September 16, 2014June 15, 2015 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

How to Build Android 4.4 for Rockchip RK3288 Devices (Tronsmart Orion R28)

After blowing up my ATX power supply, and learning such things as “FULL” power supplies do exists, I finally managed to build Android for Tronsmart Orion R28 using the provided SDK. I haven’t tried to load it on the device yet, but the build could complete successfully after following the steps below in Ubuntu 14.04. The SDK is probably not specific to one device, so it might just also work on other RK3288 TV boxes and tablets. First download Android 4.4 SDK for RK3288, or use the one in the micro SD card provided with the Beta version of R28 Pro and Meta. Install some dependencies:

sudo apt-get install git-core gnupg flex bison gperf libsdl1.2-dev libesd0-dev libwxgtk2.8-dev \
squashfs-tools build-essential zip curl libncurses5-dev zlib1g-dev pngcrush schedtool libxml2 \
libxml2-utils xsltproc lzop libc6-dev schedtool g++-multilib lib32z1-dev lib32ncurses5-dev \
lib32readline-gplv2-dev gcc-multilib libswitch-perl gcc-arm-linux-gnueabi lzop libncurses5-dev \
libssl1.0.0 libssl-dev

sudo apt-get install git-core gnupg flex bison gperf libsdl1.2-dev libesd0-dev libwxgtk2.8-dev \

squashfs-tools build-essential zip curl libncurses5-dev zlib1g-dev pngcrush schedtool libxml2 \

libxml2-utils xsltproc lzop libc6-dev schedtool g++-multilib lib32z1-dev lib32ncurses5-dev \

lib32readline-gplv2-dev gcc-multilib libswitch-perl gcc-arm-linux-gnueabi lzop libncurses5-dev \

libssl1.0.0 libssl-dev

Extract the SDK:

tar xvf Orion_R28_SDK_doc.tar.gz

1	tar xvf Orion_R28_SDK_doc.tar.gz

And build the kernel first: Enter the kernel directory:

cd RK3288_R-BOX_ANDROID4.4.2-SDK_V1.0.0/kernel/

1	cd RK3288_R-BOX_ANDROID4.4.2-SDK_V1.0.0/kernel/

Change arch/arm/boot/dts/Makefile to use RK3288 device tree file instead of an RK3188 (may not be needed, but the build failed for me without that change…):

dtb-$(CONFIG_ARCH_ROCKCHIP) += rk3288-box.dtb

1	dtb-$(CONFIG_ARCH_ROCKCHIP) += rk3288-box.dtb

It’s also quite […]

September 16, 2014 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

WeIO is an Open Source Hardware IoT Board Programmable from a Web Browser (Crowdfunding)

WeIO is an open source hardware board for the Internet of things with Wi-Fi connectivity and lots of I/Os designed by nodesign, a French based startup, in collaboration of 8devices, the makers of the Carambola boards. WeIO is powered by an Atheros AR9331 SoC running OpenWRT as well as an NXP LPC MCU for faster handling of I/Os and support for analog I/Os. One interesting aspect of this board is that it can be programmed via a web browser using HTML5 or Python, and it does not rely on the Cloud to store data. WeIO hardware specifications: SoC – Atheros AR9331 MIPS 24K Wireless SoC @ 400 MHz MCU – NXP LPC11xx ARM Cortex M0 MCU for analog I/O and real-time H/W interfaces System Memory – 64 MB DDR2 Storage – 16 MB flash + micro SD slot Connectivity – 802.11 b/g/n Wi-Fi with on-board antenna (AP and STA modes), […]

September 15, 2014September 15, 2014 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Infineon XMC 2Go Cortex M0 Development Kit Sells for 5 Euros

Infineon brought another tiny, portable, and cheap ARM Cortex M0 board to market with XMC 2Go development kit featuring XMC1100 ARM Cortex M0 micro-controller with 16KB RAM, 64KB Flash, and tow breadboard friendly headers to access various serial interfaces and ADC pins. Key features listed on Infineon website: MCU – Infineon XMC1100 ARM Cortex-M0 MCU @ 32 MHz with 64KB flash, 16KB RAM. Debugger – On-board J-Link Lite Debugger using an XMC4200 Microcontroller. Headers – 2×8 pin headers suitable for Breadbord with access to 2x USIC (Universal Serial Interface Channel: UART, SPI, I2C, I2S, LIN), 6x 12-bit ADC, external interrupts (via ERU), 4x 16-bit timers Misc – 2 x user LED, RTC Power – 5V Micro via USB, or 3.3V external power. ESD and reverse current protection Dimensions – 14.0 x 38.5 mm The board is programmed via USB using the same Dave IDE I tried with XMC4500 Relax […]

September 15, 2014September 15, 2014 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

$125 Com 1 Android Wear Watch Powered by Ingenic JZ4775 MIPS Processor (Crowdfunding)

