November 8, 2023November 12, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Toradex Titan Evaluation Kit features NXP i.MX 95 AI processor for IoT, industrial, and automotive applications

Toradex TITAN NXP i.MX 95 evaluation kit EVK

[Update September 12, 2024: The NXP i.MX 95 Titan Evaluation Kit (EVK) has been renamed to the “i.MX 95 Verdin Evaluation Kit”] Toradex Titan Evaluation Kit features the NXP i.MX 95 Cortex-A55/M33/M7 heterogenous AI processor introduced at the beginning of the year with an NXP eIQ Neutron Neural Network Accelerator (NPU) for automotive, industrial, and IoT applications. The design is comprised of a carrier board and a SO-DIMM system-on-module with the NXP i.MX 95 SoC, up to 16GB LPPDR5 memory, up to 128GB eMMC flash storage, a WiFi 5 and Bluetooth 5.0 wireless module, a gigabit Ethernet controller, a PMIC, and a few other components. The carrier board also comes with 10GbE and Gigabit Ethernet ports, HDMI video output, a few USB ports, and various expansion connectors and headers. Toradex Titan evaluation kit specifications: SoC – NXP i.MX 95 with Up to 6x Arm Cortex-A55 application cores clocked at 2.0 […]

October 11, 2023October 11, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

COM-HPC 1.2 specification released with COM-HPC Mini 95x70mm form factor

PICMG has announced the release of the COM-HPC 1.2 specification adding the COM-HPC Mini form factor that’s about the size of a credit card (90x75mm) or half the size of the next-smallest COM-HPC form factor but still provides access to high-speed interfaces such as PCIe Gen5, USB4, and 10GbE. The COM-HPC “High-Performance Computing” form factor was introduced a few years ago for more powerful CPUs (higher TDP) with support for PCIe Gen4 (the COM Express form factor can’t handle PCIe Gen 4 clock speeds and throughputs well), and until now four sizes were available with COM-HPC Client Type modules measuring 95 x 120mm (Size A) to 160 x 120mm (Size C) and Server Type modules having either 160 x 160mm (Size D) or 200 x 160mm (Size E) dimensions. The COM-HPC Mini brings a smaller (95 x 60 mm) credit card-sized form factor to the COM-HPC standard for applications such […]

September 30, 2023October 1, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

PALMSHELL NeXT H2 SBC and micro server offers 10GbE for $199 and up

Palmshell Next H2 10GbE 2.5GbE micro server

PALMSHELL NeXT H2 is an affordable AMD Ryzen Embedded R1505G-powered micro server, also available as an SBC for developers, that features two 10GbE SFP+ cages and one 2.5GbE RJ45 port, as well as expansion sockets for wireless connectivity. The system supports up to 32GB RAM plus an M.2 NVMe SSD and two SATA drives for storage, offers several wireless connectivity options with WiFi 6, Bluetooth 5.2, and 4G LTE/5G, and is equipped with two 4Kp60-capable HDMI ports, and four USB ports. PALMSHELL NeXT H2 specifications: SoC – AMD Ryzen Embedded R1505G dual-core/quad-thread processor @ 2.4GHz up to 3.3GHz with AMD Radeon Vega 3 graphics; TDP set to 25W System Memory – Optional 8GB or 16GB DDR4 @ 2400 MT/s via 2x SO-DIMM slots Storage Optional 256GB or 512GB NVMe (PCIe 3.0) SSD via M.2 Key-N 2280 socket 2x SATA III connector MicroSD card socket Video Output – 2x HDMI […]

July 21, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

SolidWAN CN9131 is a compact SD-WAN appliance powered by a Marvell OCTEON CN9131 SoC

SolidRun has just introduced the SolidWAN CN9131 SD-WAN appliance powered by a Marvell OCTEON CN9131 quad-core Cortex-A72 processor and with a compact form factor and features that makes it suitable for small offices. The Linux-based Software Defined-WAN appliance comes with 4GB to 8GB RAM, 8GB to 64GB eMMC flash storage, plus M.2 SATA and NVMe sockets, and offers four GIgabit Ethernet ports and two 10GbE SFP+ cages for networking connectivity, as well as two USB 3.0 ports. SolidWAN CN9131 specifications: System-on-Module – CN9130 SOM with SoC – Marvell OCTEON CN9131 quad-core Arm Cortex A72 clocked at up to 2.2GHz System Memory – 4GB – 8GB (4GB default) 64-bit DDR4 @ 2400MT/s Storage – 8GB eMMC flash with options up to 64GB, 8MB SPI NOR flash Storage M.2 SATA and/or NVMe SSD (See Expansion section) MicroSD card slot accessible from the outside Networking 2x 10GbE SFP+ cages 4x Gigabit Ethenret RJ45 […]

