October 17, 2023October 17, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Raspberry Pi Zero W-based Weather Orbs shows weather data on three round displays (Crowdfunding)

Peter Holderith’s Weather Orbs is a Raspberry Pi Zero W-powered desktop weather station that displays animated weather data from NOAA and NWS on three small round displays connected over SPI. Internally it’s an add-on board that connects to the 40-pin GPIO header of the Raspberry Pi Zero W and with three additional headers to connect the smartwatch round displays. The PCB also comes with 16 RGB LEDs to create some nice lighting effects. The Raspberry Pi Zero W and accompanying electronics are housed in a custom “high-quality” 3D printed enclosure with a cover made of brushed stainless steel, and thick glass magnifiers complete the design for a retro style. The default firmware fetches weather data, such as live satellite images from NOAA or radar from NWS, and displays those on the three round displays. It also starts a Wi-Fi hotspot called “weatherorbs” to which the user can connect and then […]

May 29, 2023May 31, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Review of BIGTREETECH Pad 7 Klipper pad with Creality Ender-3 Pro S1 3D printer

Creality Ender-3 S1 Pro + BIGTREETECH Pad 7 Benchy 3D printing

I received the BIGTREETECH Pad 7 7-inch Klipper pad and tablet PC for review earlier this month. I’ve already tested it with a Raspberry Pi CM4 as a Linux tablet PC with touchscreen, and I’ve now reinstalled the BTT CB1 Allwinner H616 system-on-module to run the pre-install Klipper OS and connect the Pad 7 to a Creality Ender-3 Pro S1 3D printer. When I first booted the Pad 7 it ended up with an error message from Klipper complaining about a missing configuration file. I connected to WiFi and update all software packages, but it didn’t help. It’s just because the Pad 7 needs to be configured for a specific printer. We can do so through the web dashboard accessible through a web browser going to http://btt-pad7.local (unless you’d changed the hostname in the system) We’ve got the same error shown in the web interface as Klipper needs to be […]

May 9, 2023 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

KOKONI SOTA 3D printer handles 600mm/s prints, 7-color printing (Crowdfunding)

KOKONI SOTA 3D printer with an inverted design (the printing head is under the hotbed) that supports printing speeds of up to 600mm/s, as well as 7-color printing through a filament tower adding support for 5 extra filament rolls. The upside-down design was made to move motors and rails to the bottom base of the printer to lower the center of gravity and help improve stability, reduce the vibration to virtually nothing, and enable the faster printing speed. KOKONI also says the SOTA 3D printer offers 0.1mm accuracy thanks to AI radar detection and error compensation and operates relatively silently at 30dB one meter from the 3D printer. KOKONI SOTA specifications: Printing size – 200 x 200 x 200 mm XY axis – Linear rail Z-axis SOTA Lite – Lead screw SOTA – High-precision ball screws Drive motor SOTA Lite – high-speed stepper motor SOTA – Closed-loop motor with magnetic […]

May 4, 2023May 4, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Creality Ender-3 S1 Pro review – Part 2: Engraving and 3D printing

Creality Ender 3 S1 Pro 3D Printer laser Engraver

Earlier this year, I received the Creality Ender-3 S1 Pro 2-in-1 3D printer & laser engraver and in the first part of the review, I showed the package content and how to assemble the system either to use it as a 3D printer or a laser engraver, but didn’t start it at the time. I’ve now had time to play with both laser engraving (less luck with cutting) and 3D printing, so I’ll report my experience in the second part of the review. Creality Ender-3 S1 Pro laser engraving Since in the last part of the review I had the 10W laser module installed on the 3D printer, I decided to start the testing with laser engraving and cutting. Contrary to the TwoTrees TS2 laser engraver I reviewed last year, the Creality Ender-3D S1 Pro laser engraving kit does not support autofocus, so I used the provided multi-level fixed-focus bar […]

May 2, 2023May 29, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

BIGTREETECH Pad 7 7-inch 3D printer control display runs Klipper on Allwinner H616 SoM or Raspberry Pi CM4

