December 3, 2015December 3, 2015 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Axiomtek MANO300 Industrial mini-ITX Board Features Intel Celeron N3150 Processor, Plenty of Interfaces

Axiomtek MANO300 is an industrial grade fanless mini-ITX motherboard powered by an Intel Celerron N3150 “Braswell” quad core processor with two SO-DIMM slots, two SATA interfaces, dual Gigabit Ethernet, several serial interfaces and more, targeting automation and embedded industries. MANO300 board specifications: SoC – Intel Celeron N3150 quad core Braswell processor @ up to 2.08 GHz with Intel HD Gen8 Graphics System Memory – 2x 204-pin SO-DIMM dual channel DDR3L-1333 up 8 GB Storage – 1 x SATA-600, 1x mSATA, SDXC card slot Display – 1x VGA, 1x HDMI, 1x LVDS (Up to 3 independent displays supported) Connectivity – 2 x 10/100/1000Mbps (Realtek RTL8111F) Serial 2x RS-232/422/485 (DB9) 4x RS-232 (one with 5V/12V power select) via connectors USB – 4x USB 3.0 host ports, 2x USB 2.0 (internal) Audio – Mic-in/Line-out Expansion – 1x PCIe x1, 1x PCI Express Mini Card with SIM card slot, 8x digital I/Os Misc – […]

October 15, 2015 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

ASRock N3150TM-ITX Thin Mini-ITX Board is Powered by Intel Celeron N3150 Processor

With its N3150DC-ITX motherboard, ASRock had already released a mini-ITX motherboard based on Intel Celeron N3150 “Braswell” quad core processor, but the company has now launched a thin mini-ITX version, which limits the maximum height to 2.5cm and is often used in All-in-One PCs, with ASRock N3150TM-ITX motherboard. ASRock N3150TM-ITX board specifications: SoC – Intel Celeron N3150 quad core processor @ up to 2.08 GHz with Intel HD Graphics Gen8 @ up to 640 MHz – 6W TDP System Memory – 2x DDR3/DDR3L SO-DIMM slots for up to 16GB RAM Storage – 2x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug Audio Codec – Realtek ALC892 Audio Codec, 7.1 CH HD Audio Expansion – 1x PCI Express 2.0 x1 Slot, 1x half size Mini PCI Express slot (Bluetooth function in WiFi module not supported) Rear panel ports Video Output 1x HDMI port up to 2560×1600 @ 60Hz 1x […]

August 25, 2015 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ECS LIVA X2 Braswell Mini PC Features Up to 4GB RAM, 64GB eMMC, Sells for $170 and Up

ECS LIVA was one of the first low power Intel mini PC that included both RAM and storage for less than $200 when it was first announced in March 2014. Since then there’s been a tidal wave of Bay Trail mini PCs hitting the market, and now that it’s time for Braswell and Cherry Trail lower system, ECS released LIVA X2 mini PC powered by Intel Braswell N3050 processor, that’s available for $169.99 on Newegg with 2GB RAM and 32GB storage, or $239.99 with 4GB RAM and 64GB storage. ECS LIVA X2 specifications: SoC – Intel Celeron N3050 “Braswell” dual core processor @ 1.6 GHz / 2.16GHz (Turbo) and Intel HD Graphics (6W TDP) System Memory – 2 or 4GB DDR3L (soldered) Storage – 32GB / 64GB eMMC flash, 1x M.2 for SSD (Up to 1TB) Connectivity – Gigabit Ethernet, WiFi 802.11ac and Bluetooth 4.0 Video Output – HDMI and […]

August 4, 2015 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Gigabyte GB-BACE-3000 is a Fanless mini PC Powered by Intel Celeron N3000 Braswell Processor

Systems with the latest low power Intel Braswell processors are starting to hit the shelves, and after ASRock Beebox, some Braswell laptops, Intel Braswell NUCs, and some ASRock motherboards, here’s another Braswell mini PC with Gigabyte BRIX GB-BACE-3000 based on Intel Celeron N3000 dual core processor. GB-BACE-3000 specifications: SoC – Intel Celeron N3000 dual core processor up to 2.08GHz with Intel Gen8 HD Graphics (4W TDP) System Memory – 1x SO-DIMM DDR3L 1.35V slot @ 1066/1333/1600 MHz up to 8GB RAM Storage – 2.5” thickness 7.0/9.5mm Hard Drives (1 x 6Gbps SATA3), 1 x Micro SD card slot Video Output HDMI up to 3840×2160 @ 30 Hz VGA up to 1920×1200 @ 60 Hz Audio – Realtek ALC255 audio codec, 1x Audio-out / Mic-In, HDMI Connectivity – Gigabit LAN (Realtek RTL8111H), Wi-Fi 802.11ac + Bluetooth 4.0 (M.2 module) USB – 2 x USB 3.0 ports (front panel), 2 x USB […]

