September 11, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

PICO317 Fanless Atom x5-E3940 Pico-ITX SBC Powers Industrial IoT Applications

Axiomtek has launched a 2.5-inch Pico-ITX Atom x5-E3940 Apollo Lake SBC supporting two independent video outputs and designed for Industrial IoT (IIoT) applications for industrial automation and in the transportation and retail sectors. The PICO317 single board computer is equipped with up to 8GB SO-DIMM RAM, supports SATA and mSATA storage, Gigabit Ethernet, and dual video output is achieved via HDMI and LVDS interfaces. Axiomtek PICO317 specifications: SoC – Intel Atom x5-E3940 quad-core Apollo Lake processor @ 1.6 GHz / 1.8 GHz (Turbo) with 2 MB cache, 12 EU Intel HD graphics; 9.5W TDP System Memory – Up to 8GB RAM via 1x 204-pin DDR3L-1867 SO-DIMMto Storage – SATA 3.0 connector, mSATA socket (see Expansion section), flash for AMI BIOS Video Output – 1x HDMI up to 4K, 1x dual-channel 18/24-bit LVDS Audio – Realtek ALC662 HD Codec audio; Line-out jack Networking – Gigabit Ethernet via Intel i211-AT and supporting […]

June 16, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

NVIDIA Jetson Nano Powered Edge AI System Supports one PoE Camera, Operates in -30 to +60°C Temperature Range

NVIDIA Jetson Nano PoE Camera edge AI system

Axiomtek AIE100-903-FL is a fanless edge AI System powered by NVIDIA Jetson Nano system-on-module and designed to connect a single 15W PoE camera for AI computing, edge computing, smart retail, smart city, and more. The solution can operate in a wide range of temperatures from -30°C to +60°C and comes with an optional IP42-rated waterproof cover kit that makes it suitable for use in moist places and “semi-outdoor environments” including freezers and under eaves (edges of the roof which overhang the face of a wall) and other outdoor locations with some protection against rain. Axiomtek AIE100-903-FL specifications: SoM – NVIDIA Jetson Nano with quad-core Arm Cortex-A57 processors, 128 CUDA core NVIDIA Maxwell GPU, 4GB 64-bit LPDDR4 and 16GB eMMC flash Storage – 1x M.2 Key M 2280 with PCIe x4 NVMe SSD slot, 1x Micro SD slot Video Output – 1x HDMI 2.0 up to 4K2K @ 60 Hz Connectivity […]

May 28, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Ryzen Embedded SBC is Made for Real-time AI Vision, Conveyor Belt Tracking

MIRU130 Ryzen Embedded-SBC Real-time AI Vision Conveyor Belts

Axiomtek just recently introduced CAPA13R AMD Ryzen Embedded V1605B/V1807B SBC in 3.5″ embedded SBC form factor, and the company is now back with another, larger Ryzen Embedded SBC: Axiomtek MIRU130. Why would they launch yet another Ryzne Embedded board two weeks later? Different applications. While CAPA13R targets various graphics-intensive applications ranging from medical imaging to smart digital signage, MIRU130 appears to be especially focused on real-time vision-based AI applications with PoE and USB ports for cameras, and integrated “real-time vision I/Os” such as trigger inputs, LED lighting controllers, camera trigger outputs and an encoder input designed for conveyor tracking. MIRU130 SBC specifications: SoC (One or the other) – AMD Ryzen Embedded V1807B or V1605B quad-core processor with Radeon Vega 8 graphics; V1807B: 35-54W TDP; V1605B: 12-25W TDP System Memory – 2x 240-pin DDR4-2400 SO-DIMM, up to 16GB RAM Storage 1x SATA-600 1x M.2 Key B (SATA, USB 2.0, PCIe x2 […]

May 14, 2020May 28, 2020 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

AMD Ryzen Embedded V1605B/V1807B SBC Offers Four GbE Interfaces, Four Video Outputs

We’ve written about several AMD Ryzen Embedded V1000 SBCs and many of them fully leverage the processor multimedia capabilities with support for four 4K displays, but Axiomtek CAPA13R 3.5″ Embedded SBC adds an extra twist by also offering four Gigabit Ethernet ports. The board is equipped with either Ryzen Embedded V1807B or V1605B, up to 16GB RAM, and offers two M.2 sockets for storage and connectivity. Four independent display support is achieved through a mix of three types of video output including two HDMI ports, one DisplayPort, and one LVDS connector. Axiomtek CAPA13R V1605B/V1807B SBC specifications: SoC – AMD Ryzen Embedded V1807B ( 35-54W) or V1605B (12-25W) quad-core processor with Radeon Vega 8 graphics System Memory – 1 x 260-pin SO-DIMM socket for up to 16GB DDR4-2400 (V1605B), 16GB DDR4-3200 (V1807) Storage – SATA 3.0 port (6Gbps), support for M.2 SATA/NVMe SSD in 22x42mm or 30x42mm form factor (Key B […]

