EDATEC

Posted on by Sayantan Nandy - 1 Comment on EDATEC ED-GWL1010: Amlogic S905X4-based PoE-enabled LoRaWAN gateway targets Smart Buildings and IoT applications

EDATEC ED-GWL1010: Amlogic S905X4-based PoE-enabled LoRaWAN gateway targets Smart Buildings and IoT applications

ED-GWL1010 LoRaWAN gateway

The AMLogic S905X4 SoC is typically found in TV boxes, but EDATEC has integrated the quad-core Cortex-A55 SoC into its ED-GWL1010 LoRaWAN IoT gateway designed for smart buildings and industrial IoT networks requiring long-range, low-power connectivity. The ED-GWL1010 is built around the ED-REIMEI1 single-board computer, combining a mainboard and an expansion board. It integrates Semtech’s latest SX1302/SX103 baseband chip and a Microchip ATECC608 security chip for enhanced protection. The gateway offers up to 8GB LPDDR4 and 32GB of eMMC storage. For connectivity, it supports dual-band WiFi, Bluetooth 5.0, 10/100Mbps Ethernet with PoE, and a mini PCIe slot for a LoRa module compatible with both American and European LoRa frequencies (US915, AU915, AS923, EU868). It also features USB 3.0, an RGB LED indicator, a user button, and flexible power options through a 7-18V DC input or PoE. The ED-GWL1010 operates reliably in temperatures ranging from -25°C to 50°C and is housed […]

Posted on by Debashis Das - No Comments on EDATEC ED-SBC2300 – A Raspberry Pi CM4-powered industrial Mini-ITX motherboard

EDATEC ED-SBC2300 – A Raspberry Pi CM4-powered industrial Mini-ITX motherboard

EDATEC ED SBC2300 Raspberry Pi CM4 powered Mini ITX Industrial Motherboard

The EDATEC ED-SBC2300 is an industrial mini-ITX motherboard built around the Raspberry Pi CM4. The motherboard offers various storage options including eMMC flash, microSD card, and mSATA SSD. It supports dual displays (HDMI + LVDS or HDMI + eDP with touchscreen), offers diverse connectivity with USB, GbE port, RS232, RS485, and GPIO, and boasts integrated security features like RTC, EEPROM, and crypto authentication. The board supports a wide 9V-36V DC power input and PoE is also an option through an add-on board. With its compact size, flexible I/O, and industrial-grade features, the ED-SBC2300 series suits applications like kiosks, digital signage, industrial automation, and IoT devices. Previously we have written about similar products from EDATEC including the RPI CM4-based industrial computer, the EDATEC ED-HMI2320-156C fanless panel PC, and the EDATEC ED-HMI2120-101C, also an industrial panel PC with an 10.1-inch capacitive touchscreen. Feel free to check those out if you are interested […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Fanless Raspberry Pi CM4 panel PC features 15.6-inch touchscreen display, supports 9V-36V wide input voltage

Fanless Raspberry Pi CM4 panel PC features 15.6-inch touchscreen display, supports 9V-36V wide input voltage

Raspberry Pi CM4 Fanless Panel PC

EDATEC ED-HMI2320-156C is a fanless panel PC powered by a Raspberry Pi CM4 module with 15.6-inch capacitive touchscreen display and a metal enclosure ensuring cooling that’s built upon the previous Compute Module 4 smart displays from the company such as the 10.1-inch EDATEC ED-HMI2020-101C industrial panel PC and the ED-HMI2120-101C adding features such as 4G LTE, RS232 and RS485, M.2 NVMe SSD. The company’s latest HMI solution comes with two mSATA sockets, a 4K-capable HDMI 2.1 output port, two Gigabit Ethernet ports, optional WiFi 5, Bluetooth 5, and 4G LTE connectivity, as well as a few USB ports and DB9 serial ports. It can operate in the -25°C to +60°C temperature range and takes 9V to 36V DC input. EDATEC ED-HMI2320-156C specifications: System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Raspberry Pi 5 industrial HMI displays gain M.2 NVMe SSD, RS232/RS485 interfaces, audio input/output jacks

Raspberry Pi 5 industrial HMI displays gain M.2 NVMe SSD, RS232/RS485 interfaces, audio input/output jacks

