cpu

Posted on by Jean-Luc Aufranc (CNXSoft) - 27 Comments on What is PVTM? Or why your Rockchip RK3588 CPU may not reach 2.4 GHz

What is PVTM? Or why your Rockchip RK3588 CPU may not reach 2.4 GHz

Rockchip PVTM

While the Rockchip RK3588 processor is advertised as reaching 2.4 GHz, not all RK3588 chips may achieve this frequency. The keyword is PVTM (Process-Voltage-Temperature Monitor), and we’ll try to explain why it does, and why some of the RK3588 processors may only be clocked at about 2.3 GHz, while others will run fine at 2.4 GHz. This all started with Rock 5B SBC debug party, where we noticed our boards did not reach the same frequency. Willy Tarreau noted the “pvtm” value was different between our boards: Willy’s board: (Cortex-A76 cluster 1 @ 2,304 MHz, cluster 2 @ 2,352 MHz)

CNXSoft board (Cortex-A76 cluster 1 @ 2,304 MHz, cluster 2 @ 2,304 MHz) :

Thomas Kaiser (tkaiser) board: (Cortex-A76 cluster 1 @ 2,400 MHz, cluster 2 @ 2,400 MHz)

For reference, CPU 0 to 3 are Cortex-A55 cores, CPU 4-5 are two Cortex-A76 cores (cluster 1), and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 36 Comments on Arm unveils Cortex-X3 and Cortex-A715 Armv9 cores, improves Cortex-A510 efficiency

Arm unveils Cortex-X3 and Cortex-A715 Armv9 cores, improves Cortex-A510 efficiency

Arm Cortex-A510 Cortex-A715 Cortex-X3

Besides announcing the new Immortalis-G715, Mali-G715, and Mali-G615 GPUs, Arm has also introduced the second-generation of Armv9 cores with the Cortex-A715 and Cortex-X3 cores with respectively a 20% energy-efficiency improvement (and smaller 5% performance uplift) over the Cortex-A710 core and a 25% peak performance boost against the Cortex-X2 flagship core. The announcement also includes a “refresh” of the Cortex-A510 core announced last year with a 5% improvement in efficiency and the same level of performance. The Cortex-X3 will also be used in (Windows 11) laptop processors with the single-thread performance improved by up to 34% in that case. Armv9 mobile SoC (Total Compute) in 2023 Future Armv9 flagship mobile SoC worked on this year, and released in 2023 should have a combination of Cortex-X3, Cortex-A715, and Cortex-A510 cores, an Immortalis-G715 GPU, a new DSU-110 “DynamIQ Shared Unit” that supports 50% more cores in CPU clusters (or up to 12 cores […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 60 Comments on Rockchip RK3588 datasheet available, SBC’s coming soon

Rockchip RK3588 datasheet available, SBC’s coming soon

RK3588 Block Diagram

We had most Rockchip RK3588 specifications so far for the long-awaited Cortex-A76/Cortex-A55 processor, but at today’s Rockchip Developer Conference 2021, more information surfaces with impressive CPU and GPU benchmarks, and the Rockchip RK3588 datasheet has just dropped from the sky directly into my laptop, as such document usually does. At least two single board computers are expected to soon follow from Radxa and Pine64. Rockchip RK3588 datasheet Since we have the datasheet, we can confirm some of the specifications of RK3588, and get additional details: CPU – 4x Cortex-A76 @ up to 2.4/2.6 GHz and 4x Cortex-A55 cores @ 1.8 GHz in dynamIQ configuration GPU Arm Mali-G610 MP4 “Odin” GPU with support for OpenGLES 1.1, 2.0, and 3.2, OpenCL up to 2.2 and Vulkan1.2 2D graphics engine up to 8192×8192 source, 4096×4096 destination AI Accelerator – 6 TOPS NPU 3.0 (Neural Processing Unit) VPU Video decoding 8Kp60 H.265, VP9, AVS2, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 71 Comments on Rockchip RK3588 benchmarks – Geekbench4, GFXBench, Antutu

Rockchip RK3588 benchmarks – Geekbench4, GFXBench, Antutu

RK3588 benchmarks

We’ve been talking about the Rockchip RK3588 Cortex-A76/A55 processor since it showed up in a roadmap in the Spring of 2019, and the initial plan was for a release in Q1 2020. But as most regular readers know, there have been delays after delays, and some people have even started to associate RK3588 with vaporware. But there may be light out of the tunnel with Rockchip RK3588 platform being showcased at the Rockchip Developer Conference 2021, notably with CPU and GPU benchmarks for the device. The results for Geekbench 4 reveal around 2.7 times (single core) or 3.4 times (multi-core) higher CPU speed, but the most impressive part is the GPU as GFXBench shows Rockchip RK3588 being multiple times faster than RK3399, in some cases over 10 times faster. A few weeks ago, we noted some Geekbench 4 results with a system running Android 12 with 8GB of RAM, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 40 Comments on Amlogic A311D2 octa-core Arm processor supports up to 16GB RAM

