two Intel 2.5GbE ports, and an integrated DFI M2-OOB module. These features are designed to meet the demands of factory automation and kiosk applications, and the company claims its latest mini-ITX motherboards are ideal for businesses that need to reduce TCO and accelerate AI adoption. RPS101/RPS103 mini-ITX motherboards’ specifications CPU options LGA 1700 Socket  (one or the other) 14th Gen Raptor Lake-S Refresh  – Intel 300T dual-core to Intel Core i9-14900 24-core 13th Gen Raptor Lake-S – Intel G6900TE dual-core to Intel Core i9-13900 24-core 12th Gen Alder Lake-S – Intel G6900TE dual-core to Intel Core i9-12900 16-core Graphics Intel HD […]

Posted on by Debashis Das - 1 Comment on DFI RPP051 Pico-ITX SBC features 13th Gen Intel Core embedded SoC from Processor U300E to Intel Core i7-1365UE

DFI RPP051 Pico-ITX SBC features 13th Gen Intel Core embedded SoC from Processor U300E to Intel Core i7-1365UE

DFI RPP051 Pico ITX SBC

DFI RPP051 is a 2.5-inch Pico-ITX SBC built around 13th Gen Intel Core processors ranging from the dual-core Intel Processor U300E to the 10-core Intel Core i7-1365UE. It supports up to 32GB DDR5 SO-DIMM memory and accommodates M.2 NVMe and SATA storage devices. Connectivity options include a 2.5GbE LAN port, DP++ and eDP display interfaces, USB 3.2 Gen 2 and USB 2.0 ports, RS-232/422/485 interfaces, along with I2C and GPIO for expansion. The DFI RPP051 first came to our attention while covering the AAEON PICO-RAP4 which is also an SBC with a Pico-ITX form factor, we have also written about many x86 and Arm Pico-ITX boards including AAEON PICO-MTU4, the AAEON RICO-3568, the GIGAIPC PICO-N97A and many other feel free to check them out if you are looking for compact and powerful SBCs. DFI RPP051 Pico-ITX SBC Specification 13th gen Raptor Lake SoC (one or the other) Intel Core i7-1365UE 10C/12T […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on DFI ASL9A2 COM Express Mini Type 10 module features Intel Atom x7000RE Amston Lake processor

DFI ASL9A2 COM Express Mini Type 10 module features Intel Atom x7000RE Amston Lake processor

DFI ASL9A2 COM Express Mini Type 10 Amston Lake module

DFI ASL9A2 is a COM Express Mini Type 10 module based on Intel Atom x7000RE Amston Lake processors which are pin-to-pin compatible with the Alder Lake-N Series processors and designed for the embedded market with a wider operating temperature range. The credit card-sized COM Express Mini module supports up to 16GB LPDDR5 memory, up to 128GB an eMMC flash, and exposes various interfaces such as 2.5GbE, PCIe Gen3, SATA 3.0, DDI and eDP/LVDS for dual display support, ten USB 3.2/2.0, and more. DFI ASL9A2 specifications: SoC (one or the other) Amston Lake Intel Atom x7211RE dual-core processor @ 1.0 to 3.2 GHz with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor @ 2.0 to 3.4 GHz with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE quad-core processor @ 1.5 to 3.4 GHz with 6MB cache, 32EU Intel UHD graphics; 9W TDP Intel […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on DFI X6-MTH-ORN fanless Edge AI Box computer combines 14th Gen Intel Core Ultra SoC with NVIDIA Jetson Orin AI module

DFI X6-MTH-ORN fanless Edge AI Box computer combines 14th Gen Intel Core Ultra SoC with NVIDIA Jetson Orin AI module

DFI X6-MTH-ORN Edge AI Box computer

DFI X6-MTH-ORN is a fanless Edge AI Box Computer that combines an NVIDIA Jetson Orin NX/Nano AI module with a 14th Gen Intel Core Ultra “Meteor Lake-U” 15W processor for AI-driven applications leveraging GPU computing, machine learning, and image processing. It’s a fully modular computer with an Intel COM Express Type 6 or Type 10 module, an NVIDIA Jetson Orin module, and five M.2 sockets for expansion. The fanless embedded system takes up to 64GB DDR5 RAM, supports M.2 NVMe and 2.5-inch SATA storage, offers seven video outputs (3x HDMI, 3x DP+, VGA), and six Gigabit Ethernet ports. The X6-MTH-ORN is designed for industrial applications and environments with serial interfaces, wide 9V-36V DC input, and an extended -20°C to 60°C temperature range. DFI X6-MTH-ORN specifications: Meteor Lake-U SoC (one of the other) Intel Core Ultra 7 165U 12-core (2P+8E+2LPE) processor @ 1.7 / 4.9  GHz with 12MB cache, Intel 4Xe […]

Posted on by Debashis Das - No Comments on Industrial MicroATX motherboards support Intel Core 12th-14th Gen processors with up to four 2.5GbE/10GbE ports

