January 18, 2024January 17, 2024 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Raspberry Pi 5 industrial HMI displays gain M.2 NVMe SSD, RS232/RS485 interfaces, audio input/output jacks

Raspberry Pi 5 industrial HMI with RS232/RS485 audio input/output jacks

EDATEC ED-HMI3020 is a family of Raspberry Pi 5-based industrial HMI displays that build upon the earlier ED-HMI3010 panel PCs by adding an M.2 socket for NVMe SSD, RS232 and RS485 interfaces, as well as 3.5mm audio input and output jacks. The new models are still offered with either a 7-inch (1024×600) or 10.1-inch (1200×800) touchscreen display, a Raspberry Pi 5 with 4GB or 8GB RAM with all main ports (HDMI, Ethernet, USB) accessible externally, and support for an optional 8MP front-facing camera. ED-HMI3020 specifications with differences again ED-HMI3010 highlighted in bold or strikethrough: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage MicroSD card socket M.2 […]

December 23, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

EDATEC ED-IPC3020 – A fanless Raspberry Pi 5 industrial computer with an M.2 NVMe SSD, RS485/RS232 interfaces

EDATEC ED-IPC3020 Raspberry Pi 5 industrial computer

EDATEC ED-IPC3020 is a fanless industrial computer based on the Raspberry Pi 5 SBC with support for an M.2 NVMe SSD up to 2260 in size, RS232 and RS485 serial ports, and stereo audio input and output jacks. The Raspberry Pi 5 single board computer could already support an M.2 NVMe SSD thanks to add-on boards such as the PineBerry Pi HatDrive and Pimoroni NVMe Base, but with the ED-IPC3020 we have a complete Raspberry Pi 5-powered computer with M.2 NVMe storage. EDATEC ED-IPC3020 specifications: SBC – Raspberry Pi 5 Model B SoC – Broadcom BCM2712 quad-core Arm Cortex-A76 processor clocked up to 2.4 GHz, VideoCore VI GPU, 4Kp60 H.265 decoder Memory – 4GB and 8GB LPDDR4X-4267 SDRAM are optional Storage – MicroSD card slot for the OS Video Output – 2x micro HDMI ports up to 4Kp60 Networking Gigabit Ethernet RJ45 port with optional PoE support Dual-band 802.11ac Wi-Fi […]

November 24, 2023January 17, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

7-inch and 10.1-inch industrial panel PCs feature Raspberry Pi 5 SBC

After introducing several Raspberry Pi CM4-based panel PCs over the years, EDATEC has launched its first industrial panel PCs based on the Raspberry Pi 5 SBC with the HMI3010-070C and HMI3010-101C equipped respectively with a 7-inch and 10.1-inch touchscreen display. Both HMI displays expose most I/Os and features from the Raspberry Pi 5 including the two micro HDMI ports, the USB-C port for power, the four USB Type-A connectors, and the gigabit Ethernet RJ45 jack. The company also offers an 8MP front-facing camera and/or PoE as options. EDATEC HMI3010 specifications: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage – Optional 32GB or 64GB MicroSD card Display […]

October 27, 2023March 26, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

EDATEC ED-HMI2120-101C is a Raspberry Pi CM4-based industrial panel PC with a 10.1-inch capacitive touchscreen display with plenty of interfaces to cater to a wide range of use cases from robotics to energy management and industrial automation. The panel PC builds upon the ED-HMI2020-101C introduced just a few months ago, but adds a range of features with dual Ethernet, RS485 and RS232 interfaces, and optional supports for an M.2 NVMe SSD and 4G LTE cellular connectivity. The device now supports an even wider DC input range from 9V to 36V and provides three 12V DC outputs to power external hardware such as an additional LCD. ED-HMI2120-101C specifications (with highlights in bold and strikethrough showing the differences against the earlier ED-HMI2020-101C model): System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 […]

September 24, 2023December 11, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

