alder lake

Posted on by Debashis Das - No Comments on DFI RPS101/RPS103 mini-ITX motherboards support 12th-14th Gen Intel processors, quad 4K displays, dual 2.5GbE

DFI RPS101/RPS103 mini-ITX motherboards support 12th-14th Gen Intel processors, quad 4K displays, dual 2.5GbE

DFI RPS101 or RPS103 Mini-ITX motherboard with up to 14th Gen Raptor Lake-S Refresh processor.

DFI has recently launched the RPS101/RPS103 industrial mini-ITX motherboards compatible with 14th/13th/12th Gen Intel Core processors and equipped with R680E, Q670E, or H610E chipset. They also support up to 64GB of DDR5 memory and offer various connectivity and management features including support for up to four independent 4K displays, two Intel 2.5GbE ports, and an integrated DFI M2-OOB module. These features are designed to meet the demands of factory automation and kiosk applications, and the company claims its latest mini-ITX motherboards are ideal for businesses that need to reduce TCO and accelerate AI adoption. RPS101/RPS103 mini-ITX motherboards’ specifications CPU options LGA 1700 Socket  (one or the other) 14th Gen Raptor Lake-S Refresh  – Intel 300T dual-core to Intel Core i9-14900 24-core 13th Gen Raptor Lake-S – Intel G6900TE dual-core to Intel Core i9-13900 24-core 12th Gen Alder Lake-S – Intel G6900TE dual-core to Intel Core i9-12900 16-core Graphics Intel HD […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on iKOOLCORE R2 Max Alder Lake-N mini PC/server features two 10GbE and two 2.5GbE ports

iKOOLCORE R2 Max Alder Lake-N mini PC/server features two 10GbE and two 2.5GbE ports

iKOOLCORE R2 Max

The iKOOLCORE R2 Max is an Alder Lake-N-powered firewall/gateway/server/mini PC that is offered with either an Intel Processor N100 or Core i3-N305 CPU, and equipped with two 10GbE ports and two 2.5GbE ports. It builds upon the iKOOLCORE R2 mini PC and router which we reviewed with Promox VE, Ubuntu 22.04, and pfSense and features four 2.5GbE ports in a smaller form factor. The new R2 Max model uses the N100/Core i3-N305 CPU instead of the N95/Core i3-N300, supports up to 48GB SO-DIMM memory, features a wider yet thinner design, and provides support for both 10GbE and 2.5GbE networking. iKOOCORE R2 Max specifications: Alder Lake-N SoC Intel Processor N100 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics; TDP: 6W Intel Core i3-N305 octa-core processor @ up to 3.8 GHz (Turbo) with 6MB cache, 32EU Intel UHD Graphics; TDP: 15W System Memory – 8GB, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on MINIX NEO Z300-0dB fanless mini PC features Intel Core i3-N300 8-core CPU

MINIX NEO Z300-0dB fanless mini PC features Intel Core i3-N300 8-core CPU

MINIX NEO Z300-0dB

MINIX NEO Z300-0dB is a fanless mini PC powered by an Intel Core i3-N300 octa-core Alder Lake-N CPU with 16GB DDR4 and up to a 512GB NVMe SSD. It built upon the MINIX NEO Z100-0dB that we reviewed with both Windows 11 and Ubuntu 22.04 and performed well albeit not quite as fast as some actively-cooled models. The NEO Z300-0dB brings a faster Core i3-N300 octa-core processor and from what I can see from the specs below, the other features remain the same. MINIX NEO Z300-0dB specifications: SoC – Intel Core i3-N300 octa-core Alder Lake-N processor @ up to 3.8 GHz (Turbo) with 6MB cache, 32EU Intel UHD Graphics; TDP: 7W System Memory – 4GB, 8GB, or 16GB DDDR4-3200 SO-DIMM memory, upgradable to 32GB Storage 128GB, 256GB, or 512GB M.2 SSD (PCIe Gen3 x4), upgradable up to 4TB (compatible with SATA SSD too) MicroSD card slot Video Output 2x HDMI […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Intel Processor N50 or N97 touch Panel PCs feature 7-inch or 10-inch TFT color display

Intel Processor N50 or N97 touch Panel PCs feature 7-inch or 10-inch TFT color display

Intel N50 or N97 Panel PC 10-inch display

AAEON ACP-2106 and ACP-2076 are two fanless touch panel PCs powered by an Intel N50 or N97 Alder Lake-N processor with respectively 10-inch (1280 x 800) and 7-inch (1024×600) color TFT LCD displays with capacitive multi-touch support. Both models share the same key specifications with support for up to 32GB DDR5 SO-DIMM memory and a mPCIe socket for storage. They feature an HDMI 1.4 for dual display configuration for kiosks or other similar applications, two 2.5GbE ports, M.2 sockets for WiFi and 4G LTE/5G cellular connectivity, and more. AAEON ACP-2106 and ACP-2076 specifications: Alder Lake-N SoC (one or the other) Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics; TDP: 12W Note: Turbo Mode is disabled by default. If enabling it, please ensure the system […]

