advantech News - CNX Software - Embedded Systems News

April 4, 2024April 4, 2024 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

AMD Ryzen Embedded 8000 Series processors target industrial AI with 16 TOPS NPU

AMD has recently “announced” the Ryzen Embedded 8000 Series processors in a community post with the latest AMD embedded devices combining a 16 TOPS NPU based on the AMD XDNA architecture with CPU and GPU elements for a total of 39 TOPS designed for industrial artificial intelligence. The Ryzen Embedded 8000 CPUs will be found in machine vision, robotics, and industrial automation applications to enhance the quality control and inspection processes, enable real-time, route-planning decisions on-device for minimal latency, and predictive maintenance, and autonomous control of industrial processes. AMD Ryzen Embedded 8000 key features and shared specifications: CPU – Up to 8 “Zen 4” cores, 16 threads Cache L1 Instruction Cache – 32 KB, L1 Data Cache = 32 KB (per core) L2 Cache – Up to 8 MB (total) L3 Cache- Up to 16 MB unified Graphics – RDNA 3 graphics with up to 6 WGPs (Work Group processors) […]

August 4, 2022 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

AMD Ryzen Embedded 5000 Series CPUs show up in Micro-ATX motherboard

AMD Ryzen Embedded 5000 Series motherboard

Advantech has announced the AIMB-522 industrial Micro-ATX motherboard with AMD Ryzen Embedded 5000 Series Zen3 processors for AI image processing in automation and surveillance applications. I had never heard about “Ryzen Embedded 5000 Series” processors, but that motherboard comes with a choice of new SKUs such as the 12-core Ryzen 5950E, the 10-core Ryzen 5900E, the 8-core Ryzen 5800E, and the 6-core Ryzen 5600E, as well as existing Ryzen 5000 desktop processors. AIMB-522 Micro-ATX motherboard specifications: Processor (one or the other) Ryzen 5950E 12-core processor @ up to 3.4 GHz with 64MB L3 cache; TDP: 105W Ryzen 5900E 10-core processor @ up to 3.7 GHz with 64MB L3 cache; TDP: 105W Ryzen 5800E 8-core processor @ up to 3.7 GHz with 32MB L3 cache; TDP: 100W Ryzen 5600E 6-core processor @ up to 3.6 GHz with 32MB L3 cache; TDP: 65W Ryzen 5950X 16-core processor @ up to 3.4 GHz […]

June 21, 2022June 22, 2022 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

AMD unveils Ryzen Embedded R2000 Series processors with up to four cores, quad-display support

As expected, AMD has now launched the Ryzen Embedded R2000 series processors that build up on the earlier Ryzen Embedded R1000 family, but doubles the number of cores to up to four, gets improved Radeon graphics, and adds support for Windows 11 operating system. Performance and efficiency have also improved with the new Ryzen Embedded R2514 CPU exhibiting up to 81 percent higher CPU (Passmark v10) and graphics (3DMark) performance compared to Ryzen Embedded R1606G processor, as well as higher performance-per-watt efficiency thanks to the Zen+ core architecture. The company has four Ryzen Embedded R2000 processors in its portfolio at launch. Key features and specifications include: Memory – 2,400 to 3,200 MT/s (depending on SKU) DDR4 dual-channel memory support Storage – 2x SATA 3.0, NVMe support 16 lanes of PCIe Gen3, except for R2312 limited to just 8 lanes Up to four independent 4Kp60 displays using DisplayPort 1.4, HDMI 2.0b, […]

March 9, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

NXP i.MX 8M Plus 2.5-inch Pico-ITX SBC supports UIO40-Express expansion modules

With NXP i.MX 8M Plus AI processor nearing mass production, we’ve seen many companies introduce i.MX 8M Plus systems-on-module at Embedded World 2021. But as one would come to expect, there should also be single board computers based on the new processor, and Advantech has unveiled the RSB-3720 2.5-inch SBC (aka Pico-ITX SBC) compatible with the company’s UIO40-Express expansion boards. RSB-3720 specifications: SoC – NXP i.MX8M Plus dual or quad-core Arm Cortex-A53 processor up to 1.8GHz (1.6 GHz for industrial temperature range) with Cortex-M7 real-time core, Vivante GC7000UL 3D GPU, 1080p60 H.265/H.264/VP9 decoder, 1080p60 H.265/H.264 encoder, 2.3 TOP/s Neural Network Accelerator System Memory – 4GB or 6GB LPDDR4 4000MT/s Storage – 16 GB eMMC Flash for OS, 8 MB QSPI NOR Flash for board information, microSD socket Video Output – HDMI 2.0a up to 3840 x 2160 at 30Hz Single or dual-channel 24 Bit LVDS with backlight power, 5/12V, Max. […]

February 23, 2021February 23, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Advantech Elkhart Lake mini-ITX motherboard offers triple display support, dual LAN, eight USB and six COM ports

