May 5, 2023May 5, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Banana Pi BPI-W3 SBC features Rockchip RK3588 SoM, M.2 NVMe socket, 2.5GbE, HDMI output and input

Banana Pi BPI-W3 is another Rockchip RK3588 SBC (single board computer) with 8GB RAM, 32GB eMMC flash, an M.2 NVMe socket, 2.5GbE networking, two HDMI 2.1 output ports, one HDMI 2.0 input port, and other features. We first recovered the board last summer, but at the time the RK3588 SBC came with a PCIe x4 slot and dual Gigabit Ethernet, and the company has now redesigned the board without either using instead a Rockchip RK3588 system-on-module as part of the design and implemented 2.5GbE and M.2 NVMe SSD support with the available PCIe interfaces. Banana Pi BPI-W3 specifications: SoM – BPI-RK3588 core board SoC- Rockchip RK3588 octa-core processor with 4x Cortex-A76 cores @ up to 2.4 GHz, 4x Cortex-A55 cores @ 1.8 GHz, an Arm Mali G610MC4 GPU, a 6 TOPS NPU, 8Kp60 H.265/VP9/AVS2 10-bit decoder, 8Kp30 H.265/H.264 encoder System Memory – 8GB LPDDR4 (options for 4GB to 32GB) Storage […]

May 4, 2023May 5, 2023 by Jean-Luc Aufranc (CNXSoft) - 14 Comments

Orange Pi is working on a portable gaming console with Rockchip RK3588S or AMD Ryzen 7 CPU

Single board computer manufacturer Orange Pi Ltd is working on a portable gaming console that will come with either a Rockchip RK3588S processor for Android/Linux gaming, or AMD Ryzen 7 7800U/6800U for Windows gaming. The industrial design looks to be the same for all models with a 7-inch touchscreen display, a D-Pad, two joysticks, XBOX-styled ABXY buttons, two customisable buttons on the back, two microphones, stereo speakers, three USB ports including one only for charging, The Orange Pi portable gaming console will be offered in three variants when it launches in China in October during Golden Week: AMD Ryzen 7 7840U processor with 16GB RAM, 512GB storage running Windows 11 for an early bird price of 3,000 RMB ($434 US), or a regular price of 3,499 RMB ($506). AMD Ryzen 7 6800U with Windows 11 selling for 2,000 RMB, or about $289 US (early bird price). Rockchip RK3588S octa-core Arm […]

May 4, 2023June 30, 2023 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

GL.iNet Spitz AX (GL-X3000NR) 5G NR WiFi 6 router review – Part 1: Specs, unboxing, and first boot

GL.iNet Spitz AX, also known as GL-X3000NR, is a compact 5G NR WiFi 6 router running OpenWrt 21.02 on a MediaTek Filogic 820 (TM7981A) dual-core Cortex-A53 processor coupled with 512MB DDR4 and 8GB eMMC flash, as well 2.5GbE and GbE interfaces, and a USB 2.0 port. The company sent us a Spitz AX router for evaluation, and in the first part of the review, we’ll go through the specifications, and do an unboxing and a teardown, before connecting it for a first boot. GL.iNet Spitz AX router specifications SoC – MediaTek MT7981A (Filogic 820) dual-core Arm Cortex-A53 processor @ 1.3 GHz System Memory – 512 MB DDR4 Storage – 8GB eMMC flash, MicroSD card slot up 1+ TB Networking 1x 2.5GbE WAN Ethernet port 1x Gigabit Ethernet LAN port Dual-band IEEE 802.11a/b/g/n/ac/ax WiFi 6 up to 574Mbps (2.4GHz), 2402Mbps (5GHz) RM520N-GL 5G cellular modem and 2x Nano SIM card slots […]

May 3, 2023May 4, 2023 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

Cologne GateMate A1 FPGA chip with 20,480 LE is programmable with an open-source toolchain

Cologne Chip GateMate A1 is an FPGA with 20,480 logic elements best suited for lower-power applications and programmable with an open-source toolchain based on nMigen, Yosys, and other open-source tools. The A1 FPGA also comes with 1,280 Kbit block SRAM, four PLLs, a quad SPI interface up to 100 MHz, a 5Gbps SerDes interface, and the company offers an evaluation board to get started with development. GateMate A1 specifications: CPE Architecture 20,480 programmable elements (CPE) for combinatorial and sequential logic 40,960 Latches / Flip-Flops within programmable elements CPE consists of LUT-tree with 8 inputs Each CPE is configurable as a 2-bit full-adder or 2×2-bit multipliers Features 4x programmable PLLs quad SPI interface up to 100 MHz 1,280 Kbit dual-ported block RAM with variable data widths in 32 x 40 Kbit RAM cells Multipliers with arbitrary size implementable in CPE array Multiple clocking schemas All 162 GPIOs are configurable as single-ended […]

