October 8, 2021November 21, 2022 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Blues Wireless Swan board adds castellated holes to Adafruit Feather form factor

We’ve often written about Adafruit Feather-compatible boards in the past, but Blues Wireless Swan board is a little different, as the STM32L4-based board comes with castellated holes instead of just through holes which allows the board to expose up to 55 GPIOs, or 36 more pins than a traditional feather-compatible board. The company also introduced the “Feather Starter Kit for Swan” that enables the board to work with the company’s Notecard LTE Cat-M/NB-IoT M.2 modem that ships with 10-year (up to 500MB) of IoT connectivity, as well as GPS/GNSS connectivity. The Swan board Swan specifications: MCU – STMicro STM32L4R5 Arm Cortex-M4 microcontroller clocked at 120Mhz with 2MB of flash and 640KB of RAM USB – 1x Micro USB port for power and programming Castellated holes giving access to 55 GPIO including: 8x analog input 16x digital 4x I2C, 3x SPI 1x USB OTG full speed 1x 14-channel DMA 12-bit ADC, […]

October 8, 2021 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Chhavi – An ESP32-based fingerprint sensor with optional NFC, battery (Crowdfunding)

Chhavi is a compact, wireless, touch-capacitive fingerprint sensor based on ESP32 WiFi and Bluetooth SoC that is offered with optional NFC connectivity and a battery. The Arduino programmable fingerprint sensor is equipped with Fingerprints‘ FPC BM-Lite fingerprint capacitive biometric sensor that’s much more compact and power-efficient than traditional optical fingerprint sensors. Chhavi specifications: SiP – ESP32-PICO-D4 system-in-package with ESP32 dual-core processor @ 240 MHz, 4 MB SPI flash Fingerprint sensor FPC BM-LITE Module with 99% accurate fingerprint sensing Sensor matrix: 160 x 160 pixels Number of pixels: 25,600 pixels Active sensing area: 8 x 8 mm Features – Automatic finger detection, one-to-one verification mode Durability – 10 million finger placements Connectivity 2.4 GHz 802.11 b/g/n Wi-Fi via ESP32 Bluetooth BLE 4.2/5.x via ESP32 Optional 13.56 MHz NFC via NXP PN7150 NFC I2C controller 3D antenna Display – FPC connector for display USB – 1x Micro USB port for power/charging, and […]

October 6, 2021 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Portenta H7 Lite Connected brings back WiFi & Bluetooth

Arduino has launched another Arduino Pro board! Well, sort of. Let’s not get too excited. The Portenta H7 Lite Connected is based on last month’s Portenta H7 Lite that itself was a cost-optimized version of Portenta H7 board without a wireless module, USB-C video output, and only fitted with the lower cost Microchip ATECC608 secure element. Portenta H7 Lite Connected is exactly the same board, except it brings back the Murata 1DX module with 2.4GHz 802.11b/g/n WiFI 4 and Bluetooth 5.1 BR/EDR/LE connectivity, plus the related u.FL antenna connector. Portenta H7 Lite Connected specifications: Microcontroller – STMicro STM32H747XI Cortex-M7 @ 480 MHz + M4 @ 200 MHz MCU with 2MB dual-bank Flash memory, 1 MB RAM, Chrom-ART graphical hardware accelerator System Memory – 2MB SDRAM (upgradeable up to 64MB) Storage – 16MB QSPI NOR Flash (Upgradeable up to 128MB) Connectivity 2.4GHz WiFi 802.11b/g/n up to 65 Mbps and Bluetooth 5.1 […]

October 4, 2021June 1, 2022 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

UDOO KEY ESP32 & RP2040 board launched for $4 (Crowdfunding)

UDOO is known for its x86 boards that embed an Arduino compatible MCU, but the UDOO KEY is different, as it does without an Intel or AMD processor, and instead, combines Raspberry Pi RP2040 microcontroller with Espressif ESP32 WiFi & Bluetooth WiSoC. As we noted in the past combining Raspberry Pi Pico/RP2040 with ESP32 does not make a lot of sense in most cases, but here’s the UDOO KEY will be offered for just $4 for the first 1,000 units, so they’ll basically throw the ESP32 for free since it’s the same price as one Raspberry Pi Pico, before eventually selling the device for $20. UDOO KEY specifications: MCU- Raspberry Pi RP2040 dual-core Arm Cortex-M0+ microcontroller @ 133 MHz with 264KB of on-chip SRAM Storage – 8MB QSPI Flash for RP2040 Wireless module – ESP32-WROVER-E with ESP32-D0WD-V3 dual-core WiFi + Bluetooth SoC, 16MB SPI flash, and 8MB PSRAM Sensor – […]

