NanoPi NEO2 Development Board Powered by Allwinner H5 64-bit ARM Processor Sells for $15

NanoPi NEO is a cool little board, and I’ve been using it with Armbian as a 24/7 MQTT + Domoticz server for several weeks without any issues so far. FriendlyElec has now an update with NanoPi NEO2 featuring Allwinner H5 quad core Cortex A53 processor instead of Allwinner H3 Cortex A7 processor, a faster Gigabit Ethernet connection, and a new audio header. NanoPi NEO2 specifications: SoC – Allwinner H5 quad core Cortex A53 processor with an ARM Mali-450MP GPU System Memory – 512 MB DDR3 Storage – micro SD card slot Connectivity – Gigabit Ethernet (via RTL8211E-VB-CG chip) USB – 1x USB 2.0 host ports, 1x micro USB OTG port, 2x USB via headers Expansion headers 24-pin header with I2C, 2x UART, SPI, PWM, and power signals 12-pin header with 2x USB, IR pin, I2S 5-pin audio header with microphone and LINE out signals Debugging – 4-pin header for serial […]

March 13, 2017May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 29 Comments

$25 Orange Pi Win Development Board To Run Windows 10 IoT (and Linux, and Android)

Shenzhen Xunlong Software must already have over a dozen of Orange Pi boards, but this is not stopping them from launching more, and the company has just introduced Orange Pi Win, powered by Allwinner A64 processor, and beside supporting Linux and Android like other models, it’s rumored to run Windows 10 IoT too.Orange Pi Win specifications: SoC – Allwinner A64 quad core ARM Cortex A53 processor @ 1.2 GHz with Mali-400MP2 GPU System Memory – 1 GB DDR3 Storage – 2MB SPI flash, micro SD slot up to 64 GB, footprint for optional eMMC flash Video Output / Display interface – HDMI 1.4 up to 4K @ 30 Hz with CEC 3D and HDCP support,, MIPI LCD interface Audio – HDMI, 3.5 mm headphone jack, built-in microphone Connectivity – Gigabit Ethernet + 802.11 b/g/n WiFi & Bluetooth 4.2 (AP6212) USB – 4x USB 2.0 host ports, 1x micro USB OTG […]

January 21, 2017January 21, 2017 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

How to use Sonoff POW with ESPurna Firmware and Domoticz Home Automation System

Sonoff POW is an ESP8266 based wireless switch with a power meter that comes pre-loaded with a closed-source firmware that works with eWelink app for Android or iOS by default. But we’ve also seen Sonoff POW, and other Sonoff wireless switches from the same family, can be flash with open source firmware supporting MQTT (Message Queuing Telemetry Transport) lightweight messaging protocol such as ESPurna, and I initially sent data from Sonoff POW to ThingSpeak via an MQTT broker (mosquitto) to draw some pretty charts. I did that with the switch connected to a lightbulb, but I’ve since installed Sonoff POW in my office to measure the room’s power consumption minus the ceiling light and aircon as shown below. Sonoff cable mechanism is really a pain for hard copper wires, as they are hard to push inside the mechanism, and something come out. I finally managed by it took longer than […]

January 19, 2017January 19, 2017 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

How to Install Domoticz Home Automation System in NanoPi NEO and Other ARM Linux Boards

I’ve recently started experimenting with IoT projects, and the first hurdle is to select the hardware and software for your projects are there are simply so many options. For the hardware your first have to choose the communication protocols for your sensors and actuators, and if you are going to go with WiFi, ESP8266 is the obvious solution, used together with your favorite low cost Linux development board such as Raspberry Pi or Orange Pi to run some IoT server software locally or leveraging the cloud. But the most difficult & confusing part for me was to select the server software / cloud services as there are just so many options. I prefer having a local server than something running only in the cloud, as my Internet goes a few hours a month, so I started with a solution combining ThingSpeak with MQTT gathering data from Sonoff power switches running […]

December 28, 2016December 29, 2016 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

RetrOrangePi 3.0 Retro Gaming & Media Center Firmware Released for Orange Pi H3 Boards and Beelink X2 TV Box