Industrial MicroATX motherboards support Intel Core 12th-14th Gen processors with up to four 2.5GbE/10GbE ports

DFI industrial microATX motherboard

DFI has recently unveiled two new Industrial MicroATX Motherboards, the RPS310 and ADS310, that claim to have support for Core 12th Gen (Alder Lake-S), 13th Gen (Raptor Lake-S), and 14th Gen (Raptor Lake-S Refresh) processors. The motherboards can be built around R680E or Q670E chipset and support a range of peripherals including VGA, DP++, HDMI, PCIe, M.2 M key, SATA3.0, and much more. The key difference between the two is that the RPS310 supports DDR5 memory, features 4x Intel 2.5GbE network connections, and has a 10-year CPU lifecycle with optional 5-year extended support. In contrast, the ADS310 supports DDR4 memory, features 2x Intel 10GbE + 2x Intel 2.5GbE network connections, and boasts a longer 15-year CPU lifecycle support. We’ve previously covered motherboards with a similar form factor, including the HiFive Pro P550 and Milk-V Pioneer, both powered by RISC-V CPUs. If you’re interested in alternative architectures, you might also enjoy […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on DFI MTH968 Intel Core Ultra “Meteor Lake” COM Express module to power industrial AI PCs

DFI MTH968 Intel Core Ultra “Meteor Lake” COM Express module to power industrial AI PCs

Intel Core Ultra Meteor Lake COM Express

DFI MTH968 is a COM Express Compact Type 6 computer-on-module equipped with an Intel Core Ultra Meteor Lake processor designed for industrial AI PCs thanks to the integrated Neural Processor Unit (Intel AI Boost) and designed for industrial automation, smart transportation, and smart agriculture. It’s not quite the first COM Express module based on the new Core Ultra Meteor Lake SoCs, as we previously covered the ADLINK cExpress-MTL and conga-TC700 with a similar range of features, and the MTH968 provides another alternative with the company highlighting a fanless wide temperature design operating from -40°C to 85°C, DDR5 memory, and NVMe SSD storage (soldered on module). DFI MTH968 specifications: Meteor Lake U/H-series SoC (one or the other) Intel Core Ultra 7 165H 16-core (6P+8E+2LPE) processor @ 0.9 / 1.4 / 5.0 GHz (Turbo) with 24MB cache, 8x Xe-cores Intel Arc graphics @ 2.3 GHz, Intel AI Boost NPU; TDP: 28W Intel […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on DFI PCSF51 – An 1.8-inch industrial SBC with AMD Ryzen R2000 processor

DFI PCSF51 – An 1.8-inch industrial SBC with AMD Ryzen R2000 processor

1.8-inch SBC AMD Ryzen Embedded R2000

DFI PCSF51 is a 1.8-inch single board computer (SBC) powered by an AMD Ryzen Embedded R2000 processor with up to 8GB DDR4 memory and 128GB eMMC flash designed for space-constraints industrial applications, robotics, edge computing, AI vision systems, and more. The business card-sized board comes with HDMI 1.4 video output, Gigabit Ethernet networking, two USB 3.2 Gen 1 ports, and an M.2 Key-E socket for wireless expansion, as well as eight digital I/Os. Other features include a watchdog and an RTC, and the SBC takes 12V DC input on a 2-pin terminal block.   DFI PCSF51 specifications: AMD Ryzen Embedded R2000 SoC (one or the other) AMD Ryzen Embedded R2514 quad-core processor  @ 2.1/3.7 GHz (Turbo) with 2MB Cache, 8 CU AMD Vega GPU; 12W TDP AMD Ryzen Embedded R2314, quad-core processor  @ 2.1/3.5 GHz (Turbo) with 2MB Cache, 6 CU AMD Vega GPU; 12W TDP AMD Ryzen Embedded R2312 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on AMD unveils Ryzen Embedded R2000 Series processors with up to four cores, quad-display support

AMD unveils Ryzen Embedded R2000 Series processors with up to four cores, quad-display support

AMD Ryzen Embedded R2000

As expected, AMD has now launched the Ryzen Embedded R2000 series processors that build up on the earlier Ryzen Embedded R1000 family, but doubles the number of cores to up to four, gets improved Radeon graphics, and adds support for Windows 11 operating system. Performance and efficiency have also improved with the new Ryzen Embedded R2514 CPU exhibiting up to 81 percent higher CPU (Passmark v10) and graphics (3DMark) performance compared to Ryzen Embedded R1606G processor, as well as higher performance-per-watt efficiency thanks to the Zen+ core architecture. The company has four Ryzen Embedded R2000 processors in its portfolio at launch. Key features and specifications include: Memory – 2,400 to 3,200 MT/s (depending on SKU) DDR4 dual-channel memory support Storage – 2x SATA 3.0, NVMe support 16 lanes of PCIe Gen3, except for R2312 limited to just 8 lanes Up to four independent 4Kp60 displays using DisplayPort 1.4, HDMI 2.0b, […]