July 11, 2023July 10, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

bitswrt NHX53X2 WiFi 7 system-on-module features Qualcomm IPQ5332 SoC

bitswrt NHX53X2 is a WiFi 7 system-on-module (SoC) powered by a Qualcomm IPQ5332 quad-core Cortex-A53 SoC and equipped with the QCN6274 commercial grade WiFi 7 chipset. The IPQ5332 processor looks to be the little brother of the IPQ9574 quad-core Arm Cortex-A73 processor found in the AL02 WiFi 7 reference router board from Qualcomm. The module comes with up to 3GB RAM, 1GB NAND flash, and exposes plenty of I/Os with multiple 2.5GbE interfaces, 10GbE, PCIe Gen 3.0, USB 3.0, GPIOs, and more. bitswrt NHX53X2-V01 specifications: SoC – Qualcomm IPQ5332 quad-core Arm Cortex-A53 at 1.5 GHz WiFi 7 chipset – Qualcomm QCN6274 NPU – 12-threaded network processing unit (NPU) Ubi32 @ 1.5 GHz (likely part of Qualcomm IPQ5332, but public info is sparse) System Memory – 1GB (option up to 3GB) 16/32-bit DDR4 at 2133 MT/s Storage – 8MB NOR flash, 128MB (option up to 1GB) NAND flash, 128Kbit EEPROM WLAN […]

June 29, 2023February 29, 2024 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Qualcomm IPQ9574 “AL02” router board support WiFi 7 modules, 10GbE networking

The recent Linux 6.4 release included initial support for the AL02 WiFi 7 router board powered by a Qualcomm IPQ9574 quad-core Cortex-A73 processor part of the Qualcomm Networking Pro 1620 platform with the board featuring 2GB DDR4 RAM and 256MB NAND flash. A couple of weeks ago, I was contacted by Wallystech about their DR9574 WiFi 7 board based on the IPQ9574 processor, but I ended up not writing about it due to the lack of information and low-quality photos. But it turns out it’s actually the Qualcomm AL02 reference board that’s also provided by Compex. Both companies are world-leading in the sense they offer low-quality and blurry pictures in a way that’s unmatched in the industry, but we do have some specifications, so let’s have a closer look. AL02 / DR9574 board specifications: SoC – Qualcomm IPQ9574 quad-core Arm Cortex-A73 processor @ 2.2GHz processor System Memory – 2GB DDR4 […]

June 26, 2023June 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Intel soft router offers up to eight 2.5GbE ports, Comet Lake or Whiskey Lake Core processor

Topton is offering a soft router powered by an Intel Whiskey Lake or Comet Lake processor up to the Core i7-10510U quad-core/octa-thread processor with either eight 2.5GbE RJ45 ports or four 2.5GbE RJ45 ports and two 10GbE SFP+ cages. We’ve previously written about the low-cost InuoMicro G4305L8-S2 fanless industrial PC box with eight 2.5GbE interfaces, but it is powered by an Intel Celeron 4305UE dual-core Whiskey Lake processor, and the Topton model should offer more performance with a choice of 8th or 10th generation Intel Core i3/i5/i7 Whiskey Lake or Comet Lake SoC. Specifications: SoC (one or the other) Intel Core i3-8145UE dual-core Whiskey Lake processor up to 3.90 GHz with Intel UHD Graphics 620; 15W TDP Intel Core i5-10210U quad-core/eight-thread Comet Lake processor @ 1.6 GHz / 3.9 GHz (turbo all cores) / 4.2 GHz (turbo one core), 24EU Intel UHD graphics; 6MB Cache; 15W TDP Intel Core i7-10510U […]

May 19, 2023May 18, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Cincoze DX-1200 fanless Alder Lake-S embedded computer targets machine vision, industrial automation

Cincoze DX-1200 is a fanless embedded computer powered by a choice of 12th gen Intel Core (Alder Lake-S) Celeron up to Core i9 CPUs whose mainboard is housed in a rugged and compact chassis designed for industrial edge AI and machine vision applications. The DX-1200 supports up to 64GB of 4800MHz DDR5 memory with ECC, and the Intel Xe architecture of the UHD 770 graphics chip is said to deliver image classification inference performance that is 2.8 times the speed of the Comet Lake-S platform. The embedded computer also offers a wide range of I/Os and as well expansion capabilities for up to four 10GbE, DIO, and COM ports, and M.2 and mPCIe sockets for WiFi, GNSS, 4G, and Bluetooth connectivity. Cincoze DX-1200 specifications: Alder Lake-S SoC (one or the other) Intel Core i9-12900E 16 cores up to 5 GHz with Intel UHD Graphics 770; TDP: 65W Intel Core i7-12700E […]
