Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Boardcon Idea3399 Features-Rich SBC Comes with M.2 NVMe SSD and 4G LTE PCIe Sockets

Boardcon Idea3399 Features-Rich SBC Comes with M.2 NVMe SSD and 4G LTE PCIe Sockets

SBC M.2 NVMe SSD & mPCIe 4G LTE card

Back in 2017, Boardcon introduced EM3399 single board computer powered by a Rockchip RK3399 processor through the company’s PICO3399 SO-DIMM system-on-module. They’ve now designed another RK3399 SBC – Idea3399 – comprised of a baseboard and module, but instead of re-using the SO-DIMM module, CM3399 system-on-module with castellated holes was used instead. The new board comes with many of the same features as their first board but adds an M.2 NVMe SSD slot and mPCIe socket for 4G LTE modem on the back of the board. CM3399 SoM Key features and specifications: SoC – Rockchip RK3399 dual Cortex-A72 @ 1.8GHz + quad Cortex-A53 @ 1.4GHz System Memory – 4GB LPDDR4 Storage – 8GB eMMC flash 202 castellated pin (1.3mm pitch) with  USB2.0 host, USB3.0 host, USB OTG, UART, MIPI, Ethernet, SPI, HDMI out, I2C, I2S, PCI Express, SDIO, SD/MMC, eDP, Camera, PWM, ADC IN, etc… Power – Supply Voltage: 5V; RK808 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Boardcon Introduces Rockchip RK3399 PICO3399 CPU Module and EM3399 Baseboard

Boardcon Introduces Rockchip RK3399 PICO3399 CPU Module and EM3399 Baseboard

There’s a limited number of boards based on Rockchip RK3399 processor, with the easiest to work with (for non-Chinese readers) probably being Firefly-RK3399. Shenzhen Xunlong is working on their own Orange Pi RK3399 board, 9Tripod released their X3399 SoM and devkit, Boardcon has also launched their own RK3399 SoM (system-on-module) and baseboard solution with respectively PICO3399 CPU module and EM3399 board. PICO3399 SoM specifications: SoC – Rockchip RK3399 hexa core processor with a dual ARM Cortex-A72 core cluster @ up to 2.0 GHz, quad ARM Cortex-A53 cluster, and ARM Mali-T860MP4 GPU System Memory – 4GB LPDDR3 Storage – 8GB eMMC flash 314-pin edge connector with 2x USB2.0 Host, 2x USB3.0 or 2x  Type-C, UART, MIPI, GbE, HDMI in&out, Audio, I2C, I2S, PCI-E, SD/MMC/SDIO, GPIO, eDP.. Power Supply – 5V Dimensions – 82 x 50mm (8 layers) The company provides support  for Android6.0.1 and Debian for the module. If the info […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on Boardcon MINI6818 CPU Module Features Samsung S5P6818 Octa-core Processor

Boardcon MINI6818 CPU Module Features Samsung S5P6818 Octa-core Processor

Update: a defect has been found, so the board is not for sale anymore. Samsung S5P6818 octa-core Cortex A53 processor has already been found in several single board computers and development boards including Graperain G6818 SBC and NanoPi M3 board, but so far I had not seen it implemented into a system-on-module to be used in custom designs, and that’s just was Boardcon did with their MINI6818 CPU module. Boardcon MINI6818 SoM specifications: SoC – Samsung S5P6818 octa-core ARM Cortex A53 processor @ 1.4GHz with Mali-400MP 3D GPU System Memory – 1GB DDR3 Storage – 4GB eMMC Flash 2x 100-pin board-to-board connectors with 1.27 pitch: 5x UART, I2C, SPI 1x USB2.0 Host, 1x USB HSIC Host, 1x USB2.0 OTG, LCD (TFT/LVDS/MIPI) Gigabit Ethernet I2S, CIF (not sure what it is), Audio HDMI GPIOs ADC PWM HSMMC/SD Power – 5V; AXP228 PMIC Dimensions – 70 x 58 mm (8-layer PCB) The […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Boardcon’s Rockchip RK3288 Single Board Computer Runs Android 4.4/5.1, Supports 3G, GPS, 5 Display Interfaces and More