April 7, 2020April 8, 2020 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

4K Digital Signage Player Drives up to 4x 4K Displays with AMD Ryzen Embedded V1000 SoC

AMD Ryzen Embedded V1000 Digital Signage

We’ve covered plenty of AMD Ryzen Embedded V1000 SBC‘s, as well as some mini PC‘s, but the processor’s multimedia capabilities make it an ideal candidate for advanced digital signage players capable of driving multiple 4K displays. Axiomtek leveraged those capabilities in DSP600-211 4K digital signage player that offers four HDMI ports driving up to four 4K displays, as well as dual Gigabit Ethernet. Axiomtek DSP600-211 4K digital signage specifications: SoC (one or the other) AMD Ryzen Embedded V1605B quad-core/octa-thread processor @ 2.0GHz / 3.6 GHz (Boost) with AMD Radeon Vega 8 Graphics; 12-25W TDP AMD Ryzen Embedded V1807B quad-core/octa-thread processor @ 3.35GHz / 3.8 GHz with AMD Radeon Vega 11 Graphics; 35-54W TDP System Memory – 2x DDR4-2400 SO-DIMM up to 16GB Storage – 1x M.2 Key M 2280 (SATA) and 1x M.2 Key M 2280 (NVMe) Video Output – 4x HDMI 2.0 ports up to 4K @ 60 Hz […]

August 25, 2018August 25, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Axiomtek SDM300S is an Intel Apollo Lake Smart Display Module (SDM-S) for Digital Signage

SDM300S Intel Smart Display Module (SDM)

Way back in 2010, Intel introduced the Open Pluggable Specification (OPS) defining mechanical and electrical parameters for players to be integrated into digital signage displays, with the goal of providing an easier upgrade path. Even if it was defined by Intel we’ve seem some Arm based OPS digital players such as the ones offered by ZidooLab. If you’ve checked out the latter link, you’ll know OPS players normally come with a case, and measure 180 x 119 x 30mm to comply with the specifications. But it turns out Intel also introduced a more compact card format for digital signage / displays with Intel SDM (Smart Display Module) available as SDM-S (Small: 60 mm x 100 mm x ~20 mm; up to ~10W TDP) or SDM-L (Large: 175 mm x 100 mm x ~20 mm; up to ~45W TDP) Axiomtek made one of those module with their SDM300S SDM-S module equipped with […]

July 17, 2018July 17, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Axiomtek eBOX560-900-FL Ubuntu 16.04 Fanless Embedded Computer is Powered by NVIDIA Jetson TX2 Module

Axiomtek has unveiled eBOX560-900-FL fanless embedded computer equipped with an NVIDIA Jetson TX2 module, two Gigabit Ethernet ports, a HDMI 2.0a port, an NVMe slot, etc. It also supports WiFi and LTE connectivity for gateway applications. The rugged computer runs Ubuntu 16.04, targets high performance AI workloads such as machine vision, deep learning, and edge computing, and comes with IP40 protection, vibration resistance, and -10 to 50°C temperature range support. Axiomtek eBOX560-900-FL specifications: SoM – NVIDIA Jetson TX2 module with SoC – NVIDIA TX2 hexa-core processor with 2x Denver cores, 4x Arm A57 cores, and a 256-CUDA core NVIDIA Pascal GPU System Memory – 8GB 128-bit LPDDR4 @ 1866 MHz Storage – 32GB eMMC flash Storage – 1x M.2 2280 M-Key slot w/ PCIe 2.0 x4 (supports M.2 NVMe SSD) Video Output – 1x HDMI 2.0 with 4K2K support Connectivity 2x 10/100/1000 Mbps Ethernet (NVIDIA + Intel I210-IT) 802.11ac WiFI […]

August 19, 2017 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Axiomtek NA362 Network Appliance Features Intel Atom C3538/C3758 Processors, Up to 10 LAN Ports

We reported about GIGABYTE MA10-ST0 motherboard powered by a 16-core Intel C3958 Denverton processor earlier this week, but that also corresponded to the official launch of Intel Denverton family, and many companies made announcements for their Denverton boards, products, or COM Express modules including SuperMicro, Kontron, Portwell, and others, such as Axiomtek NA362 Network Appliance powered by Atom C3538 or C3758 processors, and offering up to 10 LAN ports with six GbE RJ-45 ports, and up to four SFP+ cages. Axiomtek NA362 specifications: SoC (one or the other) Intel Atom C3538 quad core “Denverton” processor @ 2.10 GHz with 8MB cache; 15W TDP Intel Atom C3758 octa core “Denverton” processor @ 2.2 GHz with 16MB cache; 25W TDP System Memory – 2x or 4 x R-DIMM/U-DIMM non-buffer DDR4, up to 64/128GB Storage – 1x 2.5″ SATA3 HDD; 1x mSATA Ethernet 6x 10/100/1000 Mbps RJ45 ports via Intel i210 4x 10 GbE […]
