Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on MorphESP 240 ESP32-S2 board integrates a 1.3-inch color display (Crowdfunding)

MorphESP 240 ESP32-S2 board integrates a 1.3-inch color display (Crowdfunding)

MorphESP 240 ESP32-S2 board with color display

We’ve already seen ESP32 platforms with a color display such as M5Stack, but MorphESP 240 is kind of cute with a 1.3-inch color display, features the more recent ESP32-S2 WiFi processor, and supports battery power & charging. MorphESP 240 specifications: Wireless Module – ESP32-S2-WROOM with Espressif Systems ESP32-S2 single-core 32-bit Xtensa LX7 microprocessor up to 240 MHz with 128 KB ROM, 320 KB SRAM, 16 KB SRAM in RTC, 4MB SPI flash, 802.11 b/g/n 2.4 GHz Wi-Fi connectivity Display – Onboard 1.3-inch ST7789 display with 240 x 240 resolution, connected over SPI USB – 1x Micro USB port for power/charging and programming Expansion – 16-pin and 24-pin headers with GPIO, I2C, UART, SPI, USB, and power signals Misc – WS2812B RGB LED connected to IO16, Reset button, boot mode switch, battery on/off switch Power Supply 5 V to 3.3 V regulator to feed additional modules JST connector for a battery […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on FeatherS2 Board Brings ESP32-S2 to Adafruit Feather Form Factor

FeatherS2 Board Brings ESP32-S2 to Adafruit Feather Form Factor

FeatherS2 Pinout Diagram

We’ve covered a fair number of development boards following Adafruit Feather form factor in the last year or so with products such as QuickFeather Cortex-M4 + FPGA board, OrangeCrab (Lattice FPGA), nRF9160 Feather providing LTE IoT & GPS connectivity, and other boards. But here’s yet another Adafruit Feather themed board that has just launched: FeatherS2. The tiny board is equipped with the latest Espressif Systems ESP32-S2 WiFi SoC, 16 MB SPI Flash, 8 MB PSRAM, several I/O, and a USB-C port for power and programming. FeatherS2 key features and specifications: SoC – ESP32-S2 single-core Tensilica LX7 processor @ 240 MHz, RISC-V ultra-lower power co-processor, 320 kB SRAM, 128 kB ROM Memory – 8 MB extra PSRAM Storage – 16 MB SPI Flash Connectivity – 2.4 GHz Wi-Fi – 802.11b/g/n with 3D antenna USB – 1x USB-C port for power and programming Sensor – ALS-PT19 Ambient Light Sensor Expansion 16 + […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on CircuitBrains Deluxe is a Tiny, CircuitPython-compatible Module (Crowdfunding)

CircuitBrains Deluxe is a Tiny, CircuitPython-compatible Module (Crowdfunding)

CircuitBrains Deluxe

There are plenty of boards with Adafruit’s CircuitPython support, but Microchip SAMD51 powered CircuitBrains Deluxe is a little different since it’s a module with castellated holes that make it easy to solder to your own baseboard or integrate into a space-constrained product. CircuitBrains Deluxe specifications: MCU – Microchip/Atmel ATSAMD51J19 32-bit ARM Cortex M4 microcontroller @ 120 MHz with 192 KB SRAM, 512 KB Flash Storage – 8 MB Quad SPI Flash I/Os via 48x through holes and castellated holes around the module GPIO (13 Analog, 2 of which are DAC capable, and 19 Digital) SPI, I²C, UART SWD programming/debug interface USB D- & D+ Power Supply Voltage – 5V Output – Onboard 3.3 V 600 mA Linear Regulator (LDO) connected to 3V3 pin Dimensions – 29 x 29 x 3.5 mm The module comes preloaded with CircuitPython, a fork of MicroPython maintain by Adafruit. You can just connect the board […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Snekboard Controls LEGO Power Functions with CircuitPython or Snek Programming Languages (Crowdfunding)

Snekboard Controls LEGO Power Functions with CircuitPython or Snek Programming Languages (Crowdfunding)

Snekboard

LEGO has provided robotics kit for years, and LEGO blocks and accessories in general are great to build all sort of projects, so it’s not surprising third-parties have come up with LEGO-compatible boards and accessories for makers which include DFRobot BOSON kits, STEMTera smart breadboard, Brixo LEGO blocks with built-in electronics, and more. Snekboard is another option with the Microchip SAMD21 board designed to work with LEGO Power Functions motors and switches are programmable with MicroPyhon based CircuitPython or Snek programming languages. Snekboard hardware specifications: Microcontroller – Microchip SAMD21G18A Arm Cortex-M0 MCU with 256 KB flash and 32 KB RAM. Storage – 2MB SPI flash USB – 1x Micro USB port for power and programming Motor Control – 4x TI DRV8800 DC motor drivers tp provide up to 2.8A for LEGO motors and servos I/O- 8x GPIOs (3.3V) Misc – 2x RGB LEDs, 1x blue LED Power Supply 5V via […]

Posted on by Tiwalade Joanna Okedara - 3 Comments on LEGO Minifigure shaped Mini SAM M4 Board Supports CircuitPython and Arduino

LEGO Minifigure shaped Mini SAM M4 Board Supports CircuitPython and Arduino

Mini SAM Lego Board

If you are a fan of the Lego movie. Perhaps you have always wanted to use Lego bricks to make something innovative and techy. Then the Mini SAM M4 board is here for you, as it is a LEGO minifigure-sized development board. Additionally, the design and layout of the board is based around the classic 1980’s ‘spaceman’, and is made by Ben Shockley. Although the board is very small, it has a lot of wonderful features. It comes with an analog reference decoupling/filtering capacitors. Also, it has an analog to digital ferrite bead, as well as a debounce circuitry for the reset and user buttons. Furthermore, the board’s software and firmware can be developed using CircuitPython or Arduino. The development board is either based on the Microchip SAMD51G 48-Pin 32-Bit ARM – Cortex M4F MCU (Mini SAM M4), or features the Microchip SAMD21G 48-Pin 32-Bit ARM Cortex -M0+ MCU running […]