October 4, 2021October 15, 2021 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Build a LoRaWAN weighing scale with TTGO T-Weigh ESP32 board, HX711 modules

Ever wanted to build your own LoRaWAN connected weighing scale? Me neither, but apparently those types of products already exist for logistics and inventory management, and LilyGO’s latest ESP32 board – the TTGO T-Weigh – is designed for this exact purpose with a Semtech SX1272 based LoRa module, and four HX711 24-bit ADC chips. The board can handle up to four scales that transfer weight data over WiFi, Bluetooth or LoRaWAN, and should be useful in applications that require weighting goods or products where there are limited connectivity options including logistics, farming. TTGO T-Weigh specifications: Wireless modules TTGO T-Micro32 module based on ESP32-PICO-D4 SiP with ESP32 dual-core processor, 4MB SPI flash, 2.4 GHz WiFi 4 and Bluetooth 4.2/5.x TTGO LORA32 module based on Semtech SX1262 transceiver (EU868/US915)with -22 dBm Tx power, -148 dBm sensitivity, up to 62.5 kbps LoRa bitrate, up to 300 kbps FSK bitrate Antennas WiFi/Bluetooth – Ceramic […]

September 30, 2021September 30, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

M5Stack TOUGH – A weatherproof ESP32 Industrial IoT controller

M5Stack TOUGH weatherproof ESP32 display

M5Stack has launched several ESP32 WiFi & BLuetooth IoT controllers with an integrated display such as M5Stack Core2. The latest model, M5Stack TOUGH, is a little different as it is rugged and waterproof/weatherproof with a UV resistant enclosure sealed with o-ring, and offering waterproof M12 connectors. With protection against solid objects, dust, sand, dirt, and water drops, as well as variety of installation options such as screw mount, rolled strip, magnetic and adhesive back, the M5Stack TOUGH is suitable for more demanding environments from kitchens to factory floors, and outdoor data acquisition. M5Stack TOUGH specifications: SoC – Espressif ESP32-D0WDQ6-V3 dual-core processor @ 240 MHz with 520 KB, 2.4 GHz WiFi, and dual-mode Bluetooth Extra RAM – 8MB PSRAM Storage – 16MB Flash, MicroSD card slot up to 16GB Display – 2-inch color LCD with multi-touch capacitive screen, 320×240 resolution, 853nit brightness; ILI9342C display driver and CHSC6540 chip Audio – NS4168 […]

September 29, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Nicla Sense ME – Arduino PRO meets Bosch SensorTech’s motion and environmental sensors

Arduino is going full steam ahead with its Arduino PRO family of boards for industrial applications. After the announcement of the Portenta H7 Lite board earlier this month, the company has now introduced the Arduino Nicla Sense ME designed in collaboration with Bosch Sensortec. The Nicla Sense ME (Motion & Environment) board comes with a range of Bosch Sensortec sensors notably a 9DoF smart motion sensor and a 4DoF environmental sensor with AI capabilities, and targets industrial IoT applications either for research projects, rapid prototyping, or commercial products. Arduino Nicla Sense ME specifications: MCU – Nordic Semi nRF52832 Cortex-M4 microcontroller @ 64 MHz with 512KB Flash, 64KB RAM, Bluetooth 4.2/5.0 LE connectivity (via U-blox ANNA B112 module) Storage – 2MB SPI flash for storage; 2MB QSPI dedicated for BHI260AP Sensors BHI260AP motion sensor system with integrated AI, “Fuser 2” 32-bit Synopsys DesignWare ARC EM4 core with RISC FPU BMM150 magnetometer […]

September 15, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

LOLIN S2 Pico – A compact ESP32-S2 board with an OLED display

If you’re into small MCU boards with an integrated display, you’re in luck as LOLIN launched the S2 Pico board with ESP32-S2 and an OLED display about at the time same as LILYGO T-Display RP2040 board we covered yesterday. Wemos/LOLIN S2 Pico board offers WiFi connectivity, a 128×32 OLED display, USB Type-C port for power and programming, as well as the usual GPIO headers in a compact 50×23 mm form factor. LOLIN S2 Pico specifications: SoC – Espressif Systems ESP32-S2FN4R2 single-core Xtensa LX7 processor with 4MB flash, 2MB PSRAM, and WIFI connectivity only, i.e.no Bluetooth support Display – 128×32 OLED display based on SSD1306 driver USB – USB Type-C port for power and programming Expansion 16-pin + 8-pin headers with 21x GPIO with interrupt/PWM support, ADC, DAC, I2C, SPI, UART, USB OTG 4-pin I2C connector Misc – Reset and user buttons Power Supply – 5V via USB-C port Dimensions – […]
