2.5GbE

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on GEEKOM A7 review – Part 2: Windows 11 Pro tested in a compact AMD Ryzen 9 7940HS mini PC

GEEKOM A7 review – Part 2: Windows 11 Pro tested in a compact AMD Ryzen 9 7940HS mini PC

GEEKOM A7 Ryzen 9 7940HS mini PC review Windows 11 Pro

We previously had a look at the hardware of the GEEKOM A7 with an unboxing and a teardown of the powerful AMD Ryzen 9 7940HS mini PC with 32GB DDR5, a 2TB NVMe SSD, four 4K-capable video outputs, and high-speed interfaces such as USB4 and 2.5GbE, as well as WiFi 6E and Bluetooth 5.3 wireless connectivity. We’ve now had time to test it with Windows 11 Pro in detail, so in the second part of the GEEKOM A7 review, we’ll report our experience with the mini PC including a software overview, features testing, various benchmarks, networking and storage performance testing, fan noise, power consumption, and more. Software overview and features testing The System->About window confirms the GEEKOM A7 mini PC is powered by an AMD Ryzen 9 7840HS processor with Radeon 780M graphics with 32GB RAM and runs Windows 11 Pro 23H2 build 22631.2861. That also means we only had […]

Posted on by Debashis Das - No Comments on Avnet MSC C10M-ALN – A COM Express Type 10 Mini Module with Intel Alder Lake-N CPU, LPDDR5 memory

Avnet MSC C10M-ALN – A COM Express Type 10 Mini Module with Intel Alder Lake-N CPU, LPDDR5 memory

MSC C10M ALN COM Express Type 10 Module

Avnet MSC C10M-ALN is a COM Express Type 10 module powered by the Alder Lake-N family of processors including the Intel Core i3, Intel Atom x7000E, and Intel Processor N-Series. The design allows for easy adaptation of applications between various Intel CPU models, ensuring compatibility across different performance and power needs. The module supports up to 16GB LPDDR5 memory with optional In-Band Error Correcting Code(IBECC), eMMC 5.1 storage, and features an Intel i226 2.5GbE controller. It can handle up to two 4K displays through DDI and eDP video outputs, ten USB ports including USB 3.2 Gen 2, and four PCI Express Gen 3 x1 slots for expanded connectivity options. Avnet MSC C10M-ALN Com Express Module Specification: Alder Lake-N SoC (one or the other) Intel Core i3-N305, eight-core, 1.0GHz/1.8GHz, 32EU Intel UHD Graphics, 9/15W, PUC (PC Client Use Conditions) Intel Atom x7425E, four-core, 1.5GHz, 24EU Intel UHD Graphics, TCC, 12W, EUC […]

Posted on by Sponsored Post - 1 Comment on 5% discount for Intel NUC 11 with Core i7-1165G7 CPU, 16GB RAM, 512GB SSD (Sponsored)

5% discount for Intel NUC 11 with Core i7-1165G7 CPU, 16GB RAM, 512GB SSD (Sponsored)

10% discount Intel NUC 11

Intel decided to pull the plug on its NUC business in 2023, but that does not mean those are not available for sale anymore, and the Intel NUC 11 (NUC11PAHi7) powered by an Intel Core i7-1165G7 SoC with 16GB RAM and a 512GB SSD is now offered on Amazon with a 5% discount when using the coupon code A5QFKRCQ. Introduced in 2021, the Intel NUC11PAHi7 supports up to four 4K displays through HDMI, Mini DP, and Thunderbolt interfaces, offers 2.5GbE and WiFi 6 connectivity, three USB 3.2 Gen 2 ports, and even a CIR (Consumer InfraRed) port. Intel NUC11PAHi7 specifications: SoC – Intel Core i7-1165G7 quad-core/octa-thread Tiger Lake UP3 processor @ up to 2.8 GHz / 4.7 GHz (Turbo) with 96EU Iris Xe Graphics; 15W TDP (configurable between 12 and 28W) System Memory – 16GB DDR4-2666 via SO-DIMM sockets expandable up to 64GB RAM Storage 512GB M.2 NVMe (PCIe Gen4) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Sapphire Edge+ VPR-4616-MB mini-ITX motherboard features “AMD Embedded+” architecture with Ryzen R2314 & Versal VE2302

Sapphire Edge+ VPR-4616-MB mini-ITX motherboard features “AMD Embedded+” architecture with Ryzen R2314 & Versal VE2302

AMD Embedded+ mini-ITX motherboard

Sapphire Edge+ VPR-4616-MB is a new mini-ITX motherboard on the “new” AMD Embedded+ “architecture” comprised of an AMD Ryzen Embedded R2314 processor and an AMD Versal AI Edge VE2302 adaptive SoC (also called FPGA SoC…). The motherboard supports up to 64GB ECC/non-ECC DDR4 memory for the CPU, 8GB of memory for the adaptive SoC, supports SATA and NVMe storage, dual video output, 2.5GbE networking, and offers a range of USB ports and M.2 sockets for expansion. AMD Embedded+ solutions target sensor fusion, AI inferencing, industrial networking, control, and visualization applications. SAPPHIRE Edge+ VPR-4616-MB specifications: AMD Embedded+ Architecture Adaptive SoC Subsystem Main IC – AMD Versal AI Edge VE2302 with dual Arm Cortex-A72 core processor @ up to 1.6 GHz, dual-core Arm Cortex-R5F, 23 TOPS AI engine, FPGA fabric, etc… System Memory – 2x 4GB LPDDR4 Storage 1Gbit OSPI NOR flash for local boot 64 Kbit EEPROM for Board-ID Expansion 160-pin […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on Maxtang MTN-FP750 business mini PC review – Part 3: Ubuntu 22.04