EDATEC ED-IPC2100 industrial computer offers 4x RS485/RS232 ports

EDATEC ED-IPC2100 industrial computer with RS485 and RS232 ports

EDATEC has launched four more Raspberry Pi CM4-powered industrial computers with the ED-IPC2100 Series that mostly differ from the earlier ED-IPC2010 model with an extra M.2 Key-B socket for an SSD, an extra 10/100Mbps Ethernet port, and four COM ports with RS232 or RS485 interfaces depending on the exact model. The new ED-IPC2100 series industrial computer family ships with a Raspberry Pi Compute Module 4 with up to 8GB RAM, 32GB flash, optional WiFi 5 and Bluetooth 5.0, and offers a full-size HDMI video output, two Ethernet ports, and a few USB ports. The ED-IPC2120 model looks to offer some extra features such as an HDMI Touch FPC connector, MIPI CSI camera and DSI display connectors, and audio interfaces. ED-IPC2100-series specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz with VideoCore VI GPU System Memory – 1GB, 2GB, 4GB, or 8GB LPDRR4-3200 RAM Storage […]

August 10, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Raspberry Pi CM4-powered outdoor gateway supports GbE, WiFi 5, Bluetooth 5.0, 4G LTE, LoRaWAN, and GPS connectivity

EDATEC ED-GWL2110 is an IP24-rated outdoor gateway based on Raspberry Pi CM4 and supporting Gigabit Ethernet, WiFi 5, Bluetooth 5.0, 4G LTE cellular, LoRaWAN, and GPS connectivity, as well as Power over Ethernet (PoE). The weatherproof gateway also comes with two microSD cards for the OS (CM4 Lite) and data, an HDMI 2.0 output port, a serial console, and features such as an RTC with backup battery, a watchdog, an ATECC608 secure element, and a user-programmable RGB LED. EDATEC ED-GWL2110 specifications: SoM – Raspberry Pi Compute Module 4 SoC – Broadcom BCM2711 quad-core Arm Cortex-A72 processor @ up to 1.5GHz with VideoCore VI GPU System Memory – 1GB, 2GB, 4GB, or 8GB RAM Storage – Optional 8GB, 16GB, or 32GB eMMC flash Wireless – Optional WiFi 5 and Bluetooth 5.0 Storage – Dual micro SD card slot for OS (Raspberry Pi CM4 Lite) and data Video Output – 1x HDMI […]

May 12, 2023September 23, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

EDATEC ED-IPC2010 – A compact DIN Rail mountable industrial computer based on Raspberry Pi CM4

DIN Rail Raspberry Pi CM4 industrial computer

EDATEC has launched yet another Raspberry Pi CM4-powered industrial computer with the ED-IPC2010 offering a more compact design than the company’s CM4 Industrial and CM4 Sensing models, and an aluminum alloy enclosure that can easily be mounted to a DIN Rail. Most of the specifications of the new ED-IPC2010 are pretty common with a choice of Raspberry Pi Compute Modules 4 with up to 8GB RAM, 32GB flash, and optional WiFi 5 and Bluetooth 5.0, as well as a full-size HDMI video output, a Gigabit Ethernet port, and a few USB ports. What’s a little different is one FPC connector on the mainboard with both HDMI and USB for touchscreen displays. ED-IPC2010 specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz with VideoCore VI GPU System Memory – 1GB, 2GB, 4GB, or 8GB RAM Storage – 8GB, 16GB, or 32GB eMMC flash Wireless – […]

April 10, 2023March 13, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

IP67-rated CM4 AI camera uses Raspberry Pi Compute Module 4 for computer vision applications

EDATEC ED-AIC2020 is an IP67-rated, Raspberry Pi CM4-based industrial AI camera equipped with a fixed or liquid lens and LED illumination that leverages the Raspberry Pi Compute Module 4 to run computer vision applications using OpenCV, Python, And Qt. We’ve previously written about Raspberry Pi Compute Module-based smart cameras such as the Q-Wave Systems EagleEye camera (CM3+) working with OpenCV and LabVIEW NI Vision and the StereoPi v2 (CM4) with stereo vision. But the EDATEC ED-AIC2000 is the first ready-to-deploy Raspberry Pi CM4 AI camera we’ve covered so far. EDATEC “CM4 AI camera” (ED-AIC2020) specifications: SoM – Raspberry Pi Compute Module 4 up to 8GB RAM, up to 32GB eMMC flash Camera 2.0MP global shutter or 5.0MP rolling shutter Acquisition rate – Up to 70 FPS Aiming point – Red cross laser Built-in LED illumination (optional) Scanning field Electronic liquid lens Fixed focal length lens Networking Gigabit Ethernet M12 port Communication protocols – Ethernet/IP, PROFINET, Modbus […]
