June 16, 2017 by Jean-Luc Aufranc (CNXSoft) - No Comments

Axiomtek tBOX100-838-FL Fanless Transportation Computer Features BNC Video & Audio Inputs for DVR Function

Axiomtel tBOX100-838-FL is a fanless Bay Trail rugged embedded computer powered by an Intel Bay Trail-I E3845 processor with 5 BNC input ports for video and audio, and targeting vehicle, railway and marine markets. Axiomtek tBOX100-838-FL rugged mini PC’s specifications: SoC – Intel Atom E3845 quad core Bay Trail-I processor @ up to 1.91 GHz with Intel HD graphics System Memory – 4 GB DDR3L-1333 Storage – 1x 2.5” SATA slot up to 9.5mm, 1x mSATA connector, flash for AMI BIOS Video Output – 1x VGA port Video / Audio Input – 4x video in BNC connector, 1x audio in BNC connector Connectivity – 2x M12 A-coded GbE LAN or 2x RJ-45 GbE LAN (via Intel i210) Serial – 1x RS-232/422/485 (DB9) USB – 2x USB 2.0 port Expansion – 1x Full-size PCIe Mini Card with mSATA; 1x SIM card slot Misc – 1x remote switch; 1x reset button; watchdog […]

May 24, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

MinnowBoard Turbot Quad Core Open Source Hardware Board is now Shipping for $190

MinnowBoard Turbot Quad Core board was announced last autumn, with shipping expected in December 2016, but there may have been delays as the MinnowBoard foundation has just announced that the Intel open source hardware board is now shipping. MinnowBoard Turbot Quad “MBT-4220” board specifications: SoC – Intel Atom E3845 quad core Bay Trail-I processor @ up to 1.92 GHz with Intel HD graphics @ 542 / 792 MHz (10W TDP) System Memory – 2GB DDR3L 1067 MT/s (Soldered) Storage – 1x SATA2 3Gbps, 1x micro SD card slot, 8 MB SPI Flash for firmware (Tianocore UEFI, Coreboot, SeaBIOS) Video & Audio Output – 1x micro HDMI connector Connectivity – 10/100/1000M Ethernet RJ-45 connector (with Intel i211 instead of Realtek NIC on dual core MinnowBoard) USB – 1x USB 3.0 host, 1x USB 2.0 host Debugging – Serial debug header Expansion headers Low-speed expansion (LSE) port – 2×13 (26-pin) male 0.1″ […]

March 29, 2017April 1, 2017 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

isorespin.sh Script Updates Ubuntu ISO Files with Mainline Linux Kernel

Devices based on Intel Bay Trail and Cherry Trail processors have been popular due to their integration into low cost system (for an Intel platform), but Intel did not prioritize Linux development for those processors, so while Linux could run, you’d have various problems with HDMI audio, system freezes, and wireless drivers, unless you used a custom kernel. The goods news is that Linux 4.11 will feature fixes for HDMI audio and system freeze, and so you won’t need a custom kernel anymore. Ian Morrison (Linuxium), who has been working on improving Linux for those devices since they were first released, has now released isorespin.sh script to automatically update any Ubuntu ISO image to the latest mainline Linux RC kernel built by Canonical, but not integrated by default in the ISO. Once you’ve downloaded isorepin.sh and your ISO of choice, e.g. ubuntu-16.04.2-desktop-amd64.iso, you can update the ISO with mainline Linux […]

February 14, 2017February 14, 2017 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Intel Atom Z3735F (Bay Trail) vs Intel Celeron N4200 (Apollo Lake) Benchmarks Comparison

Intel introduced new processors every year, but in most cases the performance improvement from new processor with a similar power profile is only incrementally better, as we’ve seen in our Atom X7-Z8700 vs Pentium N4200 benchmarks comparison, which means it’s not really worthwhile to upgrade performance-wise, unless you really a specific feature or interface found in the new processor. But what if we compare to processor from 2 to 3 years ago? Intel Atom Z3735F was a popular choice two years ago, and if you’re looking for a cheap Intel mini PC or TV box, that’s still the cheapest option with prices under $80. So I’ve decided to compare Intel Atom Z3735F (Bay Trail) processor with 2W TDP to the latest Pentium Celeron N4200 (Apollo Lake) with 6W TDP. To do so, I gathered benchmarks results from MeLE PCG03 mini PC (PCMark 8) and PCG01 TV stick (Passmark + 3Dmark) […]

