cortex a72

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on AMD Versal Premium Gen2 SoC FPGA family features Arm Cortex-A72/R5F cores, high-end FPGA fabric, PCIe Gen6, CXL 3.1 interfaces

AMD Versal Premium Gen2 SoC FPGA family features Arm Cortex-A72/R5F cores, high-end FPGA fabric, PCIe Gen6, CXL 3.1 interfaces

AMD Versal Premium Series Gen 2 SoC FPGA combines dual-core Cortex-A72 and dual-core Cortex-R5F processors with high-end FPGA fabric with up to 3.2 million logic cells and CXL 3.1 (Compute Express Link), PCIe Gen6, and DDR5/LPDDR5X high-bandwidth interfaces for data center, communication equipment, test & measurement, and aerospace & defense data-intensive applications. AMD Versal Premium Gen2 specifications: CPU cores Dual-core Arm Cortex-A72 application core, 48 KB/32 KB L1 Cache w/ parity & ECC; 1 MB L2 Cache w/ ECC Dual-core Arm Cortex R5F, 32 KB/32 KB L1 Cache, and 256 KB TCM w/ECC Memory – 256MB on-chip with ECC FPGA fabric System Logic Cells – Up to 3,273,480 LUTs – Up to 1,496,448 DSP Engines – Up to 7,616 Interfaces connected to CPU cores 2x Ethernet 2x UART, 2x SPI, 2x I2C 2x CAN-FD 1x USB 2.0 FPGA memory, interfaces, I/Os, and transceivers Up to 327 Mbit memory @ 273 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on J721E DRA829/TDA4VM/AM752x – Texas Instruments Cortex-A72 based Monster SoC’s

J721E DRA829/TDA4VM/AM752x – Texas Instruments Cortex-A72 based Monster SoC’s

J721E DRA829 TDA4VM AM752x Block Diagran

Texas Instruments unveiled their first 64-bit processor in 2018 with TI AM654 “Keystone III” quad-core Arm Cortex-A53 + dual lockstep Cortex-R5F processor designed for general embedded and industrial applications. The company is now working on a more powerful processor with J721E SoC with Cortex-A72 cores belonging to the K3 Multicore SoC architecture platform appearing in TI Linux git repository. Ti J721E is a monster of an SoC, not necessarily in terms of CPU processing power, but it has an amazing amount of features and peripherals. I’m not going to list all specifications of this monster SoC, and we’ll do with J721E highlights instead: CPU Dual Cortex-A72 up to 2.0 GHz in a single cluster Up to three clusters of lockstep capable dual Cortex-R5F MCUs @ 1.0 GHz AI Accelerator / DSP Deep-learning Matrix Multiply Accelerator (MMA) @ up to 1.0 GHz (8 TOPS for 8-bit inference) C7x floating-point Vector DSP […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on NXP QorIQ LayerScape LX2160A is a 16-core Arm Cortex A72 Communication Processor with 100 Gbit/s Ethernet

NXP QorIQ LayerScape LX2160A is a 16-core Arm Cortex A72 Communication Processor with 100 Gbit/s Ethernet

NXP Semiconductors has been working  on a high-end communication processor with their QorIQ LayerScape LX2160A SoC equipped with 16 Arm Cortex A72 cores, 16 Ethernet ports supporting 1 to 100 Gbit/s, as well as 24 PCIe Gen4 lanes, and four SATA 3.0 ports. NXP LX2160A key specifications / features: Processor – 16x Arm Cortex-A72 CPU cores, running up to 2.2GHz with 8MB L2 cache, 8MB platform cache Memory I/F – 2 x DDR4 72b including ECC, up to 3200 MT/s, maximum capacity of 256 GB Storage – 4 x SATA3.0 Ethernet Up to 16 Ethernet ports Supported Ethernet speeds include 1, 2.5, 10, 25, 40, 50, and 100 gigabits per second 130Gbps Layer 2 Ethernet switch PCIe – Up to 24 PCIe Gen4 lanes, supporting ports as wide as x8 24 SerDes lanes, operating up to 28GHz Acceleration Engines – 50Gbps security accelerator, 100Gbps data compression/decompression engine Security – Secure […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Advantech ROM-7720 is a Qseven 2.1 Compliant i.MX 8 QuadMax Computer-on-Module

Advantech ROM-7720 is a Qseven 2.1 Compliant i.MX 8 QuadMax Computer-on-Module

Many solutions based on NXP i.MX8 processors are likely to be announced during Embedded World 2018 next week. We’ve already seen several NXP i.MX 8M Cortex A53 based modules such as Variscite DART-MX8M or Compulab CL-SOM-IMX8 systems-on-module, and more are coming. One of those will be Advantech ROM-7720 computer-on-module (CoM) featuring the top of the line NXP i.MX 8 QuadMax Cortex A72/A53 processor and following QSeven 2.1 specifications / form factor. Advantech ROM-7720 CoM specifications: SoC –  NXP i.MX 8QuadMax processor with 2x Cortex A72 cores @ up to 1.6GHz, 4x Cortex A53 cores, 2x Cortex-M4F real-time cores, a HiFi 4 DSP, and 2x Vivante GC7000XSVX GPUs System Memory – 2GB LPDDR4 @ 1600 MHz (optional 4GB RAM) Storage – 8 GB eMMC Flash for OS, 64 MB Quad SPI Flash for boot loader Video Output / Display I/F 2x 24-bit LVDS, 1366 x 768 for 1ch; 1920 x 1080 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 33 Comments on SolidRun MACCHIATOBin Mini-ITX Networking Board is Now Available for $349 and Up