If you’d like to get an Android Wear watch, but are not quite ready to spend $200+ for the models currently available, the Com 1 Android Wear smartwatch could be interesting as you may get one for as low as $125, albeit with higher risks since it’s part of a flexible funding Indiegogo campaign. The watch is powered by Ingenic JZ4775 MIPS processor, features a 1.6″ AMOLED display, and is IP67 rated (Water- and dust-proof). Com 1 watch hardware specifications: SoC – Ingenic JZ4775 XBurst (MIPS) processor @ 1.0 GHz with 2D graphics, and VPU (MPEG-2, MPEG-4, VC-1, H.264, VP8, RV9), 720p@30fps System Memory – 375 MB LPDDR1 Storage – 4 GB eMMC Display – 1.6” AMOLED touchscreen display, 320 x 320 resolution, 16.7 Million Colors , LED back light, Brightness: 300 cd/m^2. Connectivity – WiFi (802.11 a/b/g/n at 2.4/5 GHz), Bluetooth 4.0 + EDR (BLE Compliant), FM, and NFC Sensors – […]

September 15, 2014September 15, 2014 by Jean-Luc Aufranc (CNXSoft) - No Comments

Qualcomm Unveils Snapdragon 210 LTE SoC for Entry-Level Smartphones

Android smartphones with LTE connectivity are now available for a little over $100, for example with LANDVO L200G powered by Mediatek MT6582 with an external MT6290 LTE modem, but prices may soon even get lower, as Qualcomm has now unveiled their latest Snapdragon 210 processor with integrated LTE modem to bring sub $100 LTE smartphones to market in 2015. For once, they’ve even provided detailed technical specifications for their new mobile application processor: Processor – Quad ARM Cortex A7 up to 1.1GHz GPU – Adreno 304 GPU with OpenGL ES 3.0, OpenCL, DirectX, content security, and decreased power consumption DSP – QDSP6 DSP Memory/Storage – LPDDR2/LPDDR3@533MHz, eMMC 4.5, and SD 3.0 (UHS-I) Display – Up to 720p, with external displays supported Modem Integrated 4G LTE-Advanced World Mode, supporting LTE FDD, LTE TDD, WCDMA (3C-HSDPA, DC-HSUPA), CDMA1x, EV-DO Rev. B, TD-SCDMA and GSM/EDGE 4G LTE CAT4 speeds of up to 150 […]

September 13, 2014September 13, 2014 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

Tronsmart Orion R28 Meta RK3288 TV Box Unboxing

GeekBuying sent me one of their Tronsmart Orion R28 Meta (Beta) Android TV boxes powered by Rockchip RK3288 SoC. This model comes with 2GB DDR3, 16 eMMC, and 802.11 b/g/n/ac Wi-Fi. R28 Mega is the mid-range model, and there are two others models R28 Pro (entre-level) and R28 Telos (premium). I’ve already listed specifications for the three Tronsmart Orion R28 models. Today, I’ll show some picture of the device, and the board to find out more about the design of the product. Before reviewing the product in another post, I’ll probably build the image using the provided Android 4.4 SDK (provided I can download it), and perform the full review next week with the resulting firmware. Tronsmart Orion Meta R28 Unboxing I’ve received the parcel via DHL within 2 days. The same package will be used for all three models, but you’ll have a sticker on the side for Pro, […]

September 12, 2014 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Intrinsyc OPEN-Q 8084 Development Kit Powered by Qualcomm Snapdragon 805 Processor

Inforce Computing IFC6540 was the first low cost development board powered by Qualcomm Snapdragon 805 processor I discovered a few months ago, but is currently “for pre-approved customers only and have not yet been released to public”. Intrinsyc has now launched their own Snapdragon 805 development kit called OPEN-Q 8084 based on a mini-ITX carrier board, and a SoM with 3GB RAM, and 16GB eMMC. The board target applications include ruggedized tablets, digital signage, government/public safety, medical, robotics, wearable displays, video streaming/conferencing, gaming systems, and in-flight entertainment. Specifications of APQ8084 Open-Q System-on-Module: SoC – Qualcomm Snapdragon 805 (APQ8084) quad core Krait 450 @ 2.5GHz, with Adreno 420 GPU @ 500MHz, Hexagon QDSP6 V5A (600MHz), and two ISPs for up to 55-megapixel stereoscopic 3D System Memory – 3GB PoP LPDDR3 RAM Storage – 16GB eMMC 5.0 flash, expandable to 64GB, micro SD signals, and SATA signals (via MXM connector) Connectivity – […]

September 11, 2014 by Jean-Luc Aufranc (CNXSoft) - No Comments

Marvell Announces Quad Core ARMADA 1500 PRO 4K STB SoC with HEVC 10-Bit Support

Marvell has just announced a new member of its ARMADA 1500 family of multimedia processors with ARMADA 1500 PRO 4K (88DE3214), a quad-core ARM processor (12K DMIPS), with a Vivante GC3000 GPU, and Qdeo video processor supporting 4K (UHD) output and HEVC 10-bit codec. These processors will be used in smart TVs, set-top boxes (STB), over-the-top (OTT) boxes, thin-client devices, etc.. Details are scarce, but ARMADA 1500 PRO 4K could be an evolution of the ARMADA 1500 PRO processors with four Cortex A9 cores as shown above, but with a different GPU, 4K and HEVC support, and possibly some extra features for DRM. The key features mentioned by the company are as follows: 3840×2160 (UHD) at 60 frames per second 10 bit HEVC Video Decode Up to 12K DMIPs Quad Core ARM CPU Multi-core GPU, 8 shader Vivante GC3000 GPU Robust Security Engine – Security features include Trusted Rendering Path […]
