Category: Hardware

Posted on by Debashis Das - No Comments on ESP32-based Waveshare DDSM Driver HAT (B) for Raspberry Pi supports DDSM400 hub motors

ESP32-based Waveshare DDSM Driver HAT (B) for Raspberry Pi supports DDSM400 hub motors

Waveshare DDSM Driver HAT (B) Raspberry Pi DDSM motor driver

Waveshare has recently launched DDSM Driver HAT (B), a compact Raspberry Pi DDSM (Direct Drive Servo Motor) motor driver designed specifically to drive the DDSM400 hub motors. This board is built around an ESP32 MCU and supports wired (USB and UART) and wireless (2.4GHz WiFi) communication. Additionally, the board features a physical toggle switch, which lets it choose between the ESP32 control or USB control modes. On ESP32 control mode you can control the device through a built-in web application. In the USB control mode, the motor driver can be controlled via USB from a host computer sending JSON commands. An XT60 connector is used to power the board, and programming is done through a USB-C port that connects to the ESP32. The board is suitable for robotics projects, especially for mobile robots in 6×6 or 4×4 configurations. Waveshare DDSM Driver HAT (B) specifications: Wireless MCU – Espressif Systems ESP32-WROOM-32E ESP32 […]

Posted on by Tomisin Olujinmi - 1 Comment on Ditronix’s IPEM PiHat turns your Raspberry Pi into a mains power energy monitor (Crowdfunding)

Ditronix’s IPEM PiHat turns your Raspberry Pi into a mains power energy monitor (Crowdfunding)

Raspberry Pi 5 IPEM Power Energy Monitor

The IPEM PiHat is a HAT (Hardware Attached on Top) board for the Raspberry Pi that turns the single-board computer into a mains power energy monitor with four CT clamps. It provides an accurate way to track energy usage in home, office, and solar energy systems and is compatible with single-phase, two-phase, and three-phase electrical systems. The Raspberry Pi-based power energy monitor uses CT (current transformer) cable clamps to sample and measure data which can be used to report and analyze electric energy usage. This data can be used to save and divert energy to reduce costs and inefficiencies. The system is easy to set up and does not require a professional electrician. It uses a CT current clamp clipped over the building’s main power cables and connected to the local mains circuit for voltage and frequency measurement. The add-on board comes in two variants: IPEM PiHat and IPEM PiHat […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on OpenFlexture Microscope is an open-source, 3D-printed microscope based on Raspberry Pi 4 SBC and Camera Module v2

OpenFlexture Microscope is an open-source, 3D-printed microscope based on Raspberry Pi 4 SBC and Camera Module v2

OpenFlexure Microscope

The OpenFlexture Microscope is a DIY, open-source, 3D-printed microscope built around the Raspberry Pi 4, a Raspberry Pi Camera Module v2, and a choice of optics or various qualities up to lab-grade optics. It can be motorized using low-cost geared stepper motors and can achieve a resolution of up to around 100 nanometers I found out about the OpenFlexture Microscope in one of the sessions at the upcoming FOSDEM 2025 event whose description partially reads: The OpenFlexure Microscope is an open-source laboratory-grade digital robotic microscope. As a robotic microscope, it is able to automatically scan microscope slides creating, enormous multi-gigapixel digital representations of samples. The microscope is already undergoing evaluation for malaria and cancer diagnosis in Tanzania, Rwanda, and the Philippines. As an open project, our key goal is to support local manufacturing of microscopes in low-resource settings. [..] high-quality consistent documentation has enabled thousands of microscopes to be built […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on IBASE INA1607 is a fanless uCPE/SD-WAN appliance powered by an Intel Atom x7405C Amston Lake SoC

IBASE INA1607 is a fanless uCPE/SD-WAN appliance powered by an Intel Atom x7405C Amston Lake SoC

Intel Atom x7405C Amston Lake Appliance

IBASE Technology’s INA1607 is a fanless uCPE (universal Customer Premises Equipment) and SD-WAN (Software-defined WAN) appliance powered by an Intel Atom x7405C Amston Lake processor coupled with up to 16GB ECC or non-EEC DDR5 memory. The embedded computer comes with offers up to 64GB eMMC flash, features a 2.5-inch SATA bay, offers four 2.5GbE RJ45 ports, two dual-function GbE ports (RJ45/SFP), and supports wireless expansion for WiFi 6 or 4G LTE/5G modules through mini PCIe and M.2 slots and up to six antennas. IBASE INA1607 specifications: SoC – Intel Atom X7405C quad-core Amston Lake processor @ up to 2.2GHz with 6MB cache; TDP: 12W System Memory – Up to 16GB DDR5 4800MHz ECC/Non-ECC via SODIMM socket Storage 16GB, 32GB, or 64GB eMMC flash M.2 2280 B-Key 3042/3080 socket for SATA III or PCIe SSD 2.5-inch SATA drive bay Networking 4x 2.5GbE RJ45 ports via Intel i226-V controllers 2x GbE RJ45 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Morse Micro MM8108 WiFi HaLow SoC supports up to 43.33 Mbps transfer rate, improves range and power efficiency

