Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on AAEON BOXER-6647-MTH Meteor Lake embedded Box PC features screwless SATA and M.2 M-key trays

AAEON BOXER-6647-MTH Meteor Lake embedded Box PC features screwless SATA and M.2 M-key trays

AAEON BOXER-6647-MTH

AAEON BOXER-6647-MTH is an embedded Box PC powered by Intel Core Ultra 7 155H or Core Ultra 5 125H Meteor Lake processor, and mainly designed for advanced industrial robotics solutions such as AGV (Automated Guided Vehicle) and AMR (Autonomous Mobile Robot). The rugged computer supports up to 64GB DDR5 RAM, is equipped with screwless external SATA and M.2 M-Key trays, offers 2.5GbE networking, four USB 3.2 interfaces, RS-232/422/485 & DIO for cameras, sensors (LIDAR, IMUs, etc…), and actuators for robotics, as well as wireless and cellular expansion via additional M.2 sockets. AAEON BOXER-6647-MTH specifications: Meteor Lake-H SoC (one or the other) Intel Core Ultra 5 125H 14-core (4P+8E+2LPE) processor @ 1.2 / 4.9 GHz with 18MB cache, Intel 7Xe LPG graphics @ 2.2 GHz, Intel AI Boost NPU; TDP: 28W Intel Core Ultra 7 155H 16-core (6P+8E+2LPE) processor @ 1.4 / 4.8 GHz with 24MB cache, Intel 8Xe LPG graphics […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Boardcon SBC3576 – A feature-rich Rockchip RK3576 SBC with HDMI, mini DP, dual GbE, WiFi 6, optional 5G/4G LTE module, and more

Boardcon SBC3576 – A feature-rich Rockchip RK3576 SBC with HDMI, mini DP, dual GbE, WiFi 6, optional 5G/4G LTE module, and more

Boardcon SBC3576 SBC

Boardcon SBC3576 is a feature-rich single board computer (SBC) based on the MINI3576 system-on-module powered by a Rockchip RK3576 AI SoC and equipped with two 100-pin and one 44-pin board-to-board connectors for interfacing with the carrier board. The carrier board is equipped with up to 8GB RAM, 128GB eMMC flash, two gigabit Ethernet ports, a WiFi 6 and Bluetooth 5.3 module, 4K-capable HDMI 2.1 and mini DP video outputs, a mini HDMI input port, a USB 3.0 Type-A port, RS485 and CAN Bus terminal block, and more. The Rockchip RK3576 SoC comes with the same 6 TOPS NPU found in the Rockchip RK3588/RK3588S SoC and can be used as a lower-cost alternative with less performance. Boardcon SBC3576 specifications: SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, four Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU – ARM Mali-G52 MC3 GPU clocked at 1GHz with support for OpenGL […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Radxa ROCK 5T SBC packs ROCK 5 ITX mini-ITX motherboard’s features onto a 110x80mm PCB

Radxa ROCK 5T SBC packs ROCK 5 ITX mini-ITX motherboard’s features onto a 110x80mm PCB

ROCK 5T

Radxa ROCK 5T is yet another Rockchip RK3588 SBC whose main selling point is to pack most features of the ROCK 5 ITX mini-ITX motherboard (170x170mm) into a much smaller 110x80mm board. The board features up to 32GB RAM, M.2 2280 sockets for NVMe SSDs, four independent display outputs via HDMI, USB-C, and MIPI DSI, HDMI input and camera interfaces, two 2.5GbE RJ45 jacks, on-board WiFi 6/6E and Bluetooth 5.x, and an M.2 Key-B socket for cellular connectivity. Radxa ROCK 5T specifications: (with differences highlighted in bold or strikethrough) SoC – Rockchip RK3588 or RK3588J (industrial grade) CPU – Octa-core processor with four Cortex-A76 cores @ up to 2.2 GHz (industrial) / 2.4 GHz (commercial), four Cortex-A55 cores @ up to 1.8 GHz GPU – Arm Mali G610MC4 GPU VPU 8Kp60 10-bit H.265 / VP9 / AVS2  / AV1 decoder, 8Kp30 H.264  decoder 8Kp30 H.265 / H.264 encoder AI accelerator […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on AAEON GENE-MTH6 3.5-inch Meteor Lake SBC offers up to 96GB of DDR5, 9-36V wide power input, PCIe Gen4 FPC connector

AAEON GENE-MTH6 3.5-inch Meteor Lake SBC offers up to 96GB of DDR5, 9-36V wide power input, PCIe Gen4 FPC connector

AAEON GENE-MTH6 3.5-inch meteor lake SBC

AAEON GENE-MTH6 Intel Meteor Lake-powered 3.5-inch “Subcompact” SBC takes up to 96GB DDR5, offers an ERP-compliant 9V-36V wide power input range, and includes an unusual PCIe Gen4 x4 FPC connector to add an M.2 expansion module, or other custom modules. The board also features two 2.5GbE and one GbE port, supports WiFi 6 and 5G via M.2 sockets, a SATA port and an M.2 socket for storage expansion, four display interfaces, a few USB ports, four internal COM ports for RS232 and/or RS485, and more. It is offered with either 15W U-Series (Intel Core Ultra 5 125U / Core Ultra 7 155U) or 28W H-series (Intel Core Ultra 5 125H / Core Ultra 7 155H) processors. AAEON GENE-MTH6 specifications: Meteor Lake SoC (one or the other) Intel Core Ultra 7 155H 16-core/22-thread processor up to 4.8 GHz with 24MB cache, Intel 8Xe LPG graphics @ 2.25 GHz, Intel AI Boost […]

