Giveaway Week – WisBlock Kit 2 LoRa-based GPS Tracker with Solar Panel

The second prize of CNX Software’s giveaway week does not come directly from me, but instead, RAKwireless accepted to offer a sample to add to the event: Wisblock Kit 2.

The kit is a LoRa-based GPS tracker that comes with a sensor to detect location change every set time interval, and ships with a solar panel, although you could also offer it with a set of batteries (not included).

Since I’ve never written about this kit, let’s go through the main building blocks:

• RAK5005-O base board
  • Slots for 1x WisBlock Core MCU module, up to 4x WisBlock Sensor modules, and one WisBlock IO module
  • I2C, UART, GPIO’s and analog input accessible with solder contacts
  • Debugging – USB debug port
  • Misc- 2x user LED’s, reset button
  • Supports 3 different power supply sources
  • 1 slot for WisBlock Core MCU
• RAK4631 Wisblock Core module
  • WiSoC – Nordic nRF52840 with Bluetooth Low Energy 5.0 connectivity
  • LoRa
    • Sentech SX1262 transceiver
    • LoRaWan 1.0.2 protocol stack (supports Class A & C)
• RAK1904 accelerator module with STMicro LIS3DH acceleration sensor
• RAK1910 GPS module based on U-Blox MAX-7Q GNSS module with support for GPS/QZSS and GLONASS; 2.5m accuracy, 10 Hz update rate

You’ll find documentation on the RAK store where it is sold for $77.28 (also on Aliexpress), as well as an Arduino sketch sample on Github.

To enter the draw simply leave a comment with your country and whatever else you’d like to say. If the country is missing, I’ll consider the entry void. Other rules are as follows:

• Only one entry per contest. I will filter out entries with the same IP and/or email address.
• Contests are open for 48 hours starting at 10 am (Bangkok time) every day.
• Comments will be closed after 48 hours. If comments are open, the contest is still going on.
• Winners will be selected with random.org, and announced in the comments section of each giveaway.

• I’ll contact the winner by email, and I’ll expect an answer within 24 hours, or I’ll pick another winner.
• Note that I may not be able to contact people who log in with Facebook, Twitter, or Google, so it’s better to use an email address to enter the daw.
• Shipping will be handled by RAKwireless, and I’ll forward the winner’s email to arrange shipment.
• I’ll make sure we have 7 different winners, so if you have already won a device during this giveaway week, I’ll draw another person.

Good luck!

Jean-Luc Aufranc (CNXSoft)