Maxtang MTN-FP750 business mini PC review – Part 3: Ubuntu 22.04

Maxtang MTN-FP750 review Ubuntu 22.04

We’ve already checked out the hardware of the Maxtang MTN-FP750 mini PC in the first part of the review with an unboxing and a teardown, and tested the AMD Ryzen 7 7735HS Mini PC with 32GB DDR5 and a 512GB SSD in Windows 11 Pro in the second part. In the third part of the review, we will report our experience with the Ubuntu 22.04 Linux operating system. This includes features testing, several benchmarks, storage and networking performance testing, a stress test to check thermal performance, as well as fan noise and power consumption measurements. Ubuntu 22.04 installation Since the plan is to install Ubuntu 22.04 alongside Windows 11, so we will shrink the Windows 11 partition by about half first, before inserting the Ubuntu 22.04.3 USB drive to install the Linux distribution. The installation went smoothly with no issues to report on. Ubuntu 22.04 System information Going to Settings->About […]

Posted on by Sponsored Post - No Comments on GEEKOM Mini IT12 Mini PC with Core i5-12450H CPU, USB4, 2.5GbE, WiFi 6E goes for less than $400 (Sponsored)

GEEKOM Mini IT12 Mini PC with Core i5-12450H CPU, USB4, 2.5GbE, WiFi 6E goes for less than $400 (Sponsored)

GEEKOM Mini IT12 coupon code

GEEKOM has launched a new promotion for the Mini IT12 mini PC with an Intel Core i5-12450H, 16GB DDR4 memory, and a 512GB SSD which you can get for under $400 when using the coupon code cnxsoftwareit12 for a $20 discount on GEEKOM US or a £20 discount on GEEKOM UK. The mini PC also supports up to four displays thanks to two HDMI ports and two USB4 ports, offers 2.5GbE and WiFi 6E networking, and comes with a total of six USB ports for expansion. GEEKOM Mini IT12 specifications: SoC – Intel Core i5-12450H 8-core/12-thread Alder Lake hybrid processor up to 4.40 GHz with 12MB Cache, 48 EU Intel UHD Graphics @ up to 1.2 GHz; PBP: 45W System Memory – 16GB DDR4-3200 via SODIMM sockets upgradeable up to 64GB Storage 512GB M.2 2280 PCIe Gen 4 x4 SSD, expandable up to 2TB M.2 2242 SATA SSD socket up […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on GEEKOM A7 mini PC review – Part 1: Specs, unboxing, teardown, and first boot

GEEKOM A7 mini PC review – Part 1: Specs, unboxing, teardown, and first boot

GEEKOM A7 Review Windows 11 Pro

GEEKOM A7 is a compact mini PC powered by an AMD Ryzen 9 7940HS (or Ryzen 7 7840HS) processor with up to 64GB DDR5, up to a 2TB NVMe PCIe Gen 4 x4 SSD, four 4K capable video outputs, 2.5GbE and WiFi 6E connectivity, and six USB ports for expansion. The company sent us a sample of the GEEKOM A7 with an AMD Ryzen 9 7940HS CPU, 32GB DDR5, and 2TB SSD for review. We’ll do a three-part review starting by listing the specifications, checking out the hardware design and accessories, and quickly trying it in the first part of the review, before testing both Windows 11 Pro and Ubuntu 22.04 in detail in a few weeks. GEEKOM A7 specifications SoC (one or the other) AMD Ryzen 9 7940HS 8-core/16-thread processor up to 4.0GHz with 16MB cache, AMD Radeon 780M Graphics; TDP: 35 to 54W AMD Ryzen 7 7840HS 8-core/16-thread […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 31 Comments on Banana Pi BPI-M7 – A thin Rockchip RK3588 SBC with dual 2.5GbE, M.2 NVMe storage, HDMI 2.1, and more

Banana Pi BPI-M7 – A thin Rockchip RK3588 SBC with dual 2.5GbE, M.2 NVMe storage, HDMI 2.1, and more

Banana Pi BPI-M7

Banana Pi BPI-M7 SBC is powered by a Rockchip RK3588 SoC and comes with a low profile design that reminds me of boards from Khadas such as the Khadas Edge2 or VIM4 SBCs but with a few extra ports thanks to the larger form factor. The Banana Pi BPI-M7 single board computer is equipped with up to 32GB RAM and 128GB eMMC flash and features an M.2 2280 socket for one NVMe SSD, three display interfaces (HDMI, USB-C, MIPI DSI), two camera connectors, dual 2.5GbE, WiFi 6 and Bluetooth 5.2, a few USB ports, and a 40-pin GPIO header for expansion. Banana Pi BPI-M7 specifications: SoC – Rockchip RK3588 octa-core processor with CPU – 4x Cortex‑A76  cores @ up to 2.4 GHz, 4x Cortex‑A55 core @ 1.8 GHz GPU – Arm Mali-G610 MP4 “Odin” GPU Video decoder – 8Kp60 H.265, VP9, AVS2, 8Kp30 H.264 AVC/MVC, 4Kp60 AV1, 1080p60 MPEG-2/-1, VC-1, […]

UP 7000 x86 SBC