January 12, 2017January 12, 2017 by Jean-Luc Aufranc (CNXSoft) - No Comments

BioDigitalPC Credit Card Sized Pluggable Computer Fits into Desktop Docks, AIO Monitors, Datacenters-in-a-Suitcase, and More

We’ve seen in the past at last two projects development CPU cards aimed for easy upgrade a replacement, starting with EOMA-68 standard currently with products based on ARM processors and mostly targeting the consumer market, followed more recently by Intel Compute Card that focuses on the smart devices and enterprise markets. But I’ve recently found out a third company has been doing pluggable CPU cards for a little while: Arnouse Digital Device Corporation (ADDC) with their BioDigitalPC cards designed for the military and small businesses, and pluggable into desktop docks, phones, all-in-one monitors, and even portable datacenters that fit into a suitcase. The company also has “reader boards” that you can integrate into your own products / enclosures. Everything is shown in the diagram below. The latest generation (Gen 9) of BioDigitalPC cards are based on Intel Atom Bay Trail-I single, dual or quad core processors with 2 to 8 […]

December 27, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

ADLE3800SEC is a Compact Intel Bay Trail-I Board with Dual Gigabit Ethernet, HDMI or DisplayPort, and More

ADL Embedded Solutions, a US company specializing in… embedded solutions, has unveiled ADLE3800SEC embedded single board computer (SBC) optimized for size, weight and power (SWAP), based on an Intel Atom E3800 Bay Trail-I processor with HDMI, SATA dual Gigabit Ethernet, etc… The board is the first one part of the company’s Edge-Connect architecture defined a 75x75mm form factor with an edge connector exposing additional I/Os for breakout boards. ADLE3800SEC board specifications: SoC Intel Atom E3827 dual core Bay Trail-I processor @ up to 1.75GHz with 1MB cache, Intel Gen7 graphics (8W TDP) OR Intel Atom E3845 quad core Bay Trail-I processor@ up to 1.91GHz with 2MB cache, Intel Gen 7 Graphics (10W TDP) System Memory – Up to 4GB DDR3-1333MHz (soldered on-board) Storage – 1x M.2 socket(Key B, 2242); 1x SATA 2.0 (6GB/s) via edge connector Video Output 1x HDMI up to 1920 x 1200 or 1x DisplayPort up to […]

November 3, 2016November 5, 2016 by Jean-Luc Aufranc (CNXSoft) - 268 Comments

Giveaway Week – Star Cloud PCG02U Ubuntu TV Stick

The fourth device for this giveaway week will be MeLE Star Cloud PCG02U TV stick powered by Intel Atom Z3735F quad core processor, but instead of running Windows 10, the device is sold with Ubuntu 14.04, which I upgraded to Ubuntu 16.04. I found out that the device was running pretty well (minus Bluetooth support) in my PCG02U review, and for the price at the time ($70) it was really a good deal. The device has even become the best selling devices on MeLE Aliexpress store, outselling all other Windows devices. However, MeLE ethics are questionable since they used Ian Morrison (Linuxium)’s image in their devices without giving any credits. The package will come with all accessories above, minus the “Caution Hot” sticker which must have gone to sticker heaven…. Simply leave a comment below to enter the draw. Other rules are as follows: Only one entry per contest. I […]

October 31, 2016 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Voyo V2 Bay Trail mini PC with Battery Sells for $70 (Promo)

Voyo V2 is an ultra thin mini PC powered by Intel Atom Z3735F Bay Trail processor with the usual 2GB RAM and 32GB storage configuration, and depending on model an extra 64GB SSD, as well as a battery acting as a UPS. GearBest now has promotion with the mini PC without SSD, but with the 5,000 mAh battery, for $69.99 including shipping with CPVY2 coupon. Voyo V2 specifications: SoC – Intel Atom Z3735F “Bay Trail” quad core processor @ 1.33 GHz (Bust freq: 1.83 GHz) with Intel HD graphics System Memory – 2 GB DDR3 Storage – 32 GB eMMC flash + SATA II connector for 1.8″ SATA drives (via USB to SATA bridge) Video Output – HDMI 1.4b port Audio Output – HDMI, and 3.5mm audio jack Connectivity – Fast Ethernet, 802.11 b/g/n Wi-Fi, and Bluetooth 4.0 (Ampak AP6212 module) USB – 1x USB 2.0 host, 1x micro USB […]