Posted on by Debashis Das - No Comments on GIGAIPC QBiX-ADNAN97-A1 fanless industrial PC features Intel N97 CPU, dual HDMI, dual LAN

GIGAIPC QBiX-ADNAN97-A1 fanless industrial PC features Intel N97 CPU, dual HDMI, dual LAN

GIGAIPC QBiX ADNAN97 A1 industrial PC

GIGAIPC QBiX-ADNAN97-A1 industrial PC is a compact system, powered by the Intel Processor N97 quad-core Alder Lake-N processor. This industrial PC supports up to 16GB of DDR5 memory and features flexible storage options with an M.2 slot for SATA or NVMe drives. Additionally, the QBiX-ADNAN97-A1 supports dual independent displays via two HDMI ports, It also offers dual Gigabit Ethernet, multiple USB 3.2 Gen 2×1 ports, an M.2 E-Key for Wi-Fi/Bluetooth expansion, and a COM port for legacy device connectivity. Designed for reliable operation, this fanless system is ideal for various Industry 4.0 applications, including industrial automation, digital signage, and edge computing. QBiX-ADNAN97-A1 industrial PC specifications SoC – Intel Processor N97 quad-core Alder Lake-N processor @ up to 3.6 GHz with 6MB Cache, Intel UHD Graphics; 12W TDP System Memory – Up to 16GB DDR5 4800 MHz via SODIMM slot Storage – M.2 2280 M-Key socket for NVMe or SATA storage Display 2x HDMI 2.0 […]

Posted on by Debashis Das - No Comments on Jetway JPIC-ADN1 fanless, industrial Pico-ITX SBC features Intel N97 or N200 CPU, dual display support

Jetway JPIC-ADN1 fanless, industrial Pico-ITX SBC features Intel N97 or N200 CPU, dual display support

Jetway JPIC ADN1 Pico ITX SBC

Jetway JPIC-ADN1 is a fanless pico-ITX SBC powered by an Intel N97 or N200 Alder Lake-N processor and targeted at industrial robotics applications. The JPIC-ADN1 supports up to 32GB of memory via a single-channel SO-DIMM slot. The SoC comes with UHD Graphics, supporting dual-display outputs via HDMI 2.0b and a 24-bit dual-channel LVDS interface. For storage, it features an M.2 B+M-Key socket and a SATA 3 port, plus an E-Key 2230 socket for wireless expansion. Gigabit Ethernet networking is handled by the RTL8111H GbE controller. Additionally, it has a serial header, 8-bit GPIO, SMBUS, watchdog timer, and much more. JPIC-ADN1 fanless SBC specification Alder Lake-N SoC (one or the other) Intel Processor N97 quad-core Alder Lake N-series processor with Intel UHD graphics; 12W TDP Intel Processor N200 quad-core processor @ up to 3.7 GHz (Turbo) with 6MB cache, 32EU Intel HD graphics @ up to 750 MHz; TDP: 6W Additional compatible CPUs available via regional sales […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 19 Comments on Radxa X4 review – An Intel N100 alternative to Raspberry Pi 5 tested with Ubuntu 24.04

Radxa X4 review – An Intel N100 alternative to Raspberry Pi 5 tested with Ubuntu 24.04

Radxa X4 Ubuntu 24.04 review

We already looked at the Radxa X4 kit featuring an Intel N100 SBC with a design similar to the Raspberry Pi 5 and accessories including a Radxa Power PD 30W power adapter, an NVMe SSD, and a USB-C to USB-C cable, in the first part of the review, before installing Ubuntu 24.04 on the board.

In the second part of the review, we will test Ubuntu 24.04 in more detail with some benchmarks and power consumption measurements to show how well it works (or not) compared to a Raspberry Pi 5. We will also test the 40-pin GPIO header on the Radxa X4 controlled through a Raspberry Pi RP2040 microcontroller.

Posted on by Debashis Das - No Comments on ADLINK AVA-1000 is a rugged EN50155-compliant T2G gateway for railway and industrial applications

ADLINK AVA-1000 is a rugged EN50155-compliant T2G gateway for railway and industrial applications

ADLINK AVA 1000 T2G gateway top view

The ADLINK AVA-1000 T2G gateway is a rugged, EN50155-compliant T2G (Train-to-Ground) gateway designed for railway and industrial environments. Powered by a choice of NXP i.MX8M Plus Quad Cortex-A53 processor or an Intel Processor N50 Alder Lake-N processor. The i.MX8M Plus model is equipped with up to 8GB LPDDR4 and a 64GB eMMC flash whereas the Alder Lake variant features up to 4GB LPDDR5 memory and a 32GB eMMC flash. In terms of connectivity, the gateway features three M12 GbE ports and supports a wide range of options including 5G, WiFi 6, and GNSS. The AVA-1000 T2G gateway’s fanless design, wide operating temperature range, and 24-110V DC input ensure reliable operation in industrial environments. Additionally, its compliance with EN50155 and other industrial standards makes it ideal for various industrial applications. AVA-1000 T2G gateway specifications System Processor (multiple options) NXP i.MX8M Plus quad-core Cortex-A53 processor @ up to 1.8 GHz with Cortex-M7 […]