Amlogic A311D2 octa-core Arm processor supports up to 16GB RAM

Amlogic A311D2 Block Diagram

Amlogic A311D2 octa-core processor is the successor to Amlogic A311D hexa-core SoC with four Cortex-A73 cores, four Cortex-A53 cores, a more powerful Mali-G52 MP8 (8EE) GPU, support for eDP and LVDS video interface, 8Kp24 AV1 video decoding, and support for a whopping 16GB LPDDR4/X memory. But it’s not all! The chip also includes supports for three HDMI 2.1 inputs up to 4Kp60, a 16MP ISP, 4K video encoding, and the more powerful GPU and higher memory bandwidth enable 4K user interfaces which were not feasible on most other Arm hardware barring the NVIDIA Shield. Comparison of Amlogic A311D2 and A311D specifications. * Amlogic A311D multiplexed PCIe and USB 3.0  interfaces means two configurations are possible: 1x USB 2.0 Host + 1 PCIe, OR 1x USB3.0 (No PCIe), but Amlogic A311D2 PCIe and USB 3.0 interfaces are independent, so we are not losing USB 3.0 when using PCIe (5 Gbps). The […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Imagination Technologies to design RISC-V cores

Imagination Technologies to design RISC-V cores

Imagination RISC-V

Now better known for its PowerVR embedded GPUs, Imagination Technologies tried to enter the CPU market by purchasing MIPS Technologies and introducing microAptiv, interAptiv, and proAptiv cores in 2012. It did not end up well, as the company had to sell its MIPS technology a few years later, and the MIPS architecture is now barely supported. But Imagination is now working on getting back into the CPU space by designing RISC-V cores. At least that’s what the company revealed in a press release also announcing overall revenues increased by 55% to $76m in H1 2021, with $70m in cash, and no external third-party debt. This year Imagination is re-entering the CPU market with designs based around the RISC-V open ISA. Imagination’s heritage in CPU enables it to provide innovative and patent protected technologies for the discrete CPU market as well as addressing demand for heterogeneous solutions that combine GPU, CPU […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on Intel Alder Lake hybrid mobile processor family to range from 5W to 55W TDP (leak)

Intel Alder Lake hybrid mobile processor family to range from 5W to 55W TDP (leak)

Intel Alder Lake Mobile Hybrid Processors

Intel’s first foray into hybrid processors using Foveros 3D stacking technology did not end well with the company just announcing the end of the life for Lakefield hybrid processors. But the company is not giving up on hybrid technology, and a recent leak shows the Intel Alder Lake family comprised of more powerful mobile hybrid processors will be offered for a wide range of applications from tablets with 5-7W M5 processors and up to “muscle laptops” or mobile workstations (MWS) with H55 processor at 45-55W TDP. Alder Lake hybrid processors will be comprised of high-performance CPU “Golden Cove” cores and energy-efficient Atom-based “Gracemont” CPU cores, in a way that’s similar to Arm’s Cortex-A7x big cores and Cortex-A5x LITTLE cores with big.LITTLE or DynamIQ processing with the goal of optimizing power consumption. The Intel Alder Lake Mobile SKU stack includes processors for 6 market segments including three “new” segments/TDP ranges according […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 29 Comments on First Armv9 cores unveiled – Cortex-A510, Cortex-A710, Cortex-X2

First Armv9 cores unveiled – Cortex-A510, Cortex-A710, Cortex-X2

Armv9 Cortex-A510 Cortex-A710 Cortex-X2

Armv9 architecture was announced in Q1 2021, building upon Armv8 but adding blocks and instructions for artificial intelligence, security, and “specialized compute”, i.e. hardware accelerators or instructions optimized for specific tasks. The company has now introduced the first three Armv9 cores with Cortex-X2, Cortex-A710, and Cortex-A510 cores, providing updates to respectively Cortex-X1, Cortex-A78, and Cortex-A55 cores. The company calls those new cores “Arm Total Compute solutions”. Arm Cortex-X2 flagship core is the company’s most powerful CPU so far with 30% performance improvements over Cortex-X1 and will be found in premium smartphones and laptops. Arm Cortex-A710 “big” CPU core provides a 30% energy efficiency gain and 10% uplift in performance compared to Cortex-A78, while Arm Cortex-A510, high efficiency “LITTLE” Armv9 core delivers up to 35% performance improvements and over 3x uplift in ML performance compared to Cortex-A55 announced four years ago, or about the same performance as the “big” Cortex-A73 cores […]
