October 27, 2022October 27, 2022 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

WiFi HaLow IoT gateway is based on Morse Micro MM6108 802.11ah chip

Most WiFi HaLow hardware platforms we’ve seen so far are based on Newracom chips, but AsiaRF AP7688-WHM WiFi HaLow IoT gateway features a module based on Morse Micro MM6108 802.11ah SoC instead. The gateway is powered by a 580 MHz MediaTek MT7688 MIPS processor providing 802.11n WiFi 4 and dual Ethernet networking, and features a USB port as well as an RS232 console for industrial control. WiFi HaLow (802.11ah) enables video and data transmission at a range of up to one kilometer and data rates of up to 32.5 Mbps. AP7688-WHM WiFi HaLow gateway specifications: SoC – Mediatek MT7688 MIPS SoC @ 580 MHz with built-in WiFi 4 System Memory – TBD Storage – TBD Connectivity 2x Ethernet RJ45 ports 2.4 GHz WiFi 4 1T1R up to 150 Mbps; PCB antenna 850 to 950 MHz WiFi HaLow 1T1R up to 32.5Mbps @ 8 MHz bandwidth via Morse Micro MM6108 chip; […]

July 26, 2016July 26, 2016 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

AsiaRF AP7620-MPE-1 OpenWrt WiFi Router mini PCIe Card is Made for Computers and Embedded Systems

There are many mini PCIe WiFi modules on the market, but what AsiaRF provides with AP7620-MPE-1 is a little different, as it’s a router based on Mediatek MT7620A fitted into a mini PCIe card to be plugged inside a computer or embedded system. AP7620-MPE-1 mini PCIe card specifications: SoC – Mediatek MT7620A MIPS 24KEc CPU @ 580MHz with 2T2R WiFi 802.11 b/g/n (but board only supports 1×1) 802.11ac WiFI Chipset – Mediatek MT7612E AC1200 chipset limited to 433 Mbps [Changed to MT7610E chipset @ 433 Mbps] System Memory – 64 or 128MB DDR2 Storage – 8 or 16MB SPI flash WiFI features Security: 64/128-bit WEP, TKIP, WPA, WPA2, AES; 802.1X Authentication with RADIUS Client Multi-mode support: Access Point/Client mode Support Multiple SSIDs mini PCIe interface with USB2.0 to Ethernet, UART, 8 GPIOs, 1.5V, 3.3V and ground Dimensions – 60 x 41.5 mm (bigger than standard mini card: 50.95 x 30 […]

February 8, 2016February 16, 2016 by Jean-Luc Aufranc (CNXSoft) - 24 Comments

$98 Geek Force Mediatek MT7623 Router Board Features 6 GbE Ports, 3 mPCIe Slots for WiFi, 3G, or LTE (Crowdfunding)

We’ve seen a few interesting and relatively powerful router board launched last year, with the likes of MQMaker WiTi or Turris Omnia, AsiaRF has now designed Geek Force board powered by Mediatek MT7623N/MT7623A quad core network processor combined with 2GB RAM, six Gigabit Ethernet ports, and optional 802.11ac and 3G connectivity via the three mPCIe slots available on the board. The board also features two HDMI ports, and supports multimedia capabilities such as H.264, MPEG-2, or VC-1 hardware video decoding. Geek Force board preliminary specifications: SoC – MediaTek MT7623A or MT7623N quad-core ARM Cotex-A7 @ 1.3GHz with Mali-450MP GPU (MT7623N only) System Memory – 2GB DDR3 Storage – 2GB eMMC or NAND Flash + SD card slot up to 128 GB, and maybe SATA via the mPCIe slots Connectivity – 6 Gigabit Ethernet ports (WAN / LAN behavior defined by firmware), 802.11 b/g/n WiFi & Bluetooth 4.0 via MT6625L with […]

May 30, 2014May 30, 2014 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

AsiaRF AWM002 Wi-Fi Module and a Tiny IoT Server Kit Get Crowdfunded for $15 and Up

VoCore Wi-Fi module selling for $15 to $20, and it’s corresponding VoCore Dock with Ethernet has been quite popular, and at the time of writing, the project has already received $40,000 in funding with 50 more days to go. But if you’d rather get something for the same price, a few months early, and an already FCC/CE certified and proven module and tiny IoT server, AsiaRF has also launched a crowdfunding campaign for their AWM002 Wi-Fi module running OpenWRT on the same Ralink RT5350 found on the VoCore. as well as AWM002 Tiny Kit which adds Ethernet and USB, and a larger board with easier access to all ports and I/Os. As a reminder, let’s go through AWM002 specifications again: SoC – Mediatek/Ralink RT5350 MIPS 74KEc core @ 360 MHz dual band 802.11n Wi-Fi with data Rate up to 150Mbps, hardware NAT, QoS, TCP/UDP/IP checksum offloading. System Memory – 32 MB Storage […]

April 28, 2014May 1, 2014 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

$15 AsiaRF AWM002 & AWM003 Wi-Fi Modules Run OpenWRT, Expose GPIOs

This week-end I explained how to build a web server that could be used for automation and other Internet of things applications for less than $15 by combining an Arduino Leonardo with ECN18J60 Ethernet module. The hardware itself is cheap, but it may not always be convenient, or cost effective, to wire your house or office with Ethernet cables. One solution is to use Wi-Fi modules such as TI CC3000 evaluation module, an Electric Imp module, or Ariettea G25 + Wi-Fi board, but these usually cost between $30 to $50 in single quantity. AsiaRF AWM002 and AWM003 are low cost 802.11n Wi-Fi modules with access to GPIOs that could be an interesting alternative as they cost $15 + shipping, and even below $10 in quantities. The only difference between the two is that AWM003 supports more RAM (64MB vs 32MB). Here are the specifications for these modules: SoC – Mediatek/Ralink […]