May 3, 2023May 3, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

EPIC-ADS7-PUC Alder Lake-S embedded system is made for robotics, automation, healthcare imaging

AAEON EPIC-ADS7-PUC is an embedded system based on an up to 12th Gen Intel Core i7-12700E Alder Lake-S processor and designed for robotics, automation, and healthcare imaging applications. The embedded computer supports up to 32GB DDR5 and two SATA III storage devices, offers three 4K video outputs via HDMI and DisplayPort connectors, one 2.5GbE and three Gigabit Ethernet ports, along with Intel TCC support, up to six USB 3.2 Gen 2 ports, two RS232/422/4485 COM ports, and some SKUs support Intel Time Coordinated Computing (TCC) for real-time control. Key Features: SoC – Intel Core Alder Lake-S processor, up to the 12-core (8P+4E) Core i7-12700E processor clocked at up to 4.8 GHz with Intel UHD Graphics 770; TDP: 65W Chipset – Intel 600 Series Desktop Chipset (R680E/Q670E/H610E) System Memory – Up to 32GB DDR5 4800 via 2x SODIMM socket (16GB max each) Storage – 2x SATA 3 with +5V onboard SATA […]

May 2, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

AMD Radeon PCIe graphics card tested with a Rockchip RK3588 SBC (Radxa Rock 5B)

AMD Radeon PCIe graphics card Rockchip RK3588 SBC

When Rockchip first introduced the Rockchip RK3399 processor with a PCIe interface people initially hoped they could connect graphics card, but those hopes were quickly squashed due to a 32MB addressing limit. However, the PCIe implementation on the newer Rockchip RK3588 processor does not have such a limitation, and last November, Radxa teased a demo with an AMD Radeon Pro WX 5100 PCIe graphics card connected to the Rock 5B SBC running the glxgears demo on the Radeon GPU. I couldn’t find any instructions to reproduce this setup, but this got Jasbir interested, and he tried to do a test of his own with the Radxa Rock 5B connected to an AMD Radeon R7 520 (XFX R7 250 low-profile) through an “M.2 Key M Extender Cable to PCIE x16 Graphics Card Riser Adapter” ($14 plus taxes on Aliexpress) and powered by an LR1007 120W 12VDC ATX board. The experiment was […]

May 2, 2023May 29, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

BIGTREETECH Pad 7 7-inch 3D printer control display runs Klipper on Allwinner H616 SoM or Raspberry Pi CM4

Yesterday, I wrote about the BTT Pi V1.2 Allwinner H616 SBC designed for 3D printers, but also mentioned I had received the Pad 7 from BIGTREETECH which is a software-compatible, but more complete solution with a 7-inch display and an Allwinner H616-powered CB1 system-on-module compatible with the Raspberry Pi CM4. The BIGTREETECH Pad 7 should be more convenient to use with its integrated 7-inch touchscreen display, and if you ever decided you didn’t need it to control your 3D printer anymore, it could always be used as a small Linux computer running Raspberry Pi OS or another operating system. BIGTREETECH Pad 7 specifications: Supported modules BIGTREETECH CB1 v2.2 (included in the kit) – Allwinner H616 quad-core Cortex-A53 CPU with Mali-G31 MP2 GPU, 1GB RAM, 802.11 b/g/n WiFi 4 Raspberry Pi CM4 module with Broadcom BCM2711 quad-core Cortex-A72 CPU with VideoCore IV GPU, 1 to 8GB RAM, 0 to 32GB eMMC […]

April 28, 2023April 28, 2023 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Tinker Board S R2.0 SBC features Rockchip RK3288-CG W processor

ASUS Tinker Board S R2.0 is a revision of the original Tinker Board S board launched in 2018 with a 16GB eMMC flash. The R2.0 model relies on Rockchip RK3288-CG W quad-core Cortex-A17 processor and gets an upgrade to Bluetooth 4.2 from Bluetooth 4.0. The rest of the specifications remain the same with 2GB DDR3, HDMI 2.0 and MIPI DSI video interface, a MIPI CSI camera interface, a 3.5mm audio jack, Gigabit Ethernet, a WiFi 4 and Bluetooth 4.x module, four USB 2.0 host ports, and a 40-pin color-coded Raspberry Pi compatible header. Tinker Board S R2.0 specifications: SoC – Rockchip RK3288-CG.W quad-core ARM Cortex A17 processor up to 1.8 GHz with Mali-T764 GPU @ up to 600 MHz supporting OpenGL ES 1.1/2.0 /3.0, and OpenCL 1.1 System Memory – 2GB dual-channel DDR3 Storage – 16GB eMMC flash + microSD slot Video output & Display I/F 1x HDMI 2.0 up […]