SolidRun MACCHIATOBin Mini-ITX Networking Board is Now Available for $349 and Up

SolidRun MACCHIATOBin is a mini-ITX board powered by Marvell ARMADA 8040 quad core Cortex A72 processor @ up to 2.0 GHz and designed for networking and storage applications thanks to 10 Gbps, 2.5 Gbps, and 1 Gbps Ethernet interfaces, as well as three SATA port. The company is now taking order for the board (FCC waiver required) with price starting at $349 with 4GB RAM. MACCHIATOBin board specifications: SoC – ARMADA 8040 (88F8040) quad core Cortex A72 processor @ up to 2.0 GHz with accelerators (packet processor, security engine, DMA engines, XOR engines for RAID 5/6) System Memory – 1x DDR4 DIMM with optional ECC and single/dual chip select support; up to 16GB RAM Storage – 3x SATA 3.0 port, micro SD slot, SPI flash, eMMC flash Connectivity – 2x 10Gbps Ethernet via copper or SFP, 2.5Gbps via SFP,  1x Gigabit Ethernet via copper Expansion – 1x PCIe-x4 3.0 slot, Marvell […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Yundoo Y8 (Rockchip RK3399) TV Box Review – Part 1: Unboxing and Teardown

Yundoo Y8 (Rockchip RK3399) TV Box Review – Part 1: Unboxing and Teardown

Rockchip first unveiled RK3399 hexa-core processor at the beginning of 2016, but we had to wait longer than expected to get devices to play with. The first retail product based on the processor is really Samsung Chromebook Plus, and we only saw a few TV boxes for pre-sale in January such as Yundoo Y8 or R-TV Box K99, and with the first shipments occurring in March. However, I’ve also noticed many companies postponed the launch of the RK3399 mini PC/TV box, and no company contacted me for review so far, so I had no rush because that probably means the boxes were not quite ready. But starting at the beginning of next month, more companies will start selling their model, and GearBest proposed to send me Yundoo Y8 model with 4GB RAm, 32GB flash, and decided to give it a go. In this first part of the review, I’ll only […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on 9Tripod X3399 SoM and Development Board are Powered by Rockchip RK3399 Hexa Core Processor

9Tripod X3399 SoM and Development Board are Powered by Rockchip RK3399 Hexa Core Processor

9Tripod (九鼎创展) has just launched X3399 system-on-module powered by Rockchip RK3399 hexa-core Cortex A72/A53 processor, and as well as a corresponding development board for people wanted to get started quickly before designing their own baseboard. X3399 core board preliminary specifications: SoC – Rockchip RK3399 hexa-core big.LITTLE processor with two ARM Cortex A72 cores up to 2.0 GHz, four Cortex A53 cores, and a ARM Mali-T860 MP4 GPU with OpenGL 1.1 to 3.1 support, OpenVG1.1, OpenCL and DX 11 support System Memory – 2GB LPDDR3 (2x Samsung K4E8E304EE-EGCF) Storage – 8GB eMMC 5.0 flash (Samsung KLM8G1GEND-B031) IOs – 204-pin to be soldered on baseboard PMIC – Rockchip RK808-D Dimensions – 55×55 mm 9Tripod does have a forum in English, but the company provides most of the information in Chinese.  I could not find details about Linux or Android images and source code, except a few mentions of Linux Qt, Ubuntu, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on $140 R-TV BOX K99 Android 6.0 mini PC Comes with Rockchip RK3399 SoC, 4GB RAM, 32GB Storage

$140 R-TV BOX K99 Android 6.0 mini PC Comes with Rockchip RK3399 SoC, 4GB RAM, 32GB Storage

We will the first hardware platforms shipping with a Rockchip RK3399 hexa-core processor later this month and in March, with Firefly-RK3399 development board, and various TV boxes / mini PCs such as Vorke Z3, Yundoo Y8, and Remix IO+. Another option is “R-TV BOX K99” with 4GB RAM, 32GB storage, Gigabit Ethernet, 802.1ac WiFi… that’s currently up for pre-order on GeekBuying for $139.99, and scheduled to ship in 3 days. R-TV BOX K99 specifications: SoC – Rockchip RK3399 hexa core processor with 2x ARM Cortex A72 cores @ up to 2.0 GHz, 4x ARM Cortex A53 cores, Mali-T860MP4 GPU @ 800 MHz with support for OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, AFBC (frame buffer compression) System Memory – 4GB DDR3 Storage – 32 GB eMMC 5.1 flash + micro SD card slot Video Output – HDMI 2.0 up to 4K @ 60 Hz Video Codecs – 4K 10-bit H.265, H.264 & […]
