amston lake News - Page 2 of 2 - CNX Software

August 20, 2024August 20, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

UP Squared 7100 Alder Lake-N fanless SBC ships with up to 16GB LPDDR5 and 128GB eMMC flash

AAEON has just introduced the UP Squared 7100 fanless single board computer powered by Intel Processor N-series CPUs (N97 or N100 by default) with up to 16GB LPDDR5 and 128GB eMMC flash in a compact 90 x 85.6mm form factor. The SBC can drive up to three independent 4K displays at 60 Hz, features two RS232/422/485 interfaces, gigabit Ethernet, three USB 3.2 ports, and expansion options that include a 40-pin GPIO header, and two M.2 sockets for NVMe storage and WiFi/Bluetooth connectivity. UP Squared 7100 specifications: Alder Lake-N SoC (one or the other) Default options Intel Processor N100 quad-core processor up to 3.4 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 750 MHz; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 1.2 GHz; TDP: 12W Additional options upon request Intel Core i3-N305 octa-core processor […]

July 10, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

DFI ASL9A2 COM Express Mini Type 10 module features Intel Atom x7000RE Amston Lake processor

DFI ASL9A2 COM Express Mini Type 10 Amston Lake module

DFI ASL9A2 is a COM Express Mini Type 10 module based on Intel Atom x7000RE Amston Lake processors which are pin-to-pin compatible with the Alder Lake-N Series processors and designed for the embedded market with a wider operating temperature range. The credit card-sized COM Express Mini module supports up to 16GB LPDDR5 memory, up to 128GB an eMMC flash, and exposes various interfaces such as 2.5GbE, PCIe Gen3, SATA 3.0, DDI and eDP/LVDS for dual display support, ten USB 3.2/2.0, and more. DFI ASL9A2 specifications: SoC (one or the other) Amston Lake Intel Atom x7211RE dual-core processor @ 1.0 to 3.2 GHz with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor @ 2.0 to 3.4 GHz with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE quad-core processor @ 1.5 to 3.4 GHz with 6MB cache, 32EU Intel UHD graphics; 9W TDP Intel […]

May 6, 2024May 5, 2024 by Debashis Das - No Comments

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

April 24, 2024April 24, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

ASRock SBC-262M-WT 3.5-inch motherboard features up to Intel Atom X7433RE Amston Lake processor

ASRock Industrial SBC-262M-WT is a 3.5-inch SBC motherboard powered by the latest Intel Atom x7433RE quad-core Amston Lake embedded processor with support for up to 48GB DDR5-4800 memory, triple 4K display outputs, two Ethernet ports, including one with 2.5Gbps Ethernet and Intel TSN/TCC. The motherboard also takes SATA 3.0 and M.2 Key M NVMe storage, offers multiple USB interfaces, supports WiFi and/or 4G LTE or 5G cellular connectivity via M.2 modules and SIM card socket, and provides industrial features such as a wide -40 to 85°C operating temperature range and a wide 9V to 36V DC voltage input range that make it suitable for smart retail, smart cities, and embedded industrial environments. ASRock Industrial SBC-262M-WT 3.5-inch motherboard specifications: SoC – Intel Amston Lake Processors up to Atom X7433RE quad-core processor clocked up to 3.4GHz with Intel UHD Graphics; 9W TDP System Memory – Up to 48GB single-channel DDR5 4800 MHz […]

April 12, 2024November 13, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

ADLINK unveils Intel Atom x7000RE & x7000C Amston Lake COM Express and SMARC 2.1 modules

ADLINK has released two Intel Atom X7000RE & x7000C Amston Lake-powered modules with the cExpress-ASL COM Express Type 6 Compact module and the LEC-ASL SMARC 2.1 system-on-module both offered with up to 16GB LPDDR5 soldered-down memory and 2.5GbE networking. The modules are designed for high-performance, low-power, and ruggedized edge solutions running 24/7, and with support for Intel TCC and Time Sensitive Networking (TSN), the modules are also suitable for hard-real-time computing workloads required by use cases such as industrial automation, AI robots, smart retail, transportation, network communication, and more. Intel Atom x7000RE and x7000C Amston Lake processors The announcement came as a surprise because I had never heard about Intel Amston Lake processors so far. It might be because they were just announced and all seven SKUs are embedded parts with two to eight cores, and as a result, they may not quite get as much coverage as consumer processors. […]