Raspberry Pi 5 industrial HMI with RS232/RS485 audio input/output jacks

EDATEC ED-HMI3020 is a family of Raspberry Pi 5-based industrial HMI displays that build upon the earlier ED-HMI3010 panel PCs by adding an M.2 socket for NVMe SSD, RS232 and RS485 interfaces, as well as 3.5mm audio input and output jacks. The new models are still offered with either a 7-inch (1024×600) or 10.1-inch (1200×800) touchscreen display, a Raspberry Pi 5 with 4GB or 8GB RAM with all main ports (HDMI, Ethernet, USB) accessible externally, and support for an optional 8MP front-facing camera. ED-HMI3020 specifications with differences again ED-HMI3010 highlighted in bold or strikethrough: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage MicroSD card socket M.2 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on EDATEC ED-IPC3020 – A fanless Raspberry Pi 5 industrial computer with an M.2 NVMe SSD, RS485/RS232 interfaces

EDATEC ED-IPC3020 – A fanless Raspberry Pi 5 industrial computer with an M.2 NVMe SSD, RS485/RS232 interfaces

EDATEC ED-IPC3020 Raspberry Pi 5 industrial computer

EDATEC ED-IPC3020 is a fanless industrial computer based on the Raspberry Pi 5 SBC with support for an M.2 NVMe SSD up to 2260 in size, RS232 and RS485 serial ports, and stereo audio input and output jacks. The Raspberry Pi 5 single board computer could already support an M.2 NVMe SSD thanks to add-on boards such as the PineBerry Pi HatDrive and Pimoroni NVMe Base, but with the ED-IPC3020 we have a complete Raspberry Pi 5-powered computer with M.2 NVMe storage. EDATEC ED-IPC3020 specifications: SBC – Raspberry Pi 5 Model B SoC – Broadcom BCM2712 quad-core Arm Cortex-A76 processor clocked up to 2.4 GHz, VideoCore VI GPU,  4Kp60 H.265 decoder Memory – 4GB and 8GB LPDDR4X-4267 SDRAM are optional Storage – MicroSD card slot for the OS Video Output – 2x micro HDMI ports up to 4Kp60 Networking Gigabit Ethernet RJ45 port with optional PoE support Dual-band 802.11ac Wi-Fi […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on 7-inch and 10.1-inch industrial panel PCs feature Raspberry Pi 5 SBC

7-inch and 10.1-inch industrial panel PCs feature Raspberry Pi 5 SBC

Raspberry Pi 5 industrial Panel PCs

After introducing several Raspberry Pi CM4-based panel PCs over the years, EDATEC has launched its first industrial panel PCs based on the Raspberry Pi 5 SBC with the HMI3010-070C and HMI3010-101C equipped respectively with a 7-inch and 10.1-inch touchscreen display. Both HMI displays expose most I/Os and features from the Raspberry Pi 5 including the two micro HDMI ports, the USB-C port for power, the four USB Type-A connectors, and the gigabit Ethernet RJ45 jack. The company also offers an 8MP front-facing camera and/or PoE as options. EDATEC HMI3010 specifications: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage – Optional 32GB or 64GB MicroSD card  Display […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

10.1-inch Raspberry Pi CM4 panel PC

EDATEC ED-HMI2120-101C is a Raspberry Pi CM4-based industrial panel PC with a 10.1-inch capacitive touchscreen display with plenty of interfaces to cater to a wide range of use cases from robotics to energy management and industrial automation. The panel PC builds upon the ED-HMI2020-101C introduced just a few months ago, but adds a range of features with dual Ethernet, RS485 and RS232 interfaces, and optional supports for an M.2 NVMe SSD and 4G LTE cellular connectivity. The device now supports an even wider DC input range from 9V to 36V and provides three 12V DC outputs to power external hardware such as an additional LCD. ED-HMI2120-101C specifications (with highlights in bold and strikethrough showing the differences against the earlier ED-HMI2020-101C model): System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on EDATEC ED-IPC2100 industrial computer offers 4x RS485/RS232 ports

EDATEC ED-IPC2100 industrial computer offers 4x RS485/RS232 ports

EDATEC ED-IPC2100 industrial computer with RS485 and RS232 ports

EDATEC has launched four more Raspberry Pi CM4-powered industrial computers with the ED-IPC2100 Series that mostly differ from the earlier ED-IPC2010 model with an extra M.2 Key-B socket for an SSD, an extra Gigabit Ethernet port, and four COM ports with RS232 or RS485 interfaces depending on the exact model. The new ED-IPC2100 series industrial computer family ships with a Raspberry Pi Compute Module 4 with up to 8GB RAM, 32GB flash, optional WiFi 5 and Bluetooth 5.0, and offer a full-size HDMI video output, two Gigabit Ethernet port, and a few USB ports. The ED-IPC2120 model looks to offer some extra features such as an HDMI Touch FPC connector, MIPI CSI camera and DSI display connectors, and audio interfaces. ED-IPC2100-series specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz with VideoCore VI GPU System Memory – 1GB, 2GB, 4GB, or 8GB LPDRR4-3200 RAM […]