Posted on by Debashis Das - No Comments on Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Sierra Wireless HL7900 5G LPWA module

The HL7900 5G LPWA module from Semtech (Sierra Wireless) is a globally certified solution built around Sony’s Altair ALT1350 chip and designed for low-power IoT applications. It is certified by major U.S. carriers, including AT&T, T-Mobile, and Verizon, as well as Japan’s KDDI, and has achieved global regulatory certifications (FCC, CE, ISED, etc.) and industry certifications (PTCRB, GCF) for carrier interoperability. This chip features an ultra-low-power sensor hub MCU for efficient environmental monitoring. Additionally, it includes integrated sub-GHz and 2.4GHz radios supporting short-range protocols such as Wi-SUN including U-Bus Air, NB-IoT, and 5G NTN along with GNSS and Wi-Fi-based indoor/outdoor tracking. Furthermore, this chip supports embedded SIM support, secure edge-to-cloud connectivity, and over-the-air updates. These features make this chip useful for applications such as asset tracking, urban navigation, and other IoT solutions requiring reliable, low-power connectivity with global reach. Semtech HL7900 specifications: MCU – Sony ALT1350 5G cellular IoT chip […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Queclink WR310 – A compact 5G and WiFi 6 industrial cellular router with four GbE ports, GNSS, and RS232 and RS485 interfaces

Queclink WR310 – A compact 5G and WiFi 6 industrial cellular router with four GbE ports, GNSS, and RS232 and RS485 interfaces

Queclink WR310 5G industrial cellular gateway

Queclink WR310 5G and WiFi 6 industrial cellular router features four gigabit Ethernet ports, a USB Type-A port, a terminal block with RS232 and RS485, and a wide 8 to 32V DC input suitable for smart manufacturing, industrial IoT (IIoT), and edge computing applications. It looks to be a more compact and cost-optimized version of the Queclink WR300 5G industrial router introduced in 2023 with global 5G coverage. The WR310 has many of the same features, but comes with less memory and storage, one less gigabit Ethernet port, and is available in three models depending on the region of operation: WR310FEU for EMEA, AP, and Brazil regions WR310FAU for LATAM markets WR310FNA for North America Queclink WR310 specifications: SoC – Unspecified Qualcomm dual-core Arm 64-bit Cortex-A53 @ 1.0GHz; likely the Qualcomm IPQ5018 or similar (Note the Qualcomm IPQ8072 quad-core Arm Cortex-A53 @ 2.2 GHz was used in the WR300 5G […]

Posted on by Debashis Das - 1 Comment on AAEON BOXER-8654AI-KIT – NVIDIA Jetson Orin NX-based Edge AI kit features four gigabit Ethernet ports with PoE support

AAEON BOXER-8654AI-KIT – NVIDIA Jetson Orin NX-based Edge AI kit features four gigabit Ethernet ports with PoE support

AAEON BOXER-8654AI-KIT Edge AI kit

The AAEON BOXER-8654AI-KIT Edge AI kit is a compact development kit built around the NVIDIA Jetson Orin NX modules with four gigabit Ethernet ports (with optional PoE) and an Out-of-Band (OOB) management header, and designed for applications like smart cities, IoT ecosystems, edge AI, and others. The multi-functional carrier board also offers six USB 3.2 Gen 2 ports, HDMI video output, two MIPI CSI, two DB-9 ports for RS-232/422/485 and CAN Bus, and a 40-pin NVIDIA Jetson-compatible GPIO header for I2C, SPI, and UART interfaces. Expansion options include M.2 E and B-key slots for Wi-Fi and 5G modules (with onboard SIM), an M.2 M-Key slot for NVMe SSDs, and a SATA connector. AAEON BOXER-8654AI-KIT specifications SoM – NVIDIA Jetson Orin NX module CPU 8GB Version – 6-core Arm Cortex-A78AE v8.2 64-bit CPU, 1.5MB L2 cache + 4MB L3 cache 16GB Version – 8-core Arm Cortex-A78AE v8.2 64-bit CPU, 2MB L2 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Siflower SF21H8898 is a quad-core 64-bit RISC-V SoC for industrial gateways, routers, and controllers

Siflower SF21H8898 is a quad-core 64-bit RISC-V SoC for industrial gateways, routers, and controllers

Siflower SF21H8898 system block diagram

Siflower SF21H8898 SoC features a quad-core 64-bit RISC-V processor clocked at up to 1.25 GHz and a network processing unit (NPU) for handling traffic and is designed for industrial-grade gateways, controllers, and routers. The chip supports up to 2GB DDR3, DDR3L, or DDR4 memory, offers QSGMII (quad GbE), SGMII/HSGMII (GbE/2.5GbE), and RGMII (GbE) networking interfaces, and USB 2.0, PCIE 2.0, SPI, UART, I2C, and PWM interfaces. Siflower SF21H8898 specifications: CPU – Quad-core 64-bit RISC-V processor at up to 1.25 GHz Cache 32KB L1 I-Cache and 32KB L1 D-Cache per core Shared 256 KB L2 cache Memory – Up to 2GB 16-bit DDR3/3L up to 2133Mbps or DDR4 up to 2666Mbps Storage – NAND and NOR SPI flash support Networking 1x QSGMII interface (Serdes 5Gbps rate) for 4x external Gigabit Ethernet PHYs 1x SGMII/HSGMII interface (Serdes1.25/3.125Gbps rate) supporting Gigabit and 2.5Gbps modes 1x RGMII interface for Gigabit Ethernet 1x MDIO interface […]