July 19, 2015July 19, 2015 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

ASRock N3150DC-ITX Mini-ITX Motherboard is Powered by a DC Adapter

Last week, I wrote about low cost ASRock Braswell motherboards with pricing starting at just under $60. But there were mainly two complaints about these boards: performance was about the same as similarly priced Bay Trail processors, and the requirements for a large – and relatively expensive – ATX power supply. There’s not much that can be done to improve performance, but ASRock also has launched N3150DC-ITX motherboard powered by a 19V DC adapter. ASRock N3150DC-ITX motherboard specifications: SoC – Intel Celeron N3150 quad core processor @ up to 2.08 GHz with Intel HD Graphics Gen8 @ up to 640 MHz – 6W TDP System Memory – 2x 240-pin DDR3/DDR3L 1600/1066 for up to 16GB RAM Storage – 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug Audio Codec – Realtek ALC892 Audio Codec, 7.1 CH HD Audio Expansion – 1x PCI Express 2.0 x1 Slot, 1x […]

July 12, 2015August 29, 2015 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

Intel Braswell Motherboards (N3150 / N3050) Are Now Available for $60 and Up

Intel recently launched Braswell processors to succeed to their Bay Trail processor family, using 14nm lithography, a newer generation Intel GPU, more L2 cache, and various other improvements. Some ASRock motherboards based on such processors are now listed on Newegg starting at $58.99 with ASRock N3050B-ITX motherboard (dual core processor), and $69.99 for the quad core version (ASRock N3150B-ITX). Apart from the different processors, both mini-ITX motherboard mostly share the same specifications: SoC Intel Celeron N3050 dual core processor @ up to 2.16 GHz with Intel HD Graphics Gen8 @ up to 600 MHz – 6W TDP Intel Celeron N3150 quad core processor @ up to 2.08 GHz with Intel HD Graphics Gen8 @ up to 640 MHz – 6W TDP System Memory – 2x 240-pin DDR3/DDR3L 1600/1066 for up to 16GB RAM Storage – 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug Audio Codec – […]

May 26, 2015May 26, 2015 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Intel Introduces Braswell NUCs with Celeron N3050 and Pentium N3700 Processors

Intel has already announced several Braswell processors as successors for Bay Trail-M processor with 4 to 6W TDP and 14nm manufacturing process. Two of these, namely Intel Celeron N3050 (dual core) and Pentium 3700 (quad core), have fund their way into the latest Intel NUCs that are currently listed for $140 and $180 in the US with the official release date fixed on June 8. The dual core version is called NUC5CPYH, while the quad core is NUC5PPYH. Both share the following specs: Processor Intel Celeron N3050 dual core processor @ up to 2.16 GHz with 2MB cache, Intel HD Graphics @ 600 MHz max, 6W TDP Intel Pentium N3700 quad core processor @ up to 2.4 GHz with 2MB cache, Intel HD Graphics @ 700 MHZ max, 6W TDP Memory – 1x DDR3L SODIMM 1.35V, 1333/1600 MHz up to 8GB maximum Storage – 1x SATA @ 6.0 Gbps for […]

April 9, 2015 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Intel Celeron N3000 2-in-1 Laptop, and MSI Motherboards with Celeron N3050/N3150 and Pentium N3700 Processors

Intel introduced the first low power Braswell Celeron and Pentium processors with 4 to 6W TDP, meaning a lower power consumption compared to Bay Trail-M processors, and with better performance. The first devices and motherboards based on these have started to show up with Intel’s Orchid Island 2-in-1 Reference Design based on Celeron N3000, and three MSI motherboards: N3050I ECO, N3150I ECO, and N3700I ECO respectively powered by Celeron N3050 dual core processor, Celeron N3150 quad core processor, and Pentium N3700 quad core processor, all clocked @ 1.6GHz (base frequency) and with 6W TDP. MSI did not release full details about their motherboards but we still now they’ll support H.265/HEVC hardware decoding up to 4K, Blu-ray playback and 8-channel HD Audio via an HDMI 1.4b port. Other connectors and interfaces include two DDR3L-1600MHz SO-DIMM slots (up to 8GB), two SATA III ports, one PCIe slot, Gigabit Ethernet, a COM port, […]