RetrOrangePi is a Linux distribution based on armbian transforming Allwinner H3 boards – mostly Orange Pi boards, but also Banana Pi M2+ and NanoPi boards – into entertainment centers to play retro games, and watch/listen media files (videos/music) using Kodi. If you don’t have a development board, or would prefer a complete solution with casing and power supply, Beelink X2 TV box is also supported. The developers had been recently working on rectifying some GPL issues, and they have released RetrOrangePi 3.0 images right before Christmas. RetrOrangePi 3.0 changelog and key features: Full Armbian 5.23 Jessie Desktop version with kernel 3.4.113 (backdoors fixed) Slim version 1st release (less than 2 GB) coming soon OpenELEC (Kodi Jarvis 16.1) with CEC support by Jernej Škrabec RetroPie-Setup version 4.1 New Kodi Krypton beta6 version New emulationstation-ROPI branch forked from jacobfk20 with gridview, on screen keyboard with easy wifi config and storage check with […]

December 9, 2016 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

$59 RetroEngine Sigma Retro Game Console is Based on Orange Pi Lite Board (Crowdfunding)

2016 has been the year of retrogaming comeback with products like PocketCHIP, Nintendo NES Classic, GPD Win and quite a few other projects. There will soon be a new option with RetroEngine Sigma, an inexpensive Linux based retro-gaming console based on Allwinner H3 processor. RetroEngine Sigma fanless game console hardware specifications: SoC – Allwinner H3 quad core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 512 MB DDR3 Storage – 16 or 32GB micro SD card Video & Audio Output – HDMI port Connectivity – 802.11 b/g/n WiFi USB – 2x USB 2.0 host ports, 1x micro USB OTG port Misc – Programmable status LED, 2 user configurable buttons P1 & P2 Power Supply – 5V/2A via power barrel Dimensions – 110 x 85 x 33.5 mm The specifications look similar, so I went to my little list of Allwinner H3 […]

November 5, 2016November 5, 2016 by Jean-Luc Aufranc (CNXSoft) - 56 Comments

Orange Pi PC 2 Development Board based on Allwinner H5 SoC Launched for $20

Shenzhen Xunlong had already launched Orange Pi Zero, the cheapest ARM Linux board with networking you can find today, earlier this week, and I’ve just been informed the company has now listed the more powerful Orange Pi PC 2 board powered by Allwinner H5 quad core Cortex A53 processor on Aliexpress for $19.98 plus shipping.Orange Pi PC 2 specifications: SoC – Allwinner H5 quad core Cortex A53 processor with an ARM Mali-450MP4 GPU System Memory – 1GB DDR3 Storage – micro SD card slot up to 64GB, 8Mbit SPI NOR flash Video Output – HDMI 1.4 with CEC support, AV port Audio I/O – HDMI, AV port, on-board microphone Connectivity – Gigabit Ethernet USB – 3x USB 2.0 host ports, 1x micro USB OTG port Camera – MIPI CSI Interface Expansions – 40-pin Raspberry Pi compatible header Debugging – 3-pin UART header for serial console Misc – IR receiver; Power […]

November 2, 2016July 31, 2019 by Jean-Luc Aufranc (CNXSoft) - 80 Comments

Orange Pi Zero Allwinner H2+ Board with WiFi and Ethernet is Up for Sale for $7 and Up

Orange Pi Zero development board powered by Allwinner H2+ quad core Cortex A7 processor with 256 to 512MB RAM, Ethernet, and USB ports is now available for sale on Aliexpress for just $6.99, with shipping adding $3.39 in my case bringing the total to $10.38. Orange Pi Zero specifications: SoC – Allwinner H2(+) quad core Cortex A7 processor @ 1.2 GHz with Mali-400MP2 GPU @ 600 MHz System Memory – 256 to 512 MB DDR3-1866 SDRAM Storage – micro SD card slot Connectivity – 10/100M Ethernet + 802.11 b/g/n WiFi (Allwinner XR819 WiFi module) with u.FL antenna connector and external antenna USB – 1x USB 2.0 host ports, 1x micro USB OTG port Expansion headers – Unpopulated 26-pin “Raspberry Pi B+” header + 13-pin header with headphone, 2x USB 2.0, TV out, microphone and IR receiver signals Debugging – Unpopulated 3-pin header for serial console Misc – 2x LEDs Power […]