Yesterday, I wrote about the BTT Pi V1.2 Allwinner H616 SBC designed for 3D printers, but also mentioned I had received the Pad 7 from BIGTREETECH which is a software-compatible, but more complete solution with a 7-inch display and an Allwinner H616-powered CB1 system-on-module compatible with the Raspberry Pi CM4. The BIGTREETECH Pad 7 should be more convenient to use with its integrated 7-inch touchscreen display, and if you ever decided you didn’t need it to control your 3D printer anymore, it could always be used as a small Linux computer running Raspberry Pi OS or another operating system. BIGTREETECH Pad 7 specifications: Supported modules BIGTREETECH CB1 v2.2 (included in the kit) – Allwinner H616 quad-core Cortex-A53 CPU with Mali-G31 MP2 GPU, 1GB RAM, 802.11 b/g/n WiFi 4 Raspberry Pi CM4 module with Broadcom BCM2711 quad-core Cortex-A72 CPU with VideoCore IV GPU, 1 to 8GB RAM, 0 to 32GB eMMC […]

May 1, 2023May 1, 2023 by Jean-Luc Aufranc (CNXSoft) - 25 Comments

BIGTREETECH Pi v1.2 – A Raspberry Pi-sized Allwinner H616 SBC for 3D printers

BIGTREETECH Pi v1.2, also known as the BBT Pi v1.2, is a Raspberry Pi-sized Allwinner H616 single board computer (SBC) specially designed for 3D printers with many of the same ports as the Raspberry Pi 3/4, but also features 12V-24V DC power input and connectors for the ADXL345 3-axis accelerometer, CAN Bus, and so on. The board is equipped with 1GB RAM, a microSD card slot to run the operating system (Debian 11 with Klipper), a 4K capable micro HDMI port, Fast Ethernet and WiFi 4 networking, four USB ports, and the usual 40-pin Raspberry Pi header. BTT Pi specifications: SoC – Allwinner H616 quad-core Arm Cortex-A53 @ 1.5GHz with Arm Mali G31 MP2 with support for OpenGL ES 3.2 System Memory – 1GB DDR3L SDRAM Storage – MicroSD card slot Video Output Micro HDMI 2.0a port up to 4Kp60 resolution SPI port for display Audio – 3.5mm audio jack […]

March 2, 2023March 2, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Floppy thumb drive integrates Adafruit PyPortal display based on Microchip SAMD51 MCU

Anne Barela’s Floppy Thumb Drive project houses the Adafruit PyPortal internet display in a 3D-printed enclosure that looks like a 3.5-inch floppy disk, just a bit thicker. The computer-in-a-floppy-disk project runs CircuitPython code to list the first 12 files stored in the flash and can display photos or animations, play audio, or execute scripts. The project consists of three main parts: The Adafruit PyPortal internet display with Microchip SAMD51 (ATSAMD51J20) Arm Cortex-M4F microcontroller @ up to 120 MHz with 1 MB flash, 256 KB SRAM Display – 3.2-inch 320 x 240 color TFT display with resistive touchscreen Audio – Speaker Storage 8MB flash storage optional microSD card (not used in the project). ESP32 for WiFi and Bluetooth connectivity (not used in the project) Sensors – Light and Temperature sensors Misc – NeoPixel RGB Micro USB to USB cable 3D printed files for the front cover, back door, front door, disk, […]

February 17, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Ploopy – 3D printed open-source hardware headphones feature Raspberry Pi RP2040 MCU, TI PCM3060 24-bit DAC

I don’t think I’ve ever written about open-source hardware headphones. But that’s precisely what Ploopy offers with an amplifier based on a Raspberry Pi RP2040, a Texas Instruments PCM3060 24-bit DAC, and an amplifier circuit, as well as 3D printed parts and open-source firmware written in C. As we’ll see further below the project is reasonably well documented, and you can either build it from scratch, purchase a fully-assembled kit, or something in the middle. I suppose you could even do some knitting since woven covers are part of the build just in case making your own PCBs and 3D printing parts are not your things. The electronics are comprised of two boards: The Gould amplifier board with the Raspberry Pi RP2040, Texas Instruments PCM3060 24-bit 96/192 kHz DAC, and several TI OPA1688 audio operational amplifiers The Mazzoleni driver flex boards going into the left and right rings with a […]