We’ve seen a fair amount of Intel Elkhart Lake platforms including modules, 3.5-inch SBCs, Pico-ITX boards, and embedded mini PCs, but so far, I had not noticed any Elkhart Lake mini-ITX motherboard. Advantech AIMB-218 motherboard offers a choice of low-power Atom, Celeron and Pentium Elkhart Processor, and thanks to the larger form factor plenty of I/Os including four display interfaces (DP++/HDMI/eDP/LVDS) supporting up to three display, eight USB port, six serial COM port, and dual Gigabit Ethernet. Advantech AIMB-218 specifications: SoC (one or the other) – Intel Atom x6413E quad-core processor @ 1.50 GHz / 3.0 GHz (Turbo) with 16EU Intel UHD graphics; 9W TDP Intel Celeron N6211 dual-core processor @ 1.20 GHz / 3.0 GHz with 16EU Intel UHD graphics; 6.5W TDP Intel Celeron J6413 quad-core processor @ 1.80 GHz / 3.0 GHz with 16EU Intel UHD graphics; 10W TDP Intel Pentium J6426 (new part) quad-core 2.0 GHz / […]

August 21, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Whiskey Lake Thin Mini ITX SBC Features Eight USB Interfaces, Dual SATA, Dual GbE, and More

Advantech AIMB-233 thin mini-ITX SBC is equipped with a choice of 15W Intel Whiskey Lake processors, supporting up to 32GB RAM, and offering plenty of high speed I/Os include eight USB interfaces, two SATA III ports, dual Gigabit Ethernet, several PCIe & M.2 expansion slots, as well as triple display support, six COM ports, and more. The motherboard complies with the “thin mini-ITX” requirement of not exceeding 2.5cm in height, and Advantech expects the thin Mini-ITX SBC to be found in nursing carts, patient care systems, Human-Machine Interfaces (HMI), and mobile devices. AIMB-233 thin mini-ITX SBC specifications: SoC (One or the other) Intel Core i7-8665UE quad-core/octa-thread processor @ up to 1.7 / 4.4 GHz with Intel UHD Graphics 620 – 15W TDP Intel Core i5-8365UE quad-core/octa-thread processor @ up to 1.6 / 4.1 GHz with Intel UHD Graphics 620 – 15W TDP Intel Core i3-8145UE dual-core/quad-thread processor @ up to […]

July 3, 2020July 4, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Advantech UNO-220 is an Industrial RS232/RS485 Gateway Kit for Raspberry Pi 4

RS232 & RS485 Raspberry Pi 4 Gateway Kit

While Raspberry Pi SBCs are mostly designed for the education market, they find their way in various devices, even in the industrial market with products such as ModBerry M500 industrial computer, Compulab IOT-GATE-RPi industrial IoT computer, BB-400 Neuron Edge industrial controller, and many others. All those offer RS-232 and RS-485 ports besides other interfaces typically found in industrial applications like isolated inputs, CAN buses, and more. There’s now yet another option with Advantech UNO-200 industrial gateway kit for Raspberry Pi 4 board with RS232/RS485 header and RTC battery. Advantech UNO-220 specifications: Compatible SBC – Raspberry Pi 4 Model B with dual micro HDMI outputs, audio jack, as well as USB and Ethernet ports accessible through the enclosure I/O Interfaces GPIO – Input (GPI) 0-3: VIH: 2~5V VIL: 0 ~ 0.8V; Output (GPO) 0-3: 0 ~ 5V Serial Ports – 5-pin terminal block for RS232/485, automatic direction control, 300 ~ 115.2kbps […]

May 22, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Advantech Edge AI Computer and PoE NVR Feature NVIDIA Jetson Xavier NX SoM

Advantech NVIDIA-Jetson-Xavier NX Edge AI Computer

Following the launch of NVIDIA Jetson Xavier NX SoM last year, we noted several third-party carrier boards and embedded PCs had been announced, and we expected more to come soon. Advantech has now unveiled two systems based on NVIDIA latest module with respectively MIC-710AIX edge AI computer and MIC-710IVX NVR system equipped with eight PoE ports. MIC-710AIX edge AI computer Specifications: SoM – NVIDIA Jetson Xavier NX with 6-core NVIDIA Carmel ARM v8.2 64-bit CPU, 6MB L2 + 4MB L3 caches 384-core NVIDIA Volta GPU with 48 Tensor Cores 2x NVDLA deep learning accelerators System Memory – 8GB 128-bit LPDDR4x Storage – 16 GB eMMC 5.1 flash Storage – M.2 2280 Key-M socket for SSD; SD card socket Video Output – HDMI up to 3840×2160 @ 60 Hz Networking – 2x Gigabit Ethernet (RJ45) via Intel i210IT controller USB – 1x USB 3.0 host port, 1x USB 2.0 host port, […]