Boardcon’s Rockchip RK3288 Single Board Computer Runs Android 4.4/5.1, Supports 3G, GPS, 5 Display Interfaces and More

Rockchip RK3288 is back in the news this month, and after the announced of MiQi low cost board a few days ago, an high-end Rockchip RK3288 SBC has come to market with Boardcon EM3288 comprise of MINI3288 CPU module, and a features-packed baseboard with multiple ports and connectivity options, including SATA and a 3G modem. EM3288 board specifications: SoC – Rockchip RK3288 quad core ARM Cortex A17 processor up to 1.8 GHz with Mali-T764 GPU System Memory – 2G DDR3 Storage – 8 GB eMMC flash, SATA, and micro SD slot Video I/O HDMI 2.0 up to 3840×2160@60p (provided your TV/monitor support YUV444) VGA 1x 26-pin MIPI connector, 1x 40-pin LVDS (multiplexed with VGA), 1x 40-pin TTL LCD connector Audio Output / Input – HDMI, Line IN and OUT 3.5mm jacks, and built-in MIC Connectivity Gigabit Ethernet Optional 8021.11b/g/n and Bluetooth4.0 via Ampak AP6212 module Optional 3G via ZTE MF210 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Boardcon Compact 31S is an Allwinner A31s based Development Board with HDMI, VGA, and LCD Interfaces

Boardcon Compact 31S is an Allwinner A31s based Development Board with HDMI, VGA, and LCD Interfaces

Boardcon Embedded Design, an ODM providing industrial Computer-on-Module, and board, announced Compact A31S powered by Allwinner A31s quad core Cortex A7 processor, with 2GB RAM, 4GB eMMC, HDMI, LCD and VGA video outputs, and various other ports. Boardcon Compact A31s hardware specifications: SoC – Allwinner A31s quad core ARM Cortex-A7 @ 1 GHz with 256 KB L1 cache, 1MB L2 cache, and PowerVR SGX544MP2 GPU compliant with OpenGL ES 2.0, OpenCL 1.x, DX 9_3 System Memory – 2GB DDR3 @ 1866MHz Storage – 4GB eMMC Flash + micro SD slot Video Output – HDMI 1.4, VGA (up to 1280×800), and 40-pin FPC connector for LCD with capacitive touch screen support Audio Output – HDMI, 3.5mm headphone jack Connectivity – 10/100M/1000M Ethernet, Wi-Fi USB – 1x USB 2.0 host port, 1x USB 2.0 OTG port Camera – CMOS Camera interface Expansion – 1x 20-pin expansion connector for GPIOs Misc – Real Time […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Boardcon EM4412 SBC Powered by Exynos 4412 SoC Targets Embedded & Industrial Applications

Boardcon EM4412 SBC Powered by Exynos 4412 SoC Targets Embedded & Industrial Applications

Boardcon Technology Limited, a Shenzhen based ODM specializing in industrial boards and modules, has announced their EM4412 single board computer featuring MINI4412 core board powered by Samsung Exynos 4412 quad core Cortex A9 SoC a few months ago. The board, with ports such as CAN, RS-485, and a DB9 RS-232 connector, appears to have been designed with industrial applications in mind, such as point-of-sales (PoS), slot machines, car-mounted systems, factory automation, traffic management, and more. Boardcon EM4412 specifications: SoC – Samsung Exynos 4412 quad core Cortex A9 cores @ up to 1.6GHz and ARM Mali-400MP4 GPU System Memory – 2GB DDR3 RAM Storage – 4GB eMMC flash +  mini? / micro SD card slot Display HDMI 1.4 – Up to 1080p30 24-bit RGB parallel LCD interface Optional 4.3″, 7″, or 10.1″ch resistive or capacitive touchscreen Camera interfaces: MIPI-CSI slave (mipi2L CH) Optional 2x camera interfaces supporting ITU 601/656 I/F up […]