Morse Micro MM8108 WiFi HaLow SoC supports up to 43.33 Mbps transfer rate, improves range and power efficiency

Morse Micro MM8108

Morse Micro MM8108 is a new WiFi HaLow (802.11ah) SoC with a throughput of up to 43.33 Mbps, and improved range and power efficiency compared to its predecessor the Morse Micro MM6108 introduced in 2022 and supporting up to 32.3 Mbps transfer rate. The new chip is also smaller at just 5x5mm in a BGA package instead of 6x6mm in a QFN48 package for the MM6108/MM6104, adds a USB 2.0 host interface besides SDIO 2.0 and SPI, as well as a MIPI RFFE (Radio Frequency Front-End) for integration and interoperability with multi-radio systems. Morse Micro MM8108 specifications: 32-bit RISC-V Host Applications Processor (HAP) Single-Chip IEEE802.11ah Wi-Fi HaLow transceiver for low-power, long-reach IoT applications Worldwide Sub-1 GHz frequency bands (850MHz to 950MHz) On-chip 26 dBm power amplifier with support for external FEM (Front End Module) option 1/2/4/8 MHz channel bandwidth for up to 43.3 Mbps data rate using 256-QAM modulation at […]

Posted on by Debashis Das - 5 Comments on Fully enclosed ESP32-S3 board features 1.8-inch AMOLED, microphone & speaker for AI audio applications

Fully enclosed ESP32-S3 board features 1.8-inch AMOLED, microphone & speaker for AI audio applications

ESP32 S3 1.8inch AMOLED display development board

Waveshare ESP32-S3-Touch-AMOLED-1.8 is an ESP32-S3 development board with an AMOLED display and AI audio support fully housed in a plastic enclosure. The most interesting feature of this devkit is its 1.8-inch AMOLED display with a 100000:1 contrast ratio and a wide 178° viewing angle, plus support for AI speech using its built-in microphone and speaker, and a built-in battery for IoT and AI applications. Other features include a QMI8658 6-axis IMU for motion detection, a PCF85063 RTC for time, and an ES8311 audio codec for high-quality audio. The ESP32-S3 provides Bluetooth and Wi-Fi connectivity and the board also features a USB-C port for power and programming. The AXP2101 power management IC enables battery charging and optimization, while GPIO, I2C, and UART pads allow expansion. Waveshare ESP32-S3-Touch-AMOLED-1.8 specifications Wireless MCU – Espressif Systems ESP32-S3R8 CPU – Dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration. Memory – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Review of SMARTHON Smart City IoT Starter Kit for BBC Micro:bit

Review of SMARTHON Smart City IoT Starter Kit for BBC Micro:bit

Smarthon Smart City IoT Starter Kit review

SMARTHON Smart City IoT Starter Kit for micro:bit is an educational kit for 10+ years old teaching basic projects from turning an LED to more complex projects with multiple sensors, IFTTT integration, and mobile app development. The company sent us a sample of the Start Kit along with a BBC Micro:bit board for review, and we’ll report our experience with the kit in this review. Unboxing of SMARTHON Smart City IoT Starter Kit for micro:bit The package I received includes the SMARTHON Smart City IoT Starter Kit for Micro:bit and a BBC Micro:bit V2 board since it’s not included in the starter kit. The bottom side of the package lists the main components and features a QR code pointing to the product page. The package includes cardboard and wooden models, various cables, a 180° servo, a screw set, a city map, the Smarthon IoT:bit carrier board for the BBC Micro:bit, […]

Posted on by Tomisin Olujinmi - No Comments on NXP MCX L14x and MCX L25x ultra-low-power Cortex-M33 MCUs target energy harvesting and battery-powered devices

NXP MCX L14x and MCX L25x ultra-low-power Cortex-M33 MCUs target energy harvesting and battery-powered devices

MCX L series chip

NXP Semiconductors has launched the MCX L series of ultra-low-power Arm Cortex-M33 MCUs with the MCX L14x and MCX L25x SKUs. The new series offers similar peripherals as the rest of the MCX portfolio but uses a new “power management architecture that supports always-on, battery-powered applications” The MCX L series uses a dual domain architecture, with “real-time processing and ultra-low-power sensing functions in a single device.” The Arm Cortex-M33 core supports real-time processing functions while the Arm Cortex-M0+ core offers always-on operation in the ultra-low-power sense domain. The new microcontrollers reportedly use three times less power than their predecessors. The ultra-low-power series is targeted at energy-constrained applications, powered by a battery, ultracapacitor, or power harvesting circuit. These include building control, industrial sensing, smoke and fire alarms, flow meters, smart appliances, and motion detectors. NXP MCX L14x and L25x specifications: CPU Main core: Arm Cortex-M33 microcontroller @ up to 96 MHz […]
